Technical features
Internal Unit
1)Model:
- Indoor Unit Catalog Code: 2x MFZ-KT25VG
- Typology : Inverter
- Power (BTU) : 9000
- Weight : 14.5Kg
2) Model
- Indoor Unit Catalog Code: 1 x MFZ-KT50VG
- Typology : inverter
- Power (BTU) : 18000
- Weight : 14.5Kg
Outdoor Unit
Model:
- Outdoor Unit Catalog Code: MXZ-3F68VF3
- Max number of connectable indoor units: 3
- Weight : 58Kg
Cooling Technical Features:
- Nominal Capacity (min/max): 6.8Kw (2.9-8.4)
- Nominal Absorbed Power: 1.84 Kw
- SEER : 7.96 kW
- Energy Efficiency Class: A++
- Annual Energy Consumption: 299 KWh/a
- Theoretical load: 6.8 kW
Heating Technical Features:
- Nominal Capacity (min/max): 8.6Kw (2.6-10.6)
- Nominal Absorbed Power: 1.91 Kw
- SCOP : 4.12 kW
- Energy Efficiency Class: A+
- Annual Energy Consumption: 2312 Kwh/a
- Theoretical load: 6.8 kW
Performances;
- Sound Pressure min/max : 48/53 dB (A)
- Rated Sound Power : 63dB (A)
Dimensions:
- Indoor Unit H x W x D : 600 x 750 x 215
- Outdoor Unit H x W x D : 710 x 840 x 330
Installation data :
- Liquid Pipe Diameter : 6.35 mm (1/4) x3
- Gas Pipe Diameter : 9.52 mm (3/8) x3
- Maximum Piping Length: 60 m
- Maximum height difference Internal Unit/External Unit: 15 m External Unit Above
- Maximum height difference Internal unit7 External unit: 10 m External unit Below
Operating Range:
- Cooling : 10 ~ +46 °C
- Heating : 15 ~ +24 °C
General characteristics
MFZ-KT units are designed to optimize air distribution and offer a simple and elegant design to adapt to any type of furniture.
- Compact And Refined Design
- High Energy Efficiency
- Exclusive deflector movement
- High Efficiency Antibacterial Filter Supplied
- Multi-split compatible
High Heating Capacity :
The MFZ-KT model has a high capacity in heating mode compared to traditional air conditioners, which makes it suitable for winter and mid-season use.
V Blocking Air Purifier Filter Included:
V Blocking is a new purifying filter that improves on the previous silver ion filtering system, adding an antivirus action capable of inhibiting viruses, bacteria, molds and allergens.
Standard Purifier Filter Supplied:
The standard purifying filter ensures the removal of coarse polluting particles such as dust and impurities from the air with an additional antibacterial, anti-mold and odor-trapping effect
Multi-Flow Vane :
The delivery vent is characterized by the presence of three different deflectors, each with a profile specifically designed to optimize the distribution of the outgoing air, maximizing comfort in both cooling and heating.
