Chiller heat pumps

Our chiller heat pumps are the innovative energy solution for efficient heating and cooling of spaces. Take a look and discover the benefits today!

227 products


  • immagine-1-bosch-pompa-di-calore-splittata-aria-acqua-reversibile-bosch-csh-3000i-aw-6-ors-da-6-kw-r-40-unita-interna-murale-codice-7735252262

    Bosch Bosch Csh 3000i Aw 6 Ors Reversible Air-Water Split Heat Pump From 6 Kw R-40 + Internal Wall Unit Code 7735252262

    IN CASE OF NO IMMEDIATE AVAILABILITY, THE PRODUCT WILL BE ORDERED AND SHIPPED IN 10 WORKING DAYS. Technical features Model : CSH3000iAW 6 ORS Indoor unit code: 8732940817 Outdoor unit code: 8738206020 Product code : 7735252262 Optional commands Modulating thermostat CR10 Energy efficiency Average climate energy efficiency class: A+ Annual energy consumption average climate : 3532 kW Performance Heating Nominal thermal power with air 7° C and water 35° C: 8.61 kW Maximum thermal power with air 7° C and water 35° C: 8.61 kW Cooling down Nominal thermal power with air at 35° C and water at 18° C: 6.87 kW Maximum thermal power with air at 35° C and water at 18° C: 8.85 kW Performance Sound pressure : 52 dB(A) Sound power : 62 ~ 65 dB(A) Maximum flow temperature of the heat pump in heating / DHW production: 55° C Minimum heat pump delivery temperature in cooling mode: 7° C Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R-410 Operating range - Cooling: 15° ~ 45° C - Heating: -20° ~ 35° C Dimensions and weight Dimensions (WxHxD): 950x834x390 mm Weight : 212Kg Bosch heat pump with innovative wall mounted indoor unit that combines efficiency and flexibility to adapt to any need Guaranteed energy savings Guaranteed energy savings thanks to the high performance of the heat pump both in winter and in summer Maximize savings The regulation of the heat pump in hybrid systems is able to establish which is the most advantageous energy source through real-time measurements, in order to maximize economic savings Wide range of powers This heat pump offers a wide range of powers to satisfy every need, with seven power sizes from 5 kW to 15 kW with single-phase and three-phase power supply Advantages ✓ Maximum protection against freezing of the connection between indoor and outdoor units thanks to the split refrigerant circuit pre-charged with R410 refrigerant fluid ✓ Management of up to 4 heating and/or cooling circuits Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €4.225,00

  • immagine-1-panasonic-pompa-di-calore-monoblocco-panasonic-aquarea-t-cap-12-kw-wh-mxc12j6e5-r-32-wi-fi-optional-aa-con-comando-incluso

    Panasonic Panasonic Aquarea T-Cap Monoblock Heat Pump 12 Kw Wh-Mxc12j6e5 R-32 Wi-Fi Optional A++/A++ With Command Included

