Technical features
Model:
- Catalog code: 3NDA5195
- Model: AIR R-32
- Typology: heat pump
Energy efficiency:
- SEER 6.50
- SCOP 4.0
- Cooling energy class A++
- Heating energy class A+
Performance:
- Cooling Capacity (kW): 6.8
- Heating Capacity (kW): 6.8
- Indoor unit sound pressure level High / Medium / Low dB(A) 54/51/48/40
- Max sound pressure level outdoor unit dB(A) 57
- Indoor unit fan flow rate Min / Max m3/h: 970/980
- Internal unit fan capacity Max m3/h: 3200
Electrical data:
- Power supply (V/Hz/Φ) : 230/50/1
- Heating Absorbed Power (kW): 2.05
- Absorbed Power Cooling (kW) : 1.98
Characteristics:
- Refrigerant gas : R32
- Pipe diameter Liquid / Gas: 6.35 / 15.88 mm
- Outdoor temperature range in cooling °C 15~43
- Outdoor temperature range in heating °C -15~24
Dimensions and weight:
- Indoor Unit LxHxP (mm): 1010 x 315 x 220 ; 13 Kgs
- Outdoor Unit LxHxP (mm): 845x; 31 Kgs
Daitsu
Inverter technology
Air conditioning is one of those things that make your life more comfortable. The goal is simple: maintain the perfect room temperature in your home at all times and worry-free. The innovative Inverter technology of Daitsu air conditioners guarantees correct energy consumption and maintenance of the desired temperature at any moment of the day. This results in lower costs, greater comfort, and the elimination of unnecessary noise. It also extends the life of the air conditioners.
Daitsu comes to meet you and the planet
One of the most important parts of an air conditioning system is the refrigerant gas that circulates within it. If we are to truly deliver on our commitments to the planet and our customers, we must work with the most innovative systems available. One of the clear responses to the demand for ever more environmentally friendly refrigerants is the introduction of the Daitsu AIR R32 range, which uses the new R32 refrigerant. With this we obtain many advantages:
Reduction of energy consumption by 50%
Daitsu Inverter air conditioners offer exceptional energy savings. Daitsu equipment compressors, after quickly reaching the desired temperature, operate at minimum power significantly reducing energy consumption. Thanks to this efficient operation with a Daitsu Inverter system, it is possible to obtain savings of up to 50% compared to traditional systems, as continuous interruptions and starts of the equipment are avoided.
AIR R32
The new Daitsu range features a new elegant and compact design with soft lines that can be integrated into any environment. Daitsu with the new R32 ecological refrigerant gas offers an excellent balance between the level of comfort and energy savings.
New Design
A totally renewed range of air conditioners with R32 freon gas and with a more elegant design, modern and soft lines that adapt to any type of environment. The front panel backlit with LEDs (low consumption) displays the temperature and the selected functions. The new design has been used throughout the Daitsu Air R32 range.
Energy saving
In compliance with European regulations, all Daitsu air conditioners have an A ++ / A + energy classification, thus guaranteeing maximum savings and maximum efficiency.
TFIAC Smart
The TFIAC acsmart Application for Daitsu Smartphones and Tablets (optional code 3NDA9046) controls the internal units of Daitsu air conditioners and allows you to access them from anywhere in the world.
Main features
-
Automatic management The climate control system intelligently analyzes the selected temperature and fan speed. Once the appropriate comfort level has been reached, the frequency and power of the fan will be automatically adjusted.
-
Weekly timer Daitsu air conditioners are managed using the weekly timer control. They turn on and off as per the settings entered.
-
Operating speed control: It is possible to control the 4 speeds of the air conditioner
-
Operating mode management The system allows you to establish standard operating modes for situations typical of our daily life.
-
Wi Fi (Optional): this is the function that allows quick management and control, by connecting the air conditioner to the home's WLAN network, allowing you to manage the functions comfortably using your Smartphone or Tablet even when you are not at home
Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
