Baxi Kit Hybrid Auriga Hybrid Kit A7785512 For Condensing Boilers And Heat Pumps

Description

Baxi Kit Hybrid Auriga hybrid kit A7785512 for condensing boilers and heat pumps

Technical features

  • Heating circuit max pressure 3 bar
  • hybrid module capacity l 1
  • Heating/cooling circuit temperature range 25-80/7-30 °C
  • Nominal electric power W 80
  • Dimensions hxwxd 180x450x330
  • Power supply VHz 230-50
  • Degree of protection IPX5D

BAXI HYBRID KITS

The Hybrid Auriga kit is the ideal Baxi accessory to promote the energy requalification of existing heating and DHW production systems.

The Hybrid Auriga kit combined with a condensing boiler (various ranges) and an Auriga monobloc heat pump creates a Factory made hybrid system which, in view of the 110% Superbonus, allows the efficiency of the system to be improved by at least 2 energy classes. building and furthermore, allows for significant savings in future management costs.

  • Compact dimensions: only 180 mm high (210 mm with Luna Duo-tec E bottom lock extension kit)

  • No relocation of hydraulic fittings required

  • Magnetic dirt separator filter supplied as standard

  • External probe supplied as standard

  • Can be combined with boilers from the Luna Duo-tec E range (1.12, 1.24, 1.28, 24, 28, 33)

  • Can be combined with Auriga inverter packaged air-water heat pumps (4M-A, 6M-A, 8M-A,10M-A, 12M-A and 12T-A)

  • Remote digital control panel with backlit color LCD display supplied as standard

  • High head circulation pump for secondary circuit


Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Baxi Kit Hybrid Auriga Hybrid Kit A7785512 For Condensing Boilers And Heat Pumps

Product form

Baxi Kit Hybrid Auriga hybrid kit A7785512 for condensing boilers and heat pumps Technical features Heating circuit max pressure 3... Read more

€1.340,00 Incl. VAT

    Description

    Baxi Kit Hybrid Auriga hybrid kit A7785512 for condensing boilers and heat pumps

    Technical features

    • Heating circuit max pressure 3 bar
    • hybrid module capacity l 1
    • Heating/cooling circuit temperature range 25-80/7-30 °C
    • Nominal electric power W 80
    • Dimensions hxwxd 180x450x330
    • Power supply VHz 230-50
    • Degree of protection IPX5D

    BAXI HYBRID KITS

    The Hybrid Auriga kit is the ideal Baxi accessory to promote the energy requalification of existing heating and DHW production systems.

    The Hybrid Auriga kit combined with a condensing boiler (various ranges) and an Auriga monobloc heat pump creates a Factory made hybrid system which, in view of the 110% Superbonus, allows the efficiency of the system to be improved by at least 2 energy classes. building and furthermore, allows for significant savings in future management costs.

    • Compact dimensions: only 180 mm high (210 mm with Luna Duo-tec E bottom lock extension kit)

    • No relocation of hydraulic fittings required

    • Magnetic dirt separator filter supplied as standard

    • External probe supplied as standard

    • Can be combined with boilers from the Luna Duo-tec E range (1.12, 1.24, 1.28, 24, 28, 33)

    • Can be combined with Auriga inverter packaged air-water heat pumps (4M-A, 6M-A, 8M-A,10M-A, 12M-A and 12T-A)

    • Remote digital control panel with backlit color LCD display supplied as standard

    • High head circulation pump for secondary circuit


    Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    Data sheetData sheet
    • peso: 40.0 kg
    • alimentazione: Single phase
    • marca: BAXI
    • modello: A7785512