    MANDATORY CONFIGURATION AND START-UP PIT-A2W-START UP NOT INCLUDED! Technical features Catalog number WH-MXC12J6E5 Command Included Wi-Fi Optional : CZ-TAW1 Energy efficiency Energy Efficiency Class at medium temperatures: A++ Energy Efficiency Class at low temperatures: A++ Performance Cooling Capacity: 12.0 kW Heating Capacity: 12.0 kW Sound power level : 65 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R-32 Operating range - Cooling: -20° ~ 35°C - Heating: 10° ~ 43° C Installation data Plumbing pipe diameter: 1 mm (1/4") Dimensions and weight Dimensions (HxWxD): 1410x1283x320 mm Empty weight: 140 Kg Aquarea Heat Pumps Efficiency at the highest levels Panasonic introduces an innovative low energy consumption system based on air to water heat pump technology. Aquarea heats your home effectively and efficiently, even in extreme outside temperatures. Aquarea can refresh spaces even in summer and bring hot water all year round. Aquarea High Performance is the range for new installations and low consumption homes. Exceptional efficiency and energy savings with low CO 2 emissions and minimal space. The Monobloc system has only one outdoor unit. The system does not require a refrigerated connection and is only connected to heating and / or hot water A heat pump converts heat energy outdoors into heat indoors With Aquarea, 80% of the thermal energy required is taken from the environment. Aquarea, through the heat exchange with the external air and the refrigerant gas contained in it, is able to heat/cool the water by conveying it to the domestic air conditioning system and satisfies all the needs for the production of domestic hot water 3 good reasons why Aquarea is the ideal solution for your home Wide range suitable for all homes Aquarea is an innovative system with low energy consumption, designed to provide ideal temperatures and domestic hot water, even with extreme outside temperatures. It is highly reliable thanks to the quality of all components, including the compressor, developed and manufactured by Panasonic. With the possibility to choose between multiple units, Aquarea ensures a very wide range availability to ensure the most appropriate choice for your home, regardless of size Heat pump, 80% energy at no cost Based on air-to-water heat pump technology, Aquarea is highly efficient and environmentally friendly. It captures the thermal energy present in the air and transfers it to heat the water needed for heating your home, for domestic hot water and even to cool your home if you wish. In this way, up to 80% of the required thermal energy is taken from the ambient air, even at extremely low temperatures Helps you save Save up to €1,100 a year compared to conventional electric heating. While the initial investment may be higher than with other technologies, the cost of ownership is much lower, with a reduced initial cost payback period. The savings are significant, particularly when compared to oil fired electric boilers and heaters Aquarea with R32 Refrigerant The detail that makes the difference Panasonic recommends R32 refrigerant as it is environmentally friendly. Unlike R22 and R410A gases, R32 refrigerant has a low potential impact on the ozone layer and global warming. Panasonic has introduced R32 models to align with all European countries that have adopted the Montreal Protocol to protect the ozone layer and prevent global warming Innovative installation Extremely easy to install. (Make sure the pressure gauge and vacuum pump are compatible with R32). This refrigerant is 100% pure, making it easier to recycle and reuse Environmental innovation Zero impact on the ozone layer. Reduced impact on global warming by 75% Economic and energy consumption innovation Lower costs and higher savings. Higher efficiency than R410A gas Aquarea Service Cloud. Check anytime, anywhere Aquarea Smart Cloud is a powerful, intuitive and free service designed to help you remotely control Aquarea heat pumps from anywhere, 24/7 The advanced control is an intelligent, sophisticated and effective service to fully manage the Aquarea range in the heating, cooling and domestic hot water functions inside the house, including the monitoring of domestic energy consumption via smartphone, tablet or mobile device Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €6.045,00

  • immagine-1-lg-pompa-di-calore-mini-chiller-inverter-lg-therma-v-monoblocco-7-kw-hm071mr.u44-monofase-r-32

    LG Heat Pump Mini Chiller Inverter Lg Therma V Monoblock 7 Kw Hm071mr.U44 Single Phase R-32

