Technical features
- Dimensions : 760x775x520mm
- Net weight : 212 kg
- Fire mouth dimensions: 519x340 mm
- Fireplace dimensions: 570x300x325 mm
- Smoke outlet diameter: 150 mm sup
- Hearth : Cast Iron-Ironker
- heated m3: 430 m3
- Power rendered to the liquid: 8.5 kW
- Ambient output power: 6.5 kW
- Nominal thermal power useful : 15 kW
- Overall thermal power: 19.1 kW
- Exchanger fluid content: 14.5 l
- Operating pressure : 3 bar
- Optimum working temperature: 70°-75°C
- Ø Boiler connection: 1" F Gas
- Regulated primary air : Yes
- Secondary air reg. : Yes
- Tertiary air pret. : Yes
- Efficiency : 78.4%
- Hourly consumption : 4.4 kg/h
- Draft : 1.7/2.0 mm
General characteristics
WOOD STOVES
The particular attention aimed at protecting the environment and total respect for the ecosystem were the inputs that prompted La NORDICA-EXTRAFLAME to make large investments in product research and development, thus allowing for very high yields and low consumption, using only wood , fuel that is produced by nature and which returns to it through a perpetual circular flow.
Our country has large wooded areas, and is therefore able to offer a varied quantity of wood. By using this resource, you can reap significant benefits:
Environmental plan:
In nature, it has been proven that wood, when it completes the decomposition cycle, releases a quantity of CO2 (carbon dioxide) into the atmosphere which is then used for the regrowth and development of new plants.
Economic plan:
2.3Kg of dry wood have a calorific value equal to 1lt of diesel or 1m3 of natural gas. Given the equal benefit, only the cost varies, which for the purchase of wood will be 50-60% lower than for other fuels.
THERMAL INSULATION
From the elegantly classic line, connected to a thermo-sanitary system, it also allows you to heat the radiators of your home with the healthy and clean heat from the wood.
- With integrated DSA system ( possibility of producing domestic hot water by connecting the thermo-cooker to a boiler)
- Entirely in enamelled cast iron
- Ceramic glass resistant up to 750 °C
-
Thanks to the thermo-sanitary system, it heats the whole house.
Wood stove technologies:
the combustion system developed by La Nordica-Extraflame allows, thanks to a secondary/tertiary air system, a post-combustion capable of drastically reducing emissions and therefore complying with the most restrictive European regulations
- RESISTANT DOOR AT THE TIME
the doors of La Nordica-Extraflame products are made of high quality cast iron. This material, even if subjected to strong thermal stresses, does not undergo expansion or alteration of its shape.
it is a system which effectively avoids the formation of deposits on the glass of the fire door through a specific path of preheated air
it is a safety device for abruptly lowering the water temperature according to current regulations. This allows the installation of a solid fuel appliance (wood) with a closed expansion vessel
