Technical features
Model:
- Indoor unit catalog code: FCAG50B
- Outdoor unit catalog number: RZAG50A
- Standard grid code : BYCQ140E
- Power : 18000 Btu
- Optional Wi-Fi Card (Code BRP069B82 )
- Optional infrared remote control ( Code BRC7FA532F )
- Optional White Madoka Wire Control ( Code BRC1H519W )
- Optional Madoka Silver Wire Command ( Code BRC1H519S )
- Optional Madoka Black Wire Command ( Code BRC1H519K )
Energy efficiency
- SEER: 6.80
- SCOP : 4.30
- Energy Efficiency Class in Cooling : A++
- Heating Energy Efficiency Class: A+
Performance
- Cooling Capacity: 5.0 kW
- Heating Capacity: 5.8 kW
- Internal Unit air flow: 10.7 m 3 /min
- Sound Power Level Indoor Unit : 51 dB(A)
- External Unit Sound Power Level: 63 dB(A)
- Sound Pressure Level Indoor Unit : 28~35 dB(A)
- Sound Pressure Level Outdoor Unit: 49 dB(A)
Characteristics:
- Power (V/Hz/Φ) : 220~240/50/1
- Refrigerant gas : R-32
- Operating range
- - Cooling: -20° ~ 52°C
- - Heating: -20° ~ 24° C
Installation data
- Pipe diameter Liquid : 6.35 mm (1/4")
- Gas pipe diameter: 12.70 mm (1/2")
- Maximum piping length: 50 m
- Maximum height difference Indoor Unit / Outdoor Unit: 30 m
Dimensions and weight
- Internal Unit Dimensions (HxWxD): 204x840x840 mm
- Indoor Unit Weight: 19 Kg
- External Unit Dimensions (HxWxD): 734x870x373 mm
- Weight of Outdoor Unit: 52 Kg
- Grid dimensions (HxWxD): 50x950x950 mm
- Grid Weight: 5.4 Kg
Why choose SkyAir A-series The better the control, the greater the comfort
› Intuitive control via Residential Controller App
› Variable coolant temperature for optimal comfort
› Personalization according to the needs of its customers
At the heart of the system
› Equipped with exclusive Daikin technologies, tested and reliable
› Low environmental impact, the GWP value of R32 refrigerant is 68% lower than that of R410A
Flexibility in design
› More compact
> Quieter
› Extended operating range in all climatic conditions
Thought for you
› Faster and easier installation and use
› Quick and reliable replacement
R32 is the future. Join us!
› R32 is more eco-friendly than previously used refrigerants
› Daikin is the market leader and has been driving technological innovation for years
› First complete range on the market with R32 for small commercial applications
The new Sky Air A series range is ideal for any small-commercial application
Lighter and more compact units for simple on-site installation. Special range with single fans up to 14 kW
New replacement technology
A faster, easier and more reliable approach when replacing old outdated systems
› Reduction of any inconvenience and obtaining a system capable of significantly reducing consumption and energy bills
› Hepta filtration able to ensure reliable operation without having to clean the pipes
› Cost and time effective solution, as it is sufficient to replace the indoor and outdoor units without modifying the piping
Advantages
› Piping length increased up to 85 m
› Widest operating range : Cooling mode from -20°C to 52°C , heating mode down to -20°C
› Full range of indoor units available with R32 : More than 45 different options for indoor units
› Faster installation with pre-charged pipes up to 40m : 60% of applications can be installed without additional refrigerant charge
› Swiveling front panel : new design for easy access to system components
› New 7-segment display : To view any errors and system settings
› Reliability : guaranteed in all climatic conditions, to reduce requests for on-site assistance
› New refrigerant passages : The bottom of the outdoor unit heat exchanger and drain holes are left completely open, allowing chilled water to flow freely, eliminating the risk of ice buildup
› Refrigerant-cooled PCBs : Stable and reliable cooling, regardless of external conditions
› Integrated leak check function : for maximum reliability and minimum on-site checks
Daikin Cassette Round Flow
Daikin Italy , the Italian branch of the Japanese multinational world leader in air conditioning and heating systems, as well as for the entire cold chain in the field of refrigeration, announces the new Cassetta Round Flow , recognized as the most efficient on the market thanks to the technology of avant-garde and excellent design that sets it apart.
