Technical features
Indoor Units
Model:
- Indoor unit catalog number: 3x FDXM25F9
- Power : 9000 Btu
- Cooling Capacity : 2.4 kW
- Heating Capacity : 3.2 kW
- Treated Air: 8.0 m 3 /min
- Sound Power Level Indoor Unit : 53 dB(A)
- Sound pressure level : 27~35 dB(A)
- Pipe diameter Liquid : 6.35 mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Internal Unit Dimensions (HxWxD): 200x750x620 mm
- Indoor Unit Weight: 21 Kg
Optional Commands:
- Wi-Fi card : BRP069A81
- White Wire Command: BRC1H519W
- Modoka Silver Wire Control : BRC1H519S
- Black Modoka Wire Control : BRC1H519K
- Infrared remote control : BRC4C65
Outdoor Unit
Model:
- Catalog number : 3MXM68N(9)
- Maximum number of combinable indoor units: 3
Energy efficiency:
- SEER: 7.76
- SCOP: 4.09
- Energy Efficiency Class in Cooling : A+++
- Heating Energy Efficiency Class: A++
Performance:
- Cooling Capacity: 6.80 kW
- Heating Capacity: 8.60 kW
- Absorbed power Cooling: 1.63 kW
- Absorbed power Heating: 1.83 kW
- Sound power level Cooling : 61 dB(A)
- Sound power level Heating : 61 dB(A)
Characteristics:
- Power (V/Hz/Φ) : 220~240/50/1
- Refrigerant gas : R-32
- Guaranteed temperature range:
- - Cooling: -10° ~ 46°C
- - Heating: -15° ~ 18° C
Installation data:
- Pipe diameter Liquid : 6.35 mm (1/4") 3x
- Gas pipe diameter: 9.52 mm (3/8") 3x
- Maximum piping length: 50 m
- Maximum difference in height indoor unit / outdoor unit: 15 m
Dimensions and weight:
- External Unit Dimensions (HxWxD): 734x958x384 mm
- Weight of Outdoor Unit: 62.0 kg
Multisplit systems Superior efficiency
The range of new Multisplit includes 8 outdoor units from 2 to 5 connections, with power from 4 to 9 kW, which can be combined with Daikin indoor units. Designed with energy-efficient refrigerants and compressors that ensure optimal performance, all multi-split units allow you to cut consumption by up to 80%. All Bluevolution multis are in class A+++/A++.
All in even more compact dimensions. Compared to the previous range, significant improvements have also been achieved in terms of silence .
Up to five indoor units can be connected to one multi outdoor unit. The ideal solution to meet the needs of those who want to heat and cool several rooms
" Daikin Bluevolution redefines market standards for efficiency, silence, pure air and consumption control , with particular attention to environmental impact. "
Discover the well-being of the future
Those who choose Daikin for their home simply choose the best. Today, Daikin has taken the concept of comfort to a whole new level, reinventing the environment with its Bluevolution range . By choosing Daikin technologies, you can have maximum efficiency, silence and pure air. The high levels of seasonal efficiency guarantee the best atmosphere both in summer and in winter, minimizing consumption. The new R-32 refrigerant is more environmentally friendly than standard refrigerants. Daikin's vast experience and the wide range of products offered are synonymous with reliability and long-lasting systems, perfect for your home. And even when you are not at home, you can control and regulate the temperature in the rooms and the operating mode via an easy-to-use smartphone app. Let Daikin guide you to create the perfect atmosphere.
Is your air conditioner more than 10/15 years old?
Discover the advantages of replacing it with a new Daikin Bluevolution. Here are the main benefits:
-
Consumption halved by saving on energy costs. In doing so, you are good for the environment and for your wallet
-
Absolute silence with a product 10 decibels less noisy, practically imperceptible: to sleep, listen to music and study without any disturbance
-
4-year warranty Daikin Kizuna's 2-year free warranty extension will be reserved for the new BLUEVOLUTION residential range.
-
Pure air thanks to the patented Flash Streamer TM system, to remove dust, pollen, mites, mold and many other allergens; even bad smells, viruses and bacteria
-
New design with products designed so that the air conditioner becomes a piece of furniture.
Why Choose Daikin?
- Seasonal efficiency in heating and cooling
Creating a pleasant climate in your home is not just a matter of comfort. Daikin systems are also kind to the environment and your wallet. Daikin's advanced energy saving technologies guarantee high levels of seasonal efficiency in both heating and cooling, up to class A+++ . Consider that a class A+++ product is up to 40% more efficient than a class A++ product. Seasonal efficiency is a new way of rating heating and cooling products based on their energy efficiency over the year.
