- Pipe diameter Liquid : 6.35 mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Maximum piping length: 25 m
- Maximum height difference Indoor Unit / Outdoor Unit: 10 m
Dimensions and weight
- Internal Unit Dimensions (WxHxD): 777×250×201 mm
- Indoor Unit Weight: 8 Kg
- External Unit Dimensions (WxHxD): 765×310×481 mm
- Weight of Outdoor Unit: 24 Kg
4Xe White air conditioning Functions and Performance
> Wi-Fi Function Ready The indoor units are set up for Wi-Fi operation
> Inverter Technology for maximum compressor driving efficiency
> Sleep function Night-time operation program for better comfort
> Auto Swing Automatic swing movement of the flaps
> Turbo function Function that allows the fan to increase speed to reduce cooling/heating times
> Ventilation function room ventilation function only
> Golden Fin Anti-corrosion treatment carried out on the external/internal heat exchanger
> Auto Defrosting Function that allows the outdoor unit to proceed with defrosting cycles in the event of ice formation
> Automatic Leak Detection Automated internal gas pressure control system
> Silver ion filter
> Dehumidifier Function that allows you to reduce the degree of humidity in the environment
> Heat pump System that transfers the heat that is removed from the outside air and transferred inside the room
> Double Drain Bi-directional indoor unit drain pan
> 8°C control When the internal temperature reaches 8°C, the air conditioner heats the room automatically
> 3D synchronized movement of horizontal and vertical deflectors
> ECO function which minimizes electricity consumption
> Timer function that allows timed switching on and off
> Self Cleaning Particular ventilation cycle that allows you to sanitize the internal part of the wall-mounted models, limiting the emission of bad smells when restarting
> Self-Diagnosis Monitoring system which allows diagnosing any malfunctions and displaying the relative error codes
> Auto function based on the set temperature, the air conditioner determines the most appropriate operating mode
> Display dimming Display with dimming option for night-time operation
> Anti Cold Air Function which does not allow cold air to escape from the indoor units that have just been switched on in heat pump mode
> Follow Me The temperature is detected by a sensor located in the remote control
> Gentle Cooling the flow of air, through the passage in micro-holes, is diffused in a delicate and more distributed way
> Backlit Display The display remains hidden behind the front panel of the indoor unit
> Standard remote control Standard remote control
> System with particular attention to environmental sustainability, it uses the new R32 gas with a low pollution coefficient.