    NON-OBLIGATORY PAID IGNITION BY THE SERVICE CENTER Technical features Product code : HM071MR U44 Water pump : Grundfos UPM3K 20-75 CHBL Energy efficiency EER: 4.5 SCOP : 4.7 Heating Energy Efficiency Class: A+++ Performance Cooling Capacity: 7.0 kW Heating Capacity: 7.0 kW Nominal flow rate : 1206 l/h Sound power level : 57 dB(A) Sound pressure level : 35 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Operational Limits Air Heating : -25° ~ 35° C Cooling : 5° ~ 48° C Operating Limits Water Heating : 15° ~ 65° C Cooling : 5° ~ 27° C DHW : 15° ~ 80° C Installation data Hydraulic Pipe Diameter Inlet: 25.4 mm (1") Male Hydraulic piping diameter Exit : 25.4 mm (1") Male Dimensions and weight External Unit Dimensions (WxHxD): 1239x834x330 mm Weight of Outdoor Unit: 89.0 Kg LG Heat Pumps Therma V Line LG offers a wide range of highly efficient renewable energy systems and provides the ideal solution for every application and requirement What is THERMA V ? THERMA V is LG's new air-to-water heat pump system, designed for new homes and renovations with the most advanced energy-saving heating technologies. THERMA V is the ideal solution for heating, cooling and the production of domestic hot water in domestic environments. The most complete and efficient solution for your home THERMA V offers the best solution for domestic heating and for the supply of domestic hot water. Thanks to LG's inverter technology, THERMA V systems are up to 4 times more efficient than traditional boilers Applications : Fan Coil Radiators Radiant floor Hot water Why Choose LG THERMA ? LG THERMA V is designed to provide the user with energy saving, comfort, simplified control and support services, thanks to the application of advanced LG technologies. LG's Inverter technology provides high energy efficiency, achievable with the use of components such as circulation pump, heat exchanger and fan motor completely designed and manufactured by the company Furthermore, the pressure control technology allows a stable and reliable heating capacity even at low temperatures and the achievement of the performance target effectively The new packaged units, thanks to the corrosion-resistant Ocean Black Fin treatment and user-friendly control with the new RS3 command, meet the needs of both professionals and end users High performance High energy efficiency SCOP 4.45 A+++ Maximum performance at low temperatures Operating range down to -25°C Water delivery temperature 65°C up to -5° C Low noise level Innovative vapor injection scroll compressor User benefits New user-friendly control interface WiFi with LG Smart ThinQ Double independent thermal zone control Temperature control of water, air or both at the same time Simplified installation and maintenance Monobloc unit with reduced weight and dimensions. No refrigerant piping installation is required Simplified initial start-up and configuration: from PC using LG Heating Configurator software R32 monoblock THERMA V Monobloc R32 includes all the main hydraulic components (plate exchanger, expansion tank and circulation pump) in a single outdoor unit, allowing installation without the use of refrigerant gas pipes LG high efficiency solutions for heating and domestic hot water LG products represent the sustainable and efficient solution for heating in domestic and commercial applications, thanks to continuous investments in research and development of renewable energy technologies The LG THERMA V residential heating solution can be dedicated both to space heating and cooling and to the production of domestic hot water. Compared to traditional boiler systems, it is more efficient and reduces CO2 emissions by using renewable energy (contained in the outside air.). In addition, the entire system can be managed and monitored remotely via the LG Smart ThinQ app The LG control system offers a variety of solutions that allow you to reduce operating costs and maintain efficient control of the energy used. The new RS3 wired controller, together with other accessories, offers a simple interface to facilitate control, configuration and monitoring of the system New Scroll compressor The new vapor injection scroll compressor combines high performance, efficiency and reliability. Compared to traditional scroll compressors, it allows to reach water temperatures up to 65°C, reduce noise and increase the rotation speed range (10-135 Hz) Noise Level Reduction THERMA V Monobloc R32 has a lower noise level than the previous model Steam injection When using R32 refrigerant it is very important to correctly control the gas discharge temperature from the compressor. In the case of THERMA V Monobloc R32, steam injection technology was used to efficiently control the compressor discharge temperature. This allows to increase the field of use of the heat pump (up to -25°C outside) and to improve the heating performance at low temperatures Delivery temperature up to 65° C THERMA V Monobloc R32 is capable of producing hot water up to 65°C, thus being able to supply medium/high temperature terminals (e.g. radiators) without problems. For this reason, the LG solution is suitable for both renovations and new buildings Temperature Control Options To ensure greater comfort, efficiency and savings, multiple temperature control options are available. Furthermore, simultaneous air and water temperature control functions have been added, particularly suitable for the European lifestyle, very attentive to thermal comfort Seasonal Climate Mode Seasonal weather mode adjusts the heat pump operation automatically based on the outside temperature. It is used to set the water temperature in order to maximize energy savings by exploiting the integrated climatic regulation Silent mode and weekly programming Using the command it is possible to activate the Silent Mode function to reduce the noise emissions of the outdoor unit to a minimum. By means of the timer it is also possible to program the start-up and deactivation of the cycle. Using the command it is also possible to set the weekly programming of the heat pump operation Simplified Installation and Maintenance Monobloc module THERMA V Monobloc includes all the main hydraulic components (plate exchanger, expansion tank and circulation pump) in a single outdoor unit, allowing it to be installed without using refrigerant gas pipes Easy Startup Setting of operating parameters before installation Based on the information relating to the system, the installer can set the parameters using the "LG Heating Configurator" software and save the data on a memory card directly from the office. On site, simply insert the card on the back of the wired controller to activate the configuration Easy Maintenance Data Logging The remote control can memorize up to 50 events, making it possible to easily identify the causes of any malfunctions Date and time Operating modes (Heating, Cooling, Automatic, Domestic hot water) Temperature targets Flow / return temperature Room temperature DHW (Operating Status / Target Temperature / Current Temperature) Outdoor unit operation Errors and related code Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.540,00

  • immagine-1-lg-pompa-di-calore-mini-chiller-inverter-lg-therma-v-monoblocco-9-kw-hm091mr.u44-monofase-r-32-ean-8806091527394

    LG Heat Pump Mini Chiller Inverter LG Therma V Monobloc 9 Kw Hm091mr.U44 Single Phase R-32

