icon Hisense Trial Split Console 9+9+12 Air Conditioner with 3AMW72U4RJC R-32 Wi-Fi Optional with Remote Control as Standard 9000+9000+12000 | CaldaieMurali

Hisense Trial Split Console 9+9+12 Air Conditioner with 3AMW72U4RJC R-32 Wi-Fi Optional with Remote Control as Standard 9000+9000+12000

Important Notice on Regulations for Fluorinated Gases IN ITALY

In accordance with Regulation (EU) No. 517/2014 and Presidential Decree No. 146/2018, equipment containing fluorinated gases that is not hermetically sealed can only be sold if installed by a certified company.

By law, each sale must be recorded in the Fluorinated Gas Database, including a declaration from the buyer ensuring that the installation complies with the regulations. Therefore, before completing the order, it will be necessary to provide this mandatory declaration.

Description

Technical features

Internal units

1) Model

  • Indoor unit catalog code: 2x AKT26UR4RK8
  • Power: 9000 Btu
  • Cooling capacity: 2.6 kW
  • Heating capacity: 3.2 kW
  • Air flow rate: 10 m3 /min
  • Sound power level: 56 dB(A)
  • Sound pressure level : 33~40 dB(A)
  • Liquid pipe diameter: 6.35 mm (1/4")
  • Gas pipe diameter: 9.52 mm (3/8")
  • Internal unit dimensions (WxHxD): 700x630x220 mm
  • Weight: 15.0 Kg
  • Optional Wi-Fi: AEH-W4GX
  • Optional wired control: YXE-C01U

2) Model

  • Indoor unit catalog code: 1x AKT35UR4RK8
  • Power: 12000 Btu
  • Cooling capacity: 3.5 kW
  • Heating capacity: 4.0 kW
  • Air flow rate: 10 m3 /min
  • Sound power level: 55 dB(A)
  • Sound pressure level : 33~40 dB(A)
  • Liquid pipe diameter: 6.35 mm (1/4")
  • Gas pipe diameter: 9.52 mm (3/8")
  • Internal unit dimensions (WxHxD): 700x630x220 mm
  • Weight: 15.0 Kg
  • Optional Wi-Fi: AEH-W4GX
  • Optional wired control: YXE-C01U

External unit

  • Outdoor unit catalog code: 3AMW72U4RJC
  • Number of connectable indoor units : Up to 3 indoor units

Energy efficiency

  • SEER : 7.8
  • SCOP : 4.35
  • Energy efficiency class cooling: A++
  • Heating energy efficiency class: A+
  • Annual energy consumption in cooling: 283 kWh/a
  • Annual energy consumption in heating: 1920 kWh/a

Performance

  • Cooling capacity: 7.0 kW
  • Heating capacity: 8.0 kW
  • Cooling absorption: 1.75 kW
  • Heating absorption: 2.00 kW
  • Sound power level: 68 dB(A)
  • Sound pressure level : 54~60 dB(A)

Electrical data

  • Power supply (V/Hz/Ø) : 220~240/50/1
  • Refrigerant gas: R-32
  • Guaranteed temperature range:
    - Cooling: -15° ~ 50° C
    - Heating: -20° ~ 24° C

Installation data

  • Liquid tube diameter: 6.35mm (1/4") x3
  • Gas pipe diameter: 9.52 mm (3/8") x3
  • Maximum pipe length: 45 m
  • Maximum height difference between internal unit and external unit: 15 m

Dimensions and weight

  • External unit dimensions (WxHxD): 860x670310 mm
  • External unit weight: 49.0 Kg

3 year warranty (5 on compressor)

Warranty

The Hisense Italia warranty can be activated within 1 month from the date of purchase at http://www.hisenseitalia.it/clima/supporto


Multisplit external unit technologies

High efficiency DC Twin Rotary inverter compressor

The design of the new BLDC Inverter double rotor compressor guarantees better balance and reduced vibrations. This translates into maximum silence and excellent performance in terms of efficiency and energy saving.

