Technical Features
Internal Units
Model
- Internal Unit Catalog Code: 3x GWH12AAB-K6DNA4B/I
- Power: 12000 btu/h
- Cooling Capacity : 3.2 kW
- Heating capacity: 3.4 kW
- Treated Air: 320~590 m3 /h
- Sound Power Level : 38~56 dB(A)
- Sound pressure level : 26~41 dB(A)
- Liquid Pipe Diameter: 6.35mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Internal Unit Dimensions (HxWxD): 250x773x185 mm
- Internal Unit Weight: 8.0 Kg
- Wi-Fi Optional
Model:
- External Unit Catalog Code: GWHD(24)NK6OO
- Max indoor units: up to 3 indoor units
Energy Efficiency:
- SEER : 6.1
- SCOP : 4.0
- Energy Efficiency Class in Cooling: A++
- Energy Efficiency Class in Heating: A+
- Annual energy consumption in Cooling: 407 kWh/a
- Annual energy consumption in heating: 2189 kWh/a
Performance:
- Cooling capacity: 7.1 kW
- Heating capacity: 8.6 kW
- Cooling power consumption: 1.88 kW
- Heating absorption: 2.23 kW
- Sound power level: 68 dB(A)
- Sound pressure level: 58 dB(A)
Characteristics:
- Power supply (V/Hz/F) : 220~240/50/1
- Refrigerant gas: R-32
- Guaranteed temperature range:
- - Cooling: -15° ~ 43° C
- - Heating: -15° ~ 24° C
Installation Data:
- Liquid Tube Diameter: 6.35mm (1/4") x3
- Gas pipe diameter: 9.52 mm (3/8") x3
- Maximum pipe length: 30 m
- Maximum length of pipes with additional charge: 60 m
- Maximum height difference between internal units: 15 m
Dimensions:
- External Unit Dimensions (HxWxD): 654x889x340 mm
- External Unit Weight: 47.5 Kg
Gree Air Conditioners
Gree Bora Plus Elegant Design, Attention to Details
IFeel Function
Gree
air conditioners and heat pumps are equipped with sophisticated electronics that can provide high comfort. The IFeel function, linked to the presence of a temperature sensor on the remote control, allows you to have comfort in the desired place, that is, where the remote control is positioned.
The presence of flaps that can be automatically oriented both vertically and horizontally allows you to customize the air flow; the high number of ventilation speeds gives you a wide range of options for selecting the desired level. The Quiet function provides maximum silence, acting on both the ventilation speeds and the compressor frequency.
More or less sophisticated variants of the Sleep function meet the most varied comfort needs, even during sleep.
The programmable timer on 24h or, in the case of more advanced wired controls, weekly gives maximum flexibility in managing your comfort. The external unit battery is defrosted only if and when necessary, avoiding unnecessary stops in heating operation.
Turbo function
Press the “Turbo” button on the remote control to have a very strong jet of air, allowing you to reach the desired temperature in less time.
Intelligent Auto Restart
After a blackout, the unit automatically restarts when the power returns, maintaining the last settings
Low Startup Consumption (Soft Start)
Initial energy consumption is reduced to a minimum so as not to interfere with the use of other appliances.
Why Choose Gree Comfort? Gree is eco-friendly, uses R32 refrigerant , with low environmental impact.
The technology used by GREE air conditioners and heat pumps is GREEN, because it is renewable energy: it captures the thermal energy present in the air and transfers it from one place to another, multiplying it. The use of R32, a refrigerant gas with low impact on global warming, makes environmental comfort environmentally friendly: there is no impact on the ozone layer, the gas charge is 30% lower because R32 has a higher energy efficiency and the potential effect on global warming is reduced by 1/3 compared to the traditional refrigerant R410A
Gree Uses Latest Generation DC Inverter Technology and Saves You on Consumption
Inverter G10 is the Gree technology that allows you to modulate the power and speed of the compressor and fans of the air conditioner or heat pump based on the real comfort needs. As the room temperature approaches the set temperature, the compressor and fans reduce their speed and therefore energy consumption: this is why this technology helps to contain energy consumption
Gree gives you all the comfort you could wish for
GREE DC Inverter technology offers multiple advantages: rapid achievement of the desired temperature, precise temperature control, constant comfort, silence, control of electricity consumption
Flexible Matching
Outdoor units can be combined with all types of indoor units .
Operation up to low external temperatures
The ability to operate down to -15°C, both in cold -15°C and -15°C and in hot, guarantees high product reliability: when the external temperature varies, the compressor frequency and fan speed adjust accordingly.
Product Warranty: All products for sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.
