icon Hisense Dual Split Console Air Conditioner 12 + 12 With 3amw62u4rjc R-32 Wi-Fi Optional Serial Remote Control Included 12000 + 12000 | CaldaieMurali

Hisense Dual Split Console Air Conditioner 12 + 12 With 3amw62u4rjc R-32 Wi-Fi Optional Serial Remote Control Included 12000 + 12000

Important Notice on Regulations for Fluorinated Gases IN ITALY

In accordance with Regulation (EU) No. 517/2014 and Presidential Decree No. 146/2018, equipment containing fluorinated gases that is not hermetically sealed can only be sold if installed by a certified company.

By law, each sale must be recorded in the Fluorinated Gas Database, including a declaration from the buyer ensuring that the installation complies with the regulations. Therefore, before completing the order, it will be necessary to provide this mandatory declaration.

Description

Technical features

Indoor units

1) Model:

  • Internal Unit Catalog Code: 1x TQ25XE0BG
  • Series: Energy
  • Power: 9000 btu/h
  • Cooling/Heating Capacity: 2.6/3.0 kW
  • Air flow: 600 m 3 /h
  • Sound pressure level (min-max): 19-39 dB(A)
  • Internal Unit Dimensions (WxHxD): 850x270x208 mm
  • Indoor Unit Weight: 8.5 Kg
  • Integrated Wi-Fi

2) Model:

  • Internal Unit Catalog Code: 1x TQ35XE0AG
  • Series: Energy
  • Power: 12000 btu/h
  • Cooling/Heating Capacity: 3.5/4.1 kW
  • Air flow: 620 m 3 /h
  • Sound pressure level (min-max): 19-29 dB(A)
  • Internal Unit Dimensions (WxHxD): 850x270x208 mm
  • Indoor Unit Weight: 8.5 Kg
  • Integrated Wi-Fi

3) Model:

  • Catalog number: 1 x AKT26UR4RK4
  • Typology : Console
  • Power: 9000 btu/h
  • Cooling/Heating Capacity: 2.95 /3.05 kW
  • Sound pressure level (min-max): 28-39 dB(A)
  • Internal Unit Dimensions (WxHxD): 700x630x220 mm
  • Indoor Unit Weight: 15.0 Kg
  • Standard remote control*

Outdoor Unit

Model:

  • Indoor Unit catalog code: 4AMW81U4RAA
  • Max indoor units: up to 4 indoor units

Energy efficiency:

  • SEER : 7.01 (W/W)
  • SCOP : 4.05 (W/W)
  • Energy Efficiency Class (Cooling) : A++
  • Energy Efficiency Class (Heating) : A+
  • Annual energy consumption Cooling/Heating : 399/2765 kWh/a

Performance:

  • Cooling Capacity: 8 kW
  • Heating Capacity: 9 kW
  • Std cooling absorption: 2.25 kW
  • Std heating absorption: 2.25 kW
  • Sound power level : 68 dB(A)
  • Sound pressure level : 54-60 dB(A)

Characteristics:

  • Power (V/Hz/Φ) : 220~240/50/1
  • Refrigerant gas : R-32
  • Pipe diameter Liquid : 6.35 mm (1/4") x4
  • Gas pipe diameter : 9.52 mm (3/8") x4
  • Guaranteed temperature range:
  • - Cooling: -15°~48°C
  • - Heating: -15°~24°C

Dimensions:

  • External Unit Dimensions (WxHxD): 950×840×340 mm
  • Weight of Outdoor Unit: 73 Kg

3 year warranty (5 on the compressor)

Warranty

The Hisense Italia warranty can be activated within 1 month from the date of purchase at the addresshttp://www.hisenseitalia.it/clima/supporto


Multisplit Line - Free Match

Free Match products are ideal where an indoor unit is required for each room, such as a living room and 3 bedrooms. The system allows you to combine up to 5 indoor units with a single outdoor unit. Indoor units can be of different types, including ducted, wall-mounted, cassette, and ceiling/floor.

DC drive technology with 180° sine wave

The system constantly monitors the compressor frequency and creates the most efficient waveform to determine effective fuel savings.