    NON-OBLIGATORY PAID IGNITION BY THE SERVICE CENTER Technical features Product code : HM091MR U44 Water pump : Grundfos UPM3K 20-75 CHBL Energy efficiency EER: 4.2 SCOP: 4.55 Heating Energy Efficiency Class: A+++ Performance Cooling Capacity: 9.0 kW Heating Capacity: 9.0 kW Nominal flow rate : 1554 l/h Sound power level : 57 dB(A) Sound pressure level : 35 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Operational Limits Air Heating : -25° ~ 35° C Cooling : 5° ~ 48° C Operating Limits Water Heating : 15° ~ 65° C Cooling : 5° ~ 27° C DHW : 15° ~ 80° C Installation data Hydraulic Pipe Diameter Inlet: 25.4 mm (1") Male Hydraulic piping diameter Exit : 25.4 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1239x834x330 mm Weight of Outdoor Unit: 89.0 Kg LG Heat Pumps Therma V Line LG offers a wide range of highly efficient renewable energy systems and provides the ideal solution for every application and need What is THERMA V ? THERMA V is LG's new air-to-water heat pump system, designed for new homes and renovations with the most advanced energy-saving heating technologies. THERMA V is the ideal solution for heating, cooling and the production of domestic hot water in domestic environments. The most complete and efficient solution for your home THERMA V offers the best solution for domestic heating and for the supply of domestic hot water. Thanks to LG's inverter technology, THERMA V systems are up to 4 times more efficient than traditional boilers Applications : Fan Coil Radiators Radiant floor Hot water Why Choose LG THERMA ? LG THERMA V is designed to provide the user with energy saving, comfort, simplified control and support services, thanks to the application of advanced LG technologies. LG's Inverter technology provides high energy efficiency, achievable with the use of components such as circulation pump, heat exchanger and fan motor completely designed and manufactured by the company Furthermore, the pressure control technology allows a stable and reliable heating capacity even at low temperatures and the achievement of the performance target effectively The new packaged units, thanks to the corrosion-resistant Ocean Black Fin treatment and user-friendly control with the new RS3 command, meet the needs of both professionals and end users High performance High energy efficiency SCOP 4.45 A+++ Maximum performance at low temperatures Operating range down to -25°C Water delivery temperature 65°C up to -5° C Low noise level Innovative vapor injection scroll compressor User benefits New user-friendly control interface WiFi with LG Smart ThinQ Double independent thermal zone control Temperature control of water, air or both at the same time Simplified installation and maintenance Monobloc unit with reduced weight and dimensions. No refrigerant piping installation is required Simplified initial start-up and configuration: from PC using LG Heating Configurator software R32 monobloc THERMA V Monobloc R32 includes all the main hydraulic components (plate exchanger, expansion tank and circulation pump) in a single outdoor unit, allowing installation without the use of refrigerant gas pipes LG high efficiency solutions for heating and domestic hot water LG products represent the sustainable and efficient solution for heating in domestic and commercial applications, thanks to continuous investments in research and development of renewable energy technologies The LG THERMA V residential heating solution can be dedicated both to space heating and cooling and to the production of domestic hot water. Compared to traditional boiler systems, it is more efficient and reduces CO2 emissions by using renewable energy (contained in the outside air.). In addition, the entire system can be managed and monitored remotely via the LG Smart ThinQ app The LG control system offers a variety of solutions that allow you to reduce operating costs and maintain efficient control of the energy used. The new RS3 wired controller, together with other accessories, offers a simple interface to facilitate control, configuration and monitoring of the system New Scroll compressor The new vapor injection scroll compressor combines high performance, efficiency and reliability. Compared to traditional scroll compressors, it allows to reach water temperatures up to 65°C, reduce noise and increase the rotation speed range (10-135 Hz) Noise Level Reduction THERMA V Monobloc R32 has a lower noise level than the previous model Steam injection When using R32 refrigerant it is very important to correctly control the gas discharge temperature from the compressor. In the case of THERMA V Monobloc R32, steam injection technology was used to efficiently control the compressor discharge temperature. This allows to increase the field of use of the heat pump (up to -25°C outside) and to improve the heating performance at low temperatures Delivery temperature up to 65° C THERMA V Monobloc R32 is capable of producing hot water up to 65°C, thus being able to supply medium/high temperature terminals (e.g. radiators) without problems. For this reason, the LG solution is suitable for both renovations and new buildings Temperature Control Options To ensure greater comfort, efficiency and savings, multiple temperature control options are available. Furthermore, simultaneous air and water temperature control functions have been added, particularly suitable for the European lifestyle, very attentive to thermal comfort Seasonal Climate Mode Seasonal weather mode adjusts the heat pump operation automatically based on the outdoor temperature. It is used to set the water temperature in order to maximize energy savings by exploiting the integrated climatic regulation Silent mode and weekly programming Using the command it is possible to activate the Silent Mode function to reduce the noise emissions of the outdoor unit to a minimum. By means of the timer it is also possible to program the start-up and deactivation of the cycle. Using the command it is also possible to set the weekly programming of the heat pump operation Simplified Installation and Maintenance Monobloc module THERMA V Monobloc includes all the main hydraulic components (plate exchanger, expansion tank and circulation pump) in a single outdoor unit, allowing it to be installed without using refrigerant gas pipes Easy Startup Setting of operating parameters before installation Based on the information relating to the system, the installer can set the parameters using the "LG Heating Configurator" software and save the data on a memory card directly from the office. On site, simply insert the card on the back of the wired controller to activate the configuration Easy Maintenance Data Logging The remote control can memorize up to 50 events, making it possible to easily identify the causes of any malfunctions Date and time Operating modes (Heating, Cooling, Automatic, Domestic hot water) Temperature targets Flow / return temperature Room temperature DHW (Operating Status / Target Temperature / Current Temperature) Outdoor unit operation Errors and related code Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.950,00

