icon Midea Air Conditioner 4 Way Cassette 12000 Btu Mcae-35 60x60 Class A++ | CaldaieMurali

Midea Air Conditioner 4 Way Cassette 12000 Btu Mcae-35 60x60 Class A++

Important Notice on Regulations for Fluorinated Gases IN ITALY

In accordance with Regulation (EU) No. 517/2014 and Presidential Decree No. 146/2018, equipment containing fluorinated gases that is not hermetically sealed can only be sold if installed by a certified company.

By law, each sale must be recorded in the Fluorinated Gas Database, including a declaration from the buyer ensuring that the installation complies with the regulations. Therefore, before completing the order, it will be necessary to provide this mandatory declaration.

Description

Technical features

Model:

Indoor unit code: MCAE-35
Outdoor unit code: MOUE-35K
Technology: 3D DC INVERTER
Power: 12000 btu/h

Energy efficiency:

Cooling efficiency SEER: 6.1
SCOP coefficient of performance: 4.0
Energy Efficiency Class (cooling): A++
Energy Efficiency Class (heating): A+
Annual Energy Consumption cooling/heating kWh/A: 201/1260

Performance:
Power Output in cooling: 3.5 kW
Power Output in heating: 4.1 kW
Power absorbed in cooling: 960 W
Power absorbed in heating: 995 W
Air Flow (Max / Med / Min) (m3/h): 650/530/450
Indoor unit Sound Pressure (Max / Med / Min) (db(A)): 41/37/33
Internal unit sound power max db(A); 58

Characteristics:

Power supply (V/Hz/Φ) : 230/50/1
Refrigerant Piping Liquid / Gas Line: mm(inch) 6.35(1/4") / 9.52(3/8")
Operating Limit Temperature: -15

Dimensions and weight:

Indoor Unit (LxWxH): 570x570x260 mm; 16 Kgs
Panel (LxWxH) 647x647x50 mm; 2.5kg
Outdoor Unit (LxWxH): 800x333x555 mm; 35 kgs

General characteristics

60x60cm 4-Way Mono Cassette Indoor Units

Integrated drain pump

The drain pump, capable of lifting the condensed water up to 750mm, is standard for both the 4-Way Cassette and the Ducted units

Fresh air intake

The “Aria Fresca” intake is standard, it is easy to connect it to the external air passage hole.

Technical rooms air conditioning

A special technology allows all Midea Splits to be able to operate in "cooling" mode even with external temperatures down to -15°. Ideal for air conditioning Server Rooms and/or technical rooms.

Internal control box

All the control electronics are "compressed" inside a special box: this allows the product dimensions to be reduced to a minimum and maintenance and assistance to be facilitated

Arrangement of wall controls

Some Midea ranges are designed to be controlled not only via remote control but also via wall controls and/or weekly timers (optional accessories).

Series features:

Gas Leak Alarm : In the event that careless installation of the system should cause micro-leaks of refrigerant gas, the system displays a specific alarm signal.

Self-diagnosis A performance monitoring system allows Midea air conditioners to diagnose any malfunctions and breakdowns.

Technical rooms air conditioning A special technology allows all Midea Splits to be able to operate in "cooling" mode even with external temperatures down to -15°. Ideal for air conditioning Server Rooms and/or technical rooms.

Outdoor Unit Heating Tape A PTC heating tape mounted on the base plate of the outdoor unit prevents rain, water or snow from accumulating, ensuring safer operation.

Follow me Midea remote controls are equipped with a temperature sensor, which the unit considers as "ambient temperature". The air conditioner therefore works by "following" the real temperature perceived by the user.

Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Midea Air Conditioner 4 Way Cassette 12000 Btu Mcae-35 60x60 Class A++

Product form

Technical features Model: Indoor unit code: MCAE-35 Outdoor unit code: MOUE-35K Technology: 3D DC INVERTER Power: 12000 btu/h Energy efficiency:... Read more

€922,00 Incl. VAT

    Description

    Technical features

    Model:

    Indoor unit code: MCAE-35
    Outdoor unit code: MOUE-35K
    Technology: 3D DC INVERTER
    Power: 12000 btu/h

    Energy efficiency:

    Cooling efficiency SEER: 6.1
    SCOP coefficient of performance: 4.0
    Energy Efficiency Class (cooling): A++
    Energy Efficiency Class (heating): A+
    Annual Energy Consumption cooling/heating kWh/A: 201/1260

    Performance:
    Power Output in cooling: 3.5 kW
    Power Output in heating: 4.1 kW
    Power absorbed in cooling: 960 W
    Power absorbed in heating: 995 W
    Air Flow (Max / Med / Min) (m3/h): 650/530/450
    Indoor unit Sound Pressure (Max / Med / Min) (db(A)): 41/37/33
    Internal unit sound power max db(A); 58

    Characteristics:

    Power supply (V/Hz/Φ) : 230/50/1
    Refrigerant Piping Liquid / Gas Line: mm(inch) 6.35(1/4") / 9.52(3/8")
    Operating Limit Temperature: -15

    Dimensions and weight:

    Indoor Unit (LxWxH): 570x570x260 mm; 16 Kgs
    Panel (LxWxH) 647x647x50 mm; 2.5kg
    Outdoor Unit (LxWxH): 800x333x555 mm; 35 kgs

    General characteristics

    60x60cm 4-Way Mono Cassette Indoor Units

    Integrated drain pump

    The drain pump, capable of lifting the condensed water up to 750mm, is standard for both the 4-Way Cassette and the Ducted units

    Fresh air intake

    The “Aria Fresca” intake is standard, it is easy to connect it to the external air passage hole.

    Technical rooms air conditioning

    A special technology allows all Midea Splits to be able to operate in "cooling" mode even with external temperatures down to -15°. Ideal for air conditioning Server Rooms and/or technical rooms.

    Internal control box

    All the control electronics are "compressed" inside a special box: this allows the product dimensions to be reduced to a minimum and maintenance and assistance to be facilitated

    Arrangement of wall controls

    Some Midea ranges are designed to be controlled not only via remote control but also via wall controls and/or weekly timers (optional accessories).

    Series features:

    Gas Leak Alarm : In the event that careless installation of the system should cause micro-leaks of refrigerant gas, the system displays a specific alarm signal.

    Self-diagnosis A performance monitoring system allows Midea air conditioners to diagnose any malfunctions and breakdowns.

    Technical rooms air conditioning A special technology allows all Midea Splits to be able to operate in "cooling" mode even with external temperatures down to -15°. Ideal for air conditioning Server Rooms and/or technical rooms.

    Outdoor Unit Heating Tape A PTC heating tape mounted on the base plate of the outdoor unit prevents rain, water or snow from accumulating, ensuring safer operation.

    Follow me Midea remote controls are equipped with a temperature sensor, which the unit considers as "ambient temperature". The air conditioner therefore works by "following" the real temperature perceived by the user.

    Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
    Data sheetData sheet
    • peso: 35.0 kg
    • classe energetica raffreddamento: A++
    • classe energetica riscaldamento: A+
    • gas: R-32
    • marca: Midea
    • metri quadri : 25-40 m2
    • modello: CLIMAT_1165
    • potenza btu: 12000
    • superficie riscaldabile mq: 35