Compressor with rubidium magnet

Thanks to the greater compression of the gas molecules, the rubidium magnet compressor guarantees greater efficiency and lower absorption.

Electronic expansion valve

The outdoor unit uses an electronic expansion valve which regulates optimizes the refrigerant amount of all operating indoor units.

Operation with wide voltage range

The outdoor unit can work with voltage from 176V to 264V. In the new models, the use of an automatic voltage regulation technique ensures that the protection value adjusts according to it, keeping the operating frequency at an optimal value.

Exchanger design: designed to improve its efficiency

The design of the external exchanger has been designed to increase heat transfer in order to make the refrigeration circuit more efficient and avoid the creation of blocks of ice. Another advantage is that it can support long-distance connections between outdoor units and indoor units without reducing the cooling capacity.


Hisense New Comfort

New Comfort


5 Levels of fan speed

Velocità

The possibility of setting the fan speed at 5 different levels allows for more precise control of the volume of the air introduced and the noise level


Universal unit for mono and multi systems

Sistemi

The universal indoor units can be connected to Monosplit and Multisplit outdoor units to ensure maximum installation versatility


Easy installation

The New Comfort models are easy to install thanks to the new design of the indoor unit and the mounting plate.

1 . The mounting plate has two tabs that allow you to distance the indoor unit from the wall for more usable space while connecting the pipes

Easy Installation


2. The panel on the bottom of the indoor unit is easily removed to ensure convenient access to the piping

Easy Installation


3. You can choose the side to connect the drain pump according to your installation needs

Easy Installation


Characteristics

Caratteristiche


Hisense Console

Product image


Cooling down

The upper and lower airflows open simultaneously for fast and comfortable cooling.


Heating

The bottom airflow ensures uniform heating throughout the room.


Characteristics :

  • Air renewal
  • Upper and lower air delivery
  • Installation flexibility
  • Twin, Triple and Quadri applications
  • Automatic restart
  • ON/OFF contact
  • LED displays

Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Hisense Dual Split Console Air Conditioner 12 + 12 With 3amw62u4rjc R-32 Wi-Fi Optional Serial Remote Control Included 12000 + 12000

Product form

Technical features Indoor units 1) Model: Internal Unit Catalog Code: 1x TQ25XE0BG Series: Energy Power: 9000 btu/h Cooling/Heating Capacity: 2.6/3.0... Read more

€1.562,00 Incl. VAT

    Description

    Technical features

    Indoor units

    1) Model:

    • Internal Unit Catalog Code: 1x TQ25XE0BG
    • Series: Energy
    • Power: 9000 btu/h
    • Cooling/Heating Capacity: 2.6/3.0 kW
    • Air flow: 600 m 3 /h
    • Sound pressure level (min-max): 19-39 dB(A)
    • Internal Unit Dimensions (WxHxD): 850x270x208 mm
    • Indoor Unit Weight: 8.5 Kg
    • Integrated Wi-Fi

    2) Model:

    • Internal Unit Catalog Code: 1x TQ35XE0AG
    • Series: Energy
    • Power: 12000 btu/h
    • Cooling/Heating Capacity: 3.5/4.1 kW
    • Air flow: 620 m 3 /h
    • Sound pressure level (min-max): 19-29 dB(A)
    • Internal Unit Dimensions (WxHxD): 850x270x208 mm
    • Indoor Unit Weight: 8.5 Kg
    • Integrated Wi-Fi

    3) Model:

    • Catalog number: 1 x AKT26UR4RK4
    • Typology : Console
    • Power: 9000 btu/h
    • Cooling/Heating Capacity: 2.95 /3.05 kW
    • Sound pressure level (min-max): 28-39 dB(A)
    • Internal Unit Dimensions (WxHxD): 700x630x220 mm
    • Indoor Unit Weight: 15.0 Kg
    • Standard remote control*

    Outdoor Unit

    Model:

    • Indoor Unit catalog code: 4AMW81U4RAA
    • Max indoor units: up to 4 indoor units

    Energy efficiency:

