Technical features
Model:
System code CS-25V3G-1C173AY4A
Indoor unit part number CS-25V3G-1C173FA
Outdoor unit code CS-25V3G-Y4A
Energy efficiency:
Seasonal efficiency:
SEER: 6.6
SCOP: 4.1
Energy Efficiency Class (Cooling) : A++
Energy Efficiency Class (Heating) : A+
Seasonal energy consumption (cooling / heating) kWh/year; 143-875
Performance:
Air flow IU 500/430/360 m³/h
Dehumidification l/h 0.9
Power output COOL. rated kW 2.5
RISC output power nom kW 2.5
COOL absorbed power. rated kW 0.67
HEATING absorbed power. rated kW 0.66
Sound Power IU dB: 38~47
Sound Pressure IU dB 28~37
EU sound power (a.): 63
Electrical data:
Power supply (V/Hz/Φ) : 230/1/50
Characteristics:
Refrigerant gas : R-32
Liquid / gas pipes: 1/4" / 3/8"
Maximum height difference (outdoor unit above) m 10
Maximum length of the pipes 20 m
Operating limits
Temperature of use in cooling min -15 max 46 °C
Temperature of use in heating min -15 max 34 °C
Dimensions and weight:
Dimensions Indoor unit WxHxD 780×276×202 mm; 27kg
Dimensions Outdoor unit WxHxD 715×235×540 mm; 25kg
General characteristics
AMBER
Functions:
Anti-mold: this is the function that prevents mold from accumulating in the internal unit, automatically starting sanitization cycles.
Auto Defrost: this is the function that protects the compressor, allowing correct operation even at the most extreme temperatures, always guaranteeing high performance;
Sleep: this is the function that automatically adjusts the temperature during the night;
StandBy 0.5: this is the function that allows useless waste once the desired temperature has been reached;
Timer ON/OF: this is the function that allows you to regulate switching on and off;
3D air flow: it is the function that allows the air flow to be diffused in all directions, to reach every corner;
Follow Me: this is the function that allows you to reach the desired temperature in the shortest possible time;
Quiet: this is the function that reduces the noise level of the climate control system;
Eco: this is the function that reduces energy consumption;
Heat/Cool: this is the function that allows the Cooling and Heating modes;
Advantages:
R32 ecological gas
Quick installation
High Efficiency Compressor
Activated carbon filter
Golden Fin treatment of the outdoor unit
Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