To develop the new Cassette Round Flow, Daikin started from a research that revealed the three most important aspects for users: the small size , the level of comfort and the aesthetics .
Compact and attractive design
In response to customer needs, the new panel expresses elegance and high technology; it is essential in appearance and easily adapts to any type of furniture. The air intake grilles are invisible and give it a very refined look.
With a height of 204 mm , the new Daikin Round Flow Cassette is the most compact available on the market and offers greater design flexibility to adapt to the environment and to different structural constraints
The greatest possible comfort
Starting from the proven design of the Round Flow cistern, Daikin has applied a new technology, increasing the comfort that can be obtained in a room and energy efficiency.
Its important 360° air jet and smart sensors guarantee homogeneous temperatures and air distribution in every point of the room (working only when necessary and thus avoiding energy waste). Thanks to the new wider deflectors and the Coanda effect, the air flow is in fact more uniform.
The individual control and/or locking via wired remote control allows for the customization of the device which thus manages to adapt to the specific configurations of the environment.
The new Active Circulation Air Flow logic was then added. Activated when the device is started, this new function allows you to reach the set temperature as quickly and efficiently as possible. The Air Flow in Active Circulation also allows for faster start-up and energy savings of 5% in cooling mode and up to 15% in heating mode
The Round Flow Cassette, with a 360° air jet, offers the best comfort available on the market and increases efficiency up to 50% thanks to the self-cleaning technology.
Intelligent technologies for a comfortable climate
The 360° air jet of the Daikin Round Flow Casstta eliminates the problem of cold air currents or uneven air distribution. The Intelligent Eye sensor detects the presence of people and directs the air away from them, while the floor sensors ensure a homogeneous temperature from floor to ceiling.
Daikin's Round Flow cassette, with 23 possible airflow configurations , can adapt to any room layout. The remote control, adjustable flaps and optional enclosure kit help create 2, 3 or 4-way configurations that allow for installation in corners, close to walls or in irregularly shaped rooms . This feature is particularly useful when rearranging rooms as it allows you to change the airflow without moving the unit .
Greater energy efficiency increases savings
The Daikin Round Flow Cassette is equipped with the exclusive self-cleaning filter panel that reduces maintenance costs and increases savings thanks to energy efficiency up to 50% higher than normal cassettes. The intelligent eye sensor automatically switches the cassette into energy saving mode or turns it off when it doesn't detect people in the environment, reducing energy costs by up to 27% .
Ease of maintenance
Daikin's self-cleaning Round Flow Cassette features the unique self-cleaning filter panel, which reduces maintenance time and associated costs. Furthermore, an always clean filter improves energy efficiency by up to 50% compared to normal cassettes, guaranteeing considerable savings. The Intelligent Eye sensor detects the presence of people and directs the air away from them, as well as reducing energy costs by 27% when it automatically switches to energy saving mode or switches off the unit when there are no people in the room.
Forget the ladders and the cleaning technician – all you have to do to get the dust out of the collection box is connect it to a regular vacuum cleaner.
Voice Control
The Daikin Residential Controller application is designed for those who live a busy life and want to manage their system via smartphone. To further increase comfort and convenience, the Daikin Residential Controller app is now available with voice control. The ability to control the application hands-free cuts down on necessary clicks and allows for faster drive management than ever before. Transversal and multilingual, voice control can be combined with smart speakers, such as Google Assistant and Amazon Alexa
Unit Always Connected
The unit can be managed via the new Daikin Residential Controller App and compatible with Amazon Alexa and Google Home voice assistants. The Wi-Fi connection is guaranteed thanks to the SD card integrated in the unit
Programming
Set up a schedule to define system operating times, and create up to six different actions per day
Program the room temperature and operating mode
Enable vacation mode to save on energy costs
Monitoring
Get a complete overview of system performance and energy consumption
Check system status
Access energy consumption graphs (daily, weekly, monthly)
Check
Customize the system to fit your lifestyle and year-round comfort needs
Change the ambient temperature
Turn on Powerful mode to boost operation
Feature availability depends on system type, configuration, and mode of operation. The app features are only available if both the Daikin system and the app use a reliable internet connection
Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