  • immagine-1-beretta-pompa-di-calore-idronica-aria-acqua-beretta-hydro-unit-m-008-monofase-r-32-20191952

    BERETTA Air-Water Hydronic Heat Pump Beretta Hydro Unit M 008 Single-Phase R-32 20191952

    ATTENTION ! IN CASE OF NO IMMEDIATE AVAILABILITY, THE PRODUCT WILL BE ORDERED AND SHIPPED IN 10 WORKING DAYS   FREE FIRST START-UP Technical features Model : HYDRO UNIT M 008 Product code : 20191952 Optional REC10MH command Energy efficiency Energy class in heating at 35° C: A+++ Energy class in heating at 55° C: A++ Heating COP with water set at 35°C: 5.15 Heating COP with water set at 45°C: 3.85 Heating COP with water set at 55°C: 3.18 EER cooling with water set at 7°C: 3.35 EER cooling with water set at 18°C: 5.05 Performance   Heating Useful power in heating with water set at 35° C: 8.40 kW Useful power in heating with water set at 45° C: 8.10 kW Useful power in heating with water set at 55° C: 7.50 kW Absorbed power with water set at 35° C: 1.63 kW Absorbed power with water set at 45° C: 2.10 kW Absorbed power with water set at 55° C: 2.36 kW Cooling down Useful power in cooling with water set at 7 °C: 7.45 kW Useful power in cooling with water set at 18 °C: 8.30 kW Absorbed power with water set at 7° C: 2.22 kW Absorbed power with water set at 18° C: 1.64 kW Technical data Hydronic circuit maximum operating pressure: 3 bar Maximum absorbed power: 0.043 kW System expansion tank: 8 litres Sound data Sound power : 59 dB(A) Sound pressure : 48.5 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Dimensions and weight Dimensions (LxHxP): 1295x945x526 mm Empty weight: 121.0 kg Beretta HYDRO UNIT M Inverter Monoblock Air-Water Hydronic Heat Pumps These units are used for both heating and cooling applications as well as domestic hot water tanks. They can be combined with fan coil units, underfloor heating applications, low temperature high efficiency radiators, domestic hot water tanks and solar kits, all of which are field powered. A wired controller is supplied with the unit. The backup heater, available as an accessory, can increase the heating capacity in cold outside temperatures. The backup heater also serves as a backup in the event of a malfunction and as a freeze protection of the outdoor water pipes during the winter. Efficiency and sustainability The heat pumps of the HYDRO UNIT M series use R32 as the refrigerant gas, a gas with a lower Global Warming Potential than the traditional gases used. The design of a new sealed circuit for fluorinated gases, the use of R32, reduced load volumes, lower CO2 emissions and increased energy efficiency are the characteristics that differentiate HYDRO UNIT M and increase its sustainability environmental. Quietness The low noise level is guaranteed by the construction features used and can be further reduced thanks to the silent mode programming, available to the customer Antifreeze function The HYDRO UNIT M heat pump is foreseen for outdoor installation and equipped with the ANTIFREEZE function for the protection of the entire hydraulic circuit. This customer-programmable function activates automatically whenever the water temperature in the system drops below a pre-set value, ensuring the protection of the entire system Better performance The ten models available offer powers from 4 kW to 16 kW , with fast response to requests and reduced energy consumption which guarantee energy class A+++ up to 35°C and A++ up to 55°C HP KEYMARK Certified The design meets the requirements of the voluntary European HP KEYMARK certification Easy and flexible Installing HYDRO UNIT M is easy thanks to the hydronic kit that comes with the monobloc and which contains all the essential components. HYDRO UNIT M is flexible thanks to its ability to respond quickly to the real needs of the environments to be served Functional elements Beretta Hydro Unit M Inverter Control Board Maximizes power under critical load conditions and provides stability and efficiency at part loads AISI 316 steel plate heat exchanger : protected with closed cell anti-condensation insulation, it offers high heat exchange efficiency Control board Operating parameters constantly analyzes the ambient temperature and the water temperature to activate the different components and meet the demand Hydronic module Including low consumption circulator, expansion vessel, automatic vent valve and safety valve Electronic expansion valve Optimizes the flow of the refrigerant fluid in every situation Twin rotary compressor Inverter System design including DC twin rotary compressor, fan motor and pump ensures precise motor speed control for the right power needed to perfectly match actual load and save energy Fan Special design of the blade and its edge that allows optimizing the flow surface, improving efficiency and reducing fan noise Heat exchange coil With extended surface and aluminum fins Install more Hydro Unit M HYDRO UNIT M offers the possibility of connecting up to six units to each other for the heating, cooling and domestic hot water needs of small condominiums and