Technical features
- Indoor unit catalog code : GWH12AEC-K6DNA1A/I
- Outdoor unit catalog code : GWH12AEC-K6DNA1A/OI
- Power : 12000 Btu
- Integrated Wi-Fi
Energy efficiency
- SEER: 8.5
- SCOP: 4.6
- Energy Efficiency Class in Cooling : A+++
- Heating Energy Efficiency Class: A++
- Annual Energy Consumption in Cooling : 144 kWh/a
- Annual Energy Consumption in Heating: 974 kWh/a
Performance
- Cooling Capacity: 3.5 kW
- Heating Capacity: 3.81 kW
- Cooling absorption: 0.875 kW
- Heating absorption: 0.952 kW
- Treated Air Indoor Unit : 200~750 m 3 /h
- Sound Power Level Indoor Unit : 35~58 dB(A)
- External Unit Sound Power Level: 63 dB(A)
- Sound Pressure Level Indoor Unit : 21~43 dB(A)
- Sound Pressure Level Outdoor Unit : 53 dB(A)
Electrical data
- Power supply (V,Hz, Ø) : 220~240/50/1
- Refrigerant gas : R32
- Operating range
- - Cooling: -15° ~ 43°C
- - Heating: -15° ~ 24° C
Installation data
- Pipe diameter Liquid : 6.35 mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Maximum piping length: 20 m
- Maximum height difference Indoor Unit / Outdoor Unit: 10 m
Dimensions and weight
- Internal Unit Dimensions (HxWxD): 293x945x225 mm
- Indoor Unit Weight: 14 Kg
- External Unit Dimensions (HxWxD): 596x848x320 mm
- Weight of Outdoor Unit: 33.5 Kg
Gree G-Tech Disassembled in 5 Steps: Thorough do-it-yourself cleaning, maximum air quality always
Innovative Technology for Easier Maintenance
Unlike traditional systems for removing the electrical box and fan motor, with G-TECH maintenance and replacement operations are much faster and therefore more efficient. Requiring less time, they can be carried out more frequently, to the full advantage of the air quality in the room
Removing the fan motor
Different from the traditional method for removing the motor, which needs to detach the panel, panel frame and evaporator, now we can take out the motor just by removing the front decoration panel, side panel and electrical box. Therefore, we can have a quick replacement, saving time with more than 90% efficiency
Removing the electrical box
Remove the decorative detail: the side of the unit can be detached, so the electrical box can be pulled out: the intervention efficiency is increased by 50%. The condensate drain hose is easy to remove and install
Exclusive 3D Spiral Technology for Never Experienced Comfort
G-TECH adopts new technology to realize quadrangular airflow as gentle as a spring breeze. The combination of the two characterizing elements of this new air conditioner, i.e. great flexibility in the angle of the air outlet and width of the outlet, ensures homogeneous comfort throughout the room, for a comfort experience never experienced before
Thorough Cleaning in 5 Steps for High Quality Air
• Cleaning the filter
• Clean the air outlet grille
• Cleaning of the air delivery
• Cleaning of the fan unit and the condensate collection tray: G-TECH has an exclusive separate system for these two components, which can therefore be disassembled without involving electrical parts
• Coil cleaning: evaporating; this operation requires the intervention of specialized personnel
Dust that accumulates inside the indoor unit can lead to the growth of microorganisms that are harmful to health; they can in fact cause asthma, allergies, chronic bronchitis and even infectious diseases. With G-TECH the user can autonomously carry out some operations for the benefit of always better air quality. The procedure takes place in 5 steps: for the first 4 the user can proceed alone in maximum safety because the electrical components are separate
AR (Augmented Reality) display
Fun, Practical, Efficient
By downloading the Greeunity app, using the QR code, click on the image of the internal unit that appears on the screen, you can rotate the image 720° and see its detailed exploded view. Then there are 4 items on the menu that allow you to learn more about the distinctive characteristics of this product. The display also acts as a guide for after-sales, facilitating maintenance and / or repair activities
Remote Wi-Fi
Thanks to the integrated WIFI module, it is possible to control the operation of the unit remotely via the APP on your smartphone, turn the unit on or off, select the desired mode and temperature, etc., to program your comfort at any time, even when you are away from home
I Feel
The sensor built into the remote controller senses the surrounding temperature and transmits the signal to the indoor unit. In this way the indoor unit can adjust the volume and temperature of the airflow to ensure maximum comfort at the exact point where the remote control is placed, not where the unit is located
4-Way Air Delivery - 3D Swing
The flaps, both horizontal and vertical, can be adjusted automatically by remote control, in order to optimize the air flow in the room
Cold Plasma Air Purification System
It releases ions capable of neutralizing bacteria, fungi, viruses, pollen, mites and pollutants present in the air in general, making the environment healthy and the air pleasant. It guarantees effective sterilization of the air, killing over 90% of bacteria. Removes over 400 kinds of odors. Improves air quality, enriching it with negative ions.
Door Control Contact
This function allows you to use the magnetic card on the entrance door (for example in hotel rooms) to control the switching on and off of the air conditioner. By inserting the card, the air conditioner starts, by removing the card, the air conditioner stops. In this way, waste of energy is avoided. For this application it is necessary to use the wired controller
Attractive Design Covered by Over 360 Patents
Extra-glossy and very elegant is the characteristic of this unit with an Exclusive design. Made with over 360 patents including 2 design patents, 210 invention and 150 unit model patents.