High efficiency.jpg

Full DC inverter

Hisense Inverter Expert technology ensures high efficiency and low noise levels thanks to the combined action of the DC Inverter compressor, the DC Inverter fan motor and the electronic expansion valve.

Full DC inverter.jpg Compact and versatile

The dimensions of the new Free Match outdoor units have been reduced by 10% to allow installation even in small spaces.

Compact and versatile.jpg

Maximum comfort even in winter

The outdoor unit uses an electronic expansion valve that regulates and optimizes the amount of refrigerant for all operating indoor units.

Maximum comfort.jpg Super warm up

The new Free Match external units guarantee maximum efficiency even at low temperatures, down to -20°

Super warm-up.jpg


180° sine wave DC drive technology

The system constantly monitors the compressor frequency and creates the most efficient waveform to determine effective consumption savings.

Curve control

Driver della curva Hisense


Rubidium magnet compressor

Thanks to the greater compression of the gas molecules, the compressor with rubidium magnet guarantees greater efficiency and lower absorption.

Compressore


Electronic expansion valve

The outdoor unit uses an electronic expansion valve that regulates and optimizes the amount of refrigerant in all operating indoor units.

Wide voltage range operation

The outdoor unit can operate with a voltage from 176V to 264V. In the new models, the use of an automatic voltage regulation technique ensures that the protection value is adjusted accordingly, maintaining the operating frequency at an optimal value.

Exchanger design: designed to improve efficiency

The design of the external exchanger has been designed to increase heat transfer in such a way as to make the refrigeration circuit more efficient and avoid the creation of ice blocks. Another advantage is that it can support long distance connections between the external unit and the internal units without reducing the cooling capacity.

Green Gas More efficient and better for the environment

R32 is an environmentally friendly gas with a higher cooling capacity for the same volume. This means that less refrigerant is needed in each device, thus reducing global warming. The advantages of R32 gas are that it has no effect on ozone in the air, GWP (global warming impact) 66% lower than R410A gas, higher energy efficiency, higher thermal conductivity and higher cooling capacity.

Ecological gas.jpg


Hisense R-32 Console

Console

Air flow

The combination of upper and lower air flow always ensures uniform air flow for comfortable air conditioning.

It is possible to limit the flow rate via DIP Switch

  • Remove the front panel
  • Move the DIP Switch on the right side to ON

If no DIP switch is operated, the air conditioner regulates the air flow automatically.

Display

The display, which can be activated by remote control, shows the temperature and humidity in the room when set to dehumidification mode.


Installation Mode


Installation flexibility

Refrigerant and condensate drain pipes can be connected freely in any direction, including the sides.

Humidity control

Anti-condensation control works automatically in high humidity conditions to ensure no dripping from the indoor unit


I feel

The sensor inside the remote control can detect the surrounding temperature and transmit this information to the indoor unit. The indoor unit operates according to the detected temperature. Intelligent temperature control ensures a more comfortable environment and more precise temperature control, saving energy

Wi-Fi Control

Hisense air conditioners can be conveniently managed inside and outside the home with a mobile device and a Wi-Fi connection. HiSmart Life is the simple-to-use app with an intuitive interface that allows you to control the air conditioner wherever you are. The app is available for iOS and Android.

After downloading the app and pairing the air conditioner, the app allows you to manage the operating mode, temperature, fan speed and air flow. From the "Smart Function" section you can also set daily or weekly timers.

Controllo Wi-Fi.jpg


Smart Voice Control

The new HiSmart Life app is compatible with Alexa and Google Assistant: thanks to voice interaction, you can turn on, turn off, adjust the temperature and set the desired operating mode (cooling or heating).

You can find HiSmart Life in Alexa Skills and in the Google Assistant catalog.

Controllo Smart Voice.jpg



Product Warranty : The warranty on this item is 24 months from the date of purchase.