    • SEER : 7.01 (W/W)
    • SCOP : 4.05 (W/W)
    • Energy Efficiency Class (Cooling) : A++
    • Energy Efficiency Class (Heating) : A+
    • Annual energy consumption Cooling/Heating : 399/2765 kWh/a

    Performance:

    • Cooling Capacity: 8 kW
    • Heating Capacity: 9 kW
    • Std cooling absorption: 2.25 kW
    • Std heating absorption: 2.25 kW
    • Sound power level : 68 dB(A)
    • Sound pressure level : 54-60 dB(A)

    Characteristics:

    • Power (V/Hz/Φ) : 220~240/50/1
    • Refrigerant gas : R-32
    • Pipe diameter Liquid : 6.35 mm (1/4") x4
    • Gas pipe diameter : 9.52 mm (3/8") x4
    • Guaranteed temperature range:
    • - Cooling: -15°~48°C
    • - Heating: -15°~24°C

    Dimensions:

    • External Unit Dimensions (WxHxD): 950×840×340 mm
    • Weight of Outdoor Unit: 73 Kg

    3 year warranty (5 on the compressor)

    Warranty

    The Hisense Italia warranty can be activated within 1 month from the date of purchase at the addresshttp://www.hisenseitalia.it/clima/supporto


    Multisplit Line - Free Match

    Free Match products are ideal where an indoor unit is required for each room, such as a living room and 3 bedrooms. The system allows you to combine up to 5 indoor units with a single outdoor unit. Indoor units can be of different types, including ducted, wall-mounted, cassette, and ceiling/floor.

    DC drive technology with 180° sine wave

    The system constantly monitors the compressor frequency and creates the most efficient waveform to determine effective fuel savings.

    Compressor with rubidium magnet

    Thanks to the greater compression of the gas molecules, the rubidium magnet compressor guarantees greater efficiency and lower absorption.

    Electronic expansion valve

    The outdoor unit uses an electronic expansion valve which regulates optimizes the refrigerant amount of all operating indoor units.

    Operation with wide voltage range

    The outdoor unit can work with voltage from 176V to 264V. In the new models, the use of an automatic voltage regulation technique ensures that the protection value adjusts according to it, keeping the operating frequency at an optimal value.

    Exchanger design: designed to improve its efficiency

    The design of the external exchanger has been designed to increase heat transfer in order to make the refrigeration circuit more efficient and avoid the creation of blocks of ice. Another advantage is that it can support long-distance connections between outdoor units and indoor units without reducing the cooling capacity.


    Hisense New Comfort

    New Comfort


    5 Levels of fan speed

    Velocità

    The possibility of setting the fan speed at 5 different levels allows for more precise control of the volume of the air introduced and the noise level


    Universal unit for mono and multi systems

    Sistemi

    The universal indoor units can be connected to Monosplit and Multisplit outdoor units to ensure maximum installation versatility


    Easy installation

    The New Comfort models are easy to install thanks to the new design of the indoor unit and the mounting plate.

    1 . The mounting plate has two tabs that allow you to distance the indoor unit from the wall for more usable space while connecting the pipes

    Easy Installation


    2. The panel on the bottom of the indoor unit is easily removed to ensure convenient access to the piping

    Easy Installation


    3. You can choose the side to connect the drain pump according to your installation needs

    Easy Installation


    Characteristics

    Caratteristiche


    Hisense Console

    Product image


    Cooling down

    The upper and lower airflows open simultaneously for fast and comfortable cooling.


    Heating

    The bottom airflow ensures uniform heating throughout the room.


    Characteristics :

    • Air renewal
    • Upper and lower air delivery
    • Installation flexibility
    • Twin, Triple and Quadri applications
    • Automatic restart
    • ON/OFF contact
    • LED displays

    Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    Data sheetData sheet
    • peso: 55.0 kg
    • classe energetica raffreddamento: A++
    • classe energetica riscaldamento: A+
    • gas: R-32
    • marca: Hisense
    • metri quadri : 35/35
    • modello: ACTS 12+12 62
    • potenza btu: 12000+12000
    • superficie riscaldabile mq: 35/35