- R-32 More Efficiency and Eco-Friendly
Daikin uses R-32, a refrigerant which results in lower CO 2 emissions. This means that the units have a lower global warming potential and are generally more efficient. For the benefit of the environment!
Noisy units are now a thing of the past. Daikin systems are so quiet that they are inaudible. You can read, study and sleep without any background noise.
Thanks to Daikin's Onecta App the problem is solved. You can adjust the internal temperature, the air flow and the operating mode from your device, when and where you want. In addition, you will be able to keep energy consumption under control, managing your climate responsibly.
Daikin Ducted FDXM-F
It redefines market standards for efficiency, silence, pure air and consumption control, with particular attention to environmental impact .
" Daikin BLUEVOLUTION redefines market standards for efficiency, silence, pure air and consumption control , with particular attention to environmental impact. "
Discover the well-being of the future
Those who choose Daikin for their home simply choose the best. Today, Daikin has taken the concept of comfort to a whole new level, reinventing the environment with its Bluevolution range . By choosing Daikin technologies, you can have maximum efficiency, silence and pure air. The high levels of seasonal efficiency guarantee the best atmosphere both in summer and in winter, minimizing consumption. The new R-32 refrigerant is more environmentally friendly than standard refrigerants. Daikin's vast experience and the wide range of products offered are synonymous with reliability and long-lasting systems, perfect for your home. And even when you are not at home, you can control and regulate the temperature in the rooms and the operating mode via an easy-to-use smartphone app. Let Daikin guide you to create the perfect atmosphere.
Take a deep breath of Pure Air
A large choice
Daikin solutions are elegant, silent and efficient. For one or more rooms, Daikin has the right unit for you.
Why Choose Daikin?
The Daikin Bluevolution series offers the best in comfort and fresh air, design and performance. Whether you want to heat or cool one or more rooms, whether you prefer wall-mounted or concealed ceiling units, Daikin has the right solution for you.
Ductable unit
FDXM-F is a compact concealed ceiling unit, with a height of only 200mm
Silent installation
Once installed, FDXM-F is invisible as it is recessed into the false ceiling. Only the suction and discharge grilles are visible.
24 hour timer
It can be set to start the unit at any time in any 24 hour period
Simplified maintenance
The self-cleaning filter guarantees air quality, greater operating efficiency and lower maintenance costs
Onecta App Full control, wherever you are
Are not you at home? Thanks to the Onecta app, this isn't a problem. The app allows instant access to all functions. You can easily adjust Daikin Emura settings via smartphone, anywhere, anytime.
- Check all the functions of your Daikin Emura air conditioner
- Create different schedules and operating modes
- Monitor energy usage on a daily, weekly or yearly basis
- Identify the room in your home to easily control the different units
Simply connect to the WLAN network and download the Onecta app to start creating the perfect climate for your home
The Onecta app allows you to connect Daikin to the Wi-Fi network and control the air conditioning system from anywhere, using Apple or Android devices. Even when you're not at home, you can turn it on and off, set cooling or heating operation , adjust the room temperature and the air flow of the air conditioner. It's that simple
Voice Control
To further increase comfort and convenience, the app Daikin Onecta - Residential Controller it is now available with voice control. The ability to control the application hands-free cuts down on necessary clicks and allows for faster drive management than ever before. Transversal and multilingual, the voice control can be combined with smart speakers, such as Google Assistant And Amazon Alexa
Unit Always Connected
The unit can be managed via the new Daikin Onecta App - Residential Controller and compatible with Amazon Alexa and Google Home voice assistants. The Wi-Fi connection is guaranteed thanks to the SD card integrated in the unit
Programming
Set up a schedule to define system operating times, and create up to six different actions per day
Program the room temperature and operating mode
Enable vacation mode to save on energy costs
Monitoring
Get a complete overview of system performance and energy consumption
Check system status
Access energy consumption graphs (daily, weekly, monthly)
Check
Customize the system to fit your lifestyle and year-round comfort needs
Change the ambient temperature
Turn on Powerful mode to boost operation
Feature availability depends on system type, configuration, and mode of operation. The app features are only available if both the Daikin system and the app use a reliable internet connection
Product guarantee: All products for sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.