Hisense Trial Split Console 9+9+12 Air Conditioner with 3AMW72U4RJC R-32 Wi-Fi Optional with Remote Control as Standard 9000+9000+12000

Product form

Technical features Internal units 1) Model Indoor unit catalog code: 2x AKT26UR4RK8 Power: 9000 Btu Cooling capacity: 2.6 kW Heating... Read more

€2.113,00 Incl. VAT

    Description

    Technical features

    Internal units

    1) Model

    • Indoor unit catalog code: 2x AKT26UR4RK8
    • Power: 9000 Btu
    • Cooling capacity: 2.6 kW
    • Heating capacity: 3.2 kW
    • Air flow rate: 10 m3 /min
    • Sound power level: 56 dB(A)
    • Sound pressure level : 33~40 dB(A)
    • Liquid pipe diameter: 6.35 mm (1/4")
    • Gas pipe diameter: 9.52 mm (3/8")
    • Internal unit dimensions (WxHxD): 700x630x220 mm
    • Weight: 15.0 Kg
    • Optional Wi-Fi: AEH-W4GX
    • Optional wired control: YXE-C01U

    2) Model

    • Indoor unit catalog code: 1x AKT35UR4RK8
    • Power: 12000 Btu
    • Cooling capacity: 3.5 kW
    • Heating capacity: 4.0 kW
    • Air flow rate: 10 m3 /min
    • Sound power level: 55 dB(A)
    • Sound pressure level : 33~40 dB(A)
    • Liquid pipe diameter: 6.35 mm (1/4")
    • Gas pipe diameter: 9.52 mm (3/8")
    • Internal unit dimensions (WxHxD): 700x630x220 mm
    • Weight: 15.0 Kg
    • Optional Wi-Fi: AEH-W4GX
    • Optional wired control: YXE-C01U

    External unit

    • Outdoor unit catalog code: 3AMW72U4RJC
    • Number of connectable indoor units : Up to 3 indoor units

    Energy efficiency

    • SEER : 7.8
    • SCOP : 4.35
    • Energy efficiency class cooling: A++
    • Heating energy efficiency class: A+
    • Annual energy consumption in cooling: 283 kWh/a
    • Annual energy consumption in heating: 1920 kWh/a

    Performance

    • Cooling capacity: 7.0 kW
    • Heating capacity: 8.0 kW
    • Cooling absorption: 1.75 kW
    • Heating absorption: 2.00 kW
    • Sound power level: 68 dB(A)
    • Sound pressure level : 54~60 dB(A)

    Electrical data

    • Power supply (V/Hz/Ø) : 220~240/50/1
    • Refrigerant gas: R-32
    • Guaranteed temperature range:
      - Cooling: -15° ~ 50° C
      - Heating: -20° ~ 24° C

    Installation data

    • Liquid tube diameter: 6.35mm (1/4") x3
    • Gas pipe diameter: 9.52 mm (3/8") x3
    • Maximum pipe length: 45 m
    • Maximum height difference between internal unit and external unit: 15 m

    Dimensions and weight

    • External unit dimensions (WxHxD): 860x670310 mm
    • External unit weight: 49.0 Kg

    3 year warranty (5 on compressor)

    Warranty

    The Hisense Italia warranty can be activated within 1 month from the date of purchase at http://www.hisenseitalia.it/clima/supporto


    Multisplit external unit technologies

    High efficiency DC Twin Rotary inverter compressor

    The design of the new BLDC Inverter double rotor compressor guarantees better balance and reduced vibrations. This translates into maximum silence and excellent performance in terms of efficiency and energy saving.

    High efficiency.jpg

    Full DC inverter

    Hisense Inverter Expert technology ensures high efficiency and low noise levels thanks to the combined action of the DC Inverter compressor, the DC Inverter fan motor and the electronic expansion valve.

    Full DC inverter.jpg Compact and versatile

    The dimensions of the new Free Match outdoor units have been reduced by 10% to allow installation even in small spaces.