light commercial contexts. Each of the units responds individually to the demands of the environment in which it is installed Easily manage the plant Advanced remote control This module, present in every HYDRO UNIT M installation, has a multilingual display and allows you to: Manage up to six units connected in cascade Activate the programmed functions such as the Antifreeze function and the Vacation function, for the serenity of the family REC10MH management module Designed for full-electric and hybrid applications, this module is installed inside the home and allows the user to easily manage the entire system. If the system is equipped with a Hybrid distribution system, REC10MH allows you to manage the multi-zone system to optimize the operation of the system. The module is equipped with a color display and a multilingual menu USB Each HYDRO UNIT M is equipped with a USB port to connect the USB flash memory to update the unit firmware Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.200,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi140-12-kw-r-32-trifase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi140 12 Kw R-32 Three-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI140 Energy efficiency EER: 2.74 COP: 3.35 Energy Efficiency Class for low temperatures: A++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 12.0 kW Heating Capacity: 14.0 kW Cooling absorption: 4.38 kW Heating absorption: 4.18 kW Cooling water flow rate: 2065 l/h Heating water flow rate: 2474 l/h Sound power level : 70 dB(A) Sound Pressure Level : 55~57 dB(A) Electrical data Power supply (V,Hz, Ø) : 380~415/50/3 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1200x878x460 mm Weight of Outdoor Unit: 151 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion vessel Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €5.450,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi120-95-kw-r-32-trifase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi120 9.5 Kw R-32 Three-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI120T Energy efficiency EER: 3.05 COP: 3.45 Energy Efficiency Class for low temperatures: A+++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 9.5 kW Heating Capacity: 12.0 kW Cooling absorption: 3.11 kW Heating absorption: 3.48 kW Cooling water flow rate: 1665 l/h Heating water flow rate: 2040 l/h Sound power level : 69 dB(A) Sound Pressure Level : 54~56 dB(A) Electrical data Power supply (V,Hz, Ø) : 380~415/50/3 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1200x878x460 mm Weight of Outdoor Unit: 151 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion tank Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €4.615,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi160-13-kw-r-32-monofase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi160 13 Kw R-32 Single-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI160 Energy efficiency EER: 2.62 COP : 3.30 Energy Efficiency Class for low temperatures: A++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 13.0 kW Heating Capacity: 15.0 kW Cooling absorption: 4.96 kW Heating absorption: 4.70 kW Cooling water flow rate: 2270 l/h Heating water flow rate: 2700 l/h Sound power level : 72 dB(A) Sound Pressure Level : 57~59 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1200x878x460 mm Weight of Outdoor Unit: 151 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion vessel Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €5.715,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi120-95-kw-r-32-monofase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi120 9.5 Kw R-32 Single-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI120 Energy efficiency EER: 2.97 COP: 3.45 Energy Efficiency Class for low temperatures: A+++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 9.5 kW Heating Capacity: 12.0 kW Cooling absorption: 3.2 kW Heating absorption: 3.48 kW Cooling water flow rate: 1650 l/h Heating water flow rate: 2050 l/h Sound power level : 69 dB(A) Sound Pressure Level : 54~56 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1200x878x460 mm Weight of Outdoor Unit: 151 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion vessel Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €4.465,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi060-4-kw-r-32-monofase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi060 4 Kw R-32 Single-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI060 Energy efficiency EER: 3.10 COP: 3.80 Energy Efficiency Class for low temperatures: A+++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 4.0 kW Heating Capacity: 6.0 kW Cooling absorption: 1.29 kW Heating absorption: 1.58 kW Cooling water flow rate: 672 l/h Heating water flow rate: 977 l/h Sound power level : 64 dB(A) Sound Pressure Level : 50~52 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1150x758x345 mm Weight of Outdoor Unit: 96 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion vessel Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.750,00