    Compact and versatile.jpg

    Maximum comfort even in winter

    The outdoor unit uses an electronic expansion valve that regulates and optimizes the amount of refrigerant for all operating indoor units.

    Maximum comfort.jpg Super warm up

    The new Free Match external units guarantee maximum efficiency even at low temperatures, down to -20°

    Super warm-up.jpg


    180° sine wave DC drive technology

    The system constantly monitors the compressor frequency and creates the most efficient waveform to determine effective consumption savings.

    Curve control

    Driver della curva Hisense


    Rubidium magnet compressor

    Thanks to the greater compression of the gas molecules, the compressor with rubidium magnet guarantees greater efficiency and lower absorption.

    Compressore


    Electronic expansion valve

    The outdoor unit uses an electronic expansion valve that regulates and optimizes the amount of refrigerant in all operating indoor units.

    Wide voltage range operation

    The outdoor unit can operate with a voltage from 176V to 264V. In the new models, the use of an automatic voltage regulation technique ensures that the protection value is adjusted accordingly, maintaining the operating frequency at an optimal value.

    Exchanger design: designed to improve efficiency

    The design of the external exchanger has been designed to increase heat transfer in such a way as to make the refrigeration circuit more efficient and avoid the creation of ice blocks. Another advantage is that it can support long distance connections between the external unit and the internal units without reducing the cooling capacity.

    Green Gas More efficient and better for the environment

    R32 is an environmentally friendly gas with a higher cooling capacity for the same volume. This means that less refrigerant is needed in each device, thus reducing global warming. The advantages of R32 gas are that it has no effect on ozone in the air, GWP (global warming impact) 66% lower than R410A gas, higher energy efficiency, higher thermal conductivity and higher cooling capacity.

    Ecological gas.jpg


    Hisense R-32 Console

    Console

    Air flow

    The combination of upper and lower air flow always ensures uniform air flow for comfortable air conditioning.

    It is possible to limit the flow rate via DIP Switch

    • Remove the front panel
    • Move the DIP Switch on the right side to ON

    If no DIP switch is operated, the air conditioner regulates the air flow automatically.

    Display

    The display, which can be activated by remote control, shows the temperature and humidity in the room when set to dehumidification mode.


    Installation Mode


    Installation flexibility

    Refrigerant and condensate drain pipes can be connected freely in any direction, including the sides.

    Humidity control

    Anti-condensation control works automatically in high humidity conditions to ensure no dripping from the indoor unit


    I feel

    The sensor inside the remote control can detect the surrounding temperature and transmit this information to the indoor unit. The indoor unit operates according to the detected temperature. Intelligent temperature control ensures a more comfortable environment and more precise temperature control, saving energy

    Wi-Fi Control

    Hisense air conditioners can be conveniently managed inside and outside the home with a mobile device and a Wi-Fi connection. HiSmart Life is the simple-to-use app with an intuitive interface that allows you to control the air conditioner wherever you are. The app is available for iOS and Android.

    After downloading the app and pairing the air conditioner, the app allows you to manage the operating mode, temperature, fan speed and air flow. From the "Smart Function" section you can also set daily or weekly timers.

    Controllo Wi-Fi.jpg


    Smart Voice Control

    The new HiSmart Life app is compatible with Alexa and Google Assistant: thanks to voice interaction, you can turn on, turn off, adjust the temperature and set the desired operating mode (cooling or heating).

    You can find HiSmart Life in Alexa Skills and in the Google Assistant catalog.

    Controllo Smart Voice.jpg



    Product Warranty : The warranty on this item is 24 months from the date of purchase.

    Data sheetData sheet
    • peso: 80.0 kg
    • classe energetica raffreddamento: A++
    • classe energetica riscaldamento: A+
    • gas: R-32
    • marca: Hisense
    • modello: ACT 9+9+12 72
    • potenza btu: 9000+9000+12000
    • superficie riscaldabile mq: 25/25/35