  • immagine-1-aermec-pompa-di-calore-reversibile-aermec-refrigeratore-hmi040-3-kw-r-32-monofase-wi-fi-integrato-con-pannello-di-controllo-remoto-incluso

    Aermec Aermec Reversible Heat Pump Chiller Hmi040 3 Kw R-32 Single-Phase Integrated Wi-Fi With Remote Control Panel Included

    FREE FIRST START-UP Technical features Product code : HMI040 Energy efficiency EER: 3.19 COP : 4.0 Energy Efficiency Class for low temperatures: A+++ Energy Efficiency Class for medium temperatures: A++ Performance Cooling Capacity: 3.0 kW Heating Capacity: 4.0 kW Cooling absorption: 0.94 kW Heating absorption: 1.0 kW Cooling water flow rate: 516 l/h Heating water flow rate: 690 l/h Sound power level : 64 dB(A) Sound Pressure Level : 50~51 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Installation data Hydraulic pipes diameter: 25 mm (1") Male Dimensions and weight External Unit Dimensions (LxHxP): 1150x758x345 mm Weight of Outdoor Unit: 96 Kg Aermec Air Condensed Heat Pump Outdoor reversible heat pump for air conditioning systems where, in addition to cooling the rooms, high temperature hot water is required for heating or for the production of domestic hot water. For the production of DHW, it must be combined with the DHWT300S domestic hot water storage tank . HMI has been designed to meet the needs of the new construction and renovation markets, replacing or supporting conventional boilers . It can be combined with low temperature emission systems such as underfloor heating or fan coils but also with more traditional radiators, and is already supplied with the main hydraulic components, thus also facilitating the final installation Operational Limits Full load operation up to -25 °C outside air temperature in winter and up to 48 °C in summer. Maximum temperature of water produced in heating mode 60 °C Cooling circuit with economizer Brushless DC axial fans designed for aerodynamic optimization, allowing a reduction of the noise level, but at the same time, an increase in efficiency and air flow. Equipped with base electric resistance to prevent any formation of ice and facilitate the disposal of condensate during heating operation. Electronic expansion valve Main hydraulic components Inverter pump Plate heat exchanger Expansion tank Safety valve Flow switch Supplied water filter (compulsory installation) Adjustment via multilingual touch screen control panel Management of a 3-way diverter valve (not supplied) for the production of domestic hot water Management of a 2-way valve (not supplied) for shutting off a part of the system Weekly and time band programming Auto-restart function Emergency operation (can activate a substitute heat source) Quick hot water function for rapid heating of domestic hot water Weather dependent mode function for climatic regulation Quiet function for silent operation, programmable with timer Condensation control The activation of the anti-legionella cycle (easily set from the control panel) allows weekly heating of the entire tank to a temperature (max 70°C) such as to eradicate the bacterium responsible for the infection Special golden fin battery Unlike normal coils, this special gold colored silicon-free epoxy coating is able to protect the exchanger from rust and corrosion in areas where the amount of salt present in the air is very high Ewpe Smart APP The system is equipped as standard with the Wi-Fi module; through this module and a special App for iOS and Android devices, available free of charge on the Apple Store and Google Play, it is possible to control the system remotely directly from your smartphone or tablet. Remote control can be done via Cloud using a wireless router connected to the internet. Accessories DHWT300S: (220-240V~50Hz) enamelled steel domestic hot water storage tank. Single-phase power supply, 300-litre capacity with main and secondary coil, 3 kW electric support heater. Magnesium sacrificial anode. Indoor installation, as indicated in the installation manual HMICB15: Connection cable for wired control panel. Cable length 15m IC-2P: Connector for using communication via ModBus or VMF-485LINK. Compulsory accessory if combined with VMF-485LINK, or for third-party supervisory systems VMF-485LINK: Expansion to interface the unit with the VMF communication protocol, making it possible to manage from VMF-E5 or VMF-E6 supervisors Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.684,00

  • immagine-1-panasonic-pompa-di-calore-monoblocco-panasonic-aquarea-9-kw-wh-mdc09j3e5-r-32-wi-fi-optional-aa

    Panasonic Panasonic Aquarea Monobloc Heat Pump 9 Kw Wh-Mdc09j3e5 R-32 Wi-Fi Optional A+++/A++

    MANDATORY CONFIGURATION AND START-UP PIT-A2W-START UP NOT INCLUDED! Technical features Catalog number WH-MDC09J3E5 Wi-Fi Optional : CZ-TAW1 Energy efficiency Energy Efficiency Class at medium temperatures: A+++ Energy Efficiency Class at low temperatures: A++ Performance Cooling Capacity: 9.0 kW Heating Capacity: 9.0 kW Sound power level : 59 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R410 Operating range - Cooling: -10° ~ 43°C - Heating: -20° ~ 35° C Installation data Plumbing pipe diameter: 1 mm (1/4") Dimensions and weight Dimensions (HxWxD): 865x1283x320 mm Empty weight: 104 Kg Aquarea Heat Pumps Efficiency at the highest levels Panasonic introduces an innovative low energy consumption system based on air to water heat pump technology. Aquarea heats your home effectively and efficiently, even in extreme outside temperatures. Aquarea can refresh spaces even in summer and bring hot water all year round. Aquarea High Performance is the range for new installations and low consumption homes. Exceptional efficiency and energy savings with low CO 2 emissions and minimal space. The Monobloc system has only one outdoor unit. The system does not require a refrigerated connection and is only connected to heating and / or hot water A heat pump converts heat energy outdoors into heat indoors With Aquarea, 80% of the thermal energy required is taken from the environment. Aquarea, through the heat exchange with the external air and the refrigerant gas contained in it, is able to heat/cool the water by conveying it to the domestic air conditioning system and satisfies all the needs for the production of domestic hot water 3 good reasons why Aquarea is the ideal solution for your home Wide range suitable for all homes Aquarea is an innovative system with low energy consumption, designed to provide ideal temperatures and domestic hot water, even with extreme outside temperatures. It is highly reliable thanks to the quality of all components, including the compressor, developed and manufactured by Panasonic. With the possibility to choose between multiple units, Aquarea ensures a very wide range availability to ensure the most appropriate choice for your home, regardless of size Heat pump, 80% energy at no cost Based on air-to-water heat pump technology, Aquarea is highly efficient and environmentally friendly. It captures the thermal energy present in the air and transfers it to heat the water needed for heating your home, for domestic hot water and even to cool your home if you wish. In this way, up to 80% of the required thermal energy is taken from the ambient air, even at extremely low temperatures Helps you save Save up to €1,100 a year compared to conventional electric heating. While the initial investment may be higher than with other technologies, the cost of ownership is much lower, with a reduced initial cost payback period. The savings are significant, particularly when compared to oil fired electric boilers and heaters Aquarea with R32 Refrigerant The detail that makes the difference Panasonic recommends R32 refrigerant as it is environmentally friendly. Unlike R22 and R410A gases, R32 refrigerant has a low potential impact on the ozone layer and global warming. Panasonic has introduced R32 models to align with all European countries that have adopted the Montreal Protocol to protect the ozone layer and prevent global warming Innovative installation Extremely easy to install. (Make sure the pressure gauge and vacuum pump are compatible with R32). This refrigerant is 100% pure, making it easier to recycle and reuse Environmental innovation Zero impact on the ozone layer. Reduced impact on global warming by 75% Economic and energy consumption innovation Lower costs and higher savings. Higher efficiency than R410A gas Aquarea Service Cloud. Check anytime, anywhere Aquarea Smart Cloud is a powerful, intuitive and free service designed to help you remotely control Aquarea heat pumps from anywhere, 24/7 The advanced control is an intelligent, sophisticated and effective service to fully manage the Aquarea range in the heating, cooling and domestic hot water functions inside the house, including the monitoring of domestic energy consumption via smartphone, tablet or mobile device Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

    €3.985,00
