Technical features Indoor units 1) Model Indoor unit catalog code : 2x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 1x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 3) Model Indoor unit catalog code : 1x ASYG14KMCF Indoor unit code: 3NGF82115 Power: 14000 btu/h Cooling capacity : 4.2 kW Heating capacity : 5.4 kW Air flow : 770 m 3 /h Sound power level : 57~59 dB(A) Sound pressure level : 21~44 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 2x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 2x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 1x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 1x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 3) Model Indoor unit catalog code : 2x ASYG14KMCF Indoor unit code: 3NGF82115 Power: 14000 btu/h Cooling capacity : 4.2 kW Heating capacity : 5.4 kW Air flow : 770 m 3 /h Sound power level : 57~59 dB(A) Sound pressure level : 21~44 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy savings High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor unit catalog code : ASYG07KMCF Outdoor unit catalog code : AOYG07KMCC Kit code : 3NGF87270 Power : 7000 Btu Integrated Wi-Fi Energy efficiency SEER : 7.40 SCOP : 4.10 Energy efficiency class in cooling: A++ Energy efficiency class in heating: A+ Annual energy consumption in cooling : 95 kWh/a Annual energy consumption in heating : 785 kWh/a Performance Cooling capacity : 2.0 kW Heating capacity: 2.5 kW Cooling absorption: 0.450 kW Heating absorption: 0.555 kW Internal unit air flow: 650 m 3 /h Indoor unit sound power level : 54~56 dB(A) External unit sound power level : 61 dB(A) Indoor unit sound pressure level : 20~41 dB(A) Outdoor unit sound pressure level : 46 dB(A) Electrical data Power supply (V,Hz, Ø) : 230/50/1 Refrigerant gas : R32 Operating range - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Maximum piping length: 20 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight Internal unit dimensions (HxWxD): 270x834x222 mm Indoor unit weight: 10.0 Kg External unit dimensions (HxWxD): 541×663×290 mm Outdoor unit weight: 22.0 Kg Fujitu KM Series Air Conditioner The KM models are equipped with R32 refrigerant gas which allows a 67% reduction in the global warming indicator (from a value of 2.088 to 675), bringing the Ozone Depletion Potential (ODP) to a value close to zero. In the 9000 and 12000 Btu versions the seasonal energy efficiency index (SEER) is respectively 7.40 and 7.30 (in the previous models of the same series the index was 7.00). Attention to consumption and energy savings are also confirmed by the double class A in cooling. Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Inverter technology Twin rotary DC compressor Twin rotary DC is the high efficiency compressor used in all our product ranges. Its innovative design guarantees greater energy efficiency than normal compressors. The DC fan motor supports the high efficiencies required in all of our air conditioners. Maximum operating power Only 20 minutes at maximum power: with this function, the air conditioner quickly reaches the comfort conditions required inside the rooms. Silent mode for outdoor unit Activating this function of the remote controller reduces the noise of the outdoor machine. 10°C holding temperature The 10°C holding temperature mode prevents the temperature in unoccupied rooms from falling too low High energy savings High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Comfortable ventilation and silent operation The large baffle and the new diffusion structure allow a comfortable airflow that spreads wider to the user's feet and silent operation Functions • Up and down movement of the flaps Automatic opening and closing of the flaps • Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room • Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns • 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating • Automatic shutdown Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed shutdown of the air conditioner • Daily Timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON • Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort • Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling mode • Energy saving Control system for energy saving • Silent Mode Reducing the noise of the external machine • Filter status indicator Allows you to check the cleanliness of the filters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 1x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 2x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 3) Model Indoor unit catalog code : 1x ASYG14KMCF Indoor unit code: 3NGF82115 Power: 14000 btu/h Cooling capacity : 4.2 kW Heating capacity : 5.4 kW Air flow : 770 m 3 /h Sound power level : 57~59 dB(A) Sound pressure level : 21~44 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 1x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 3x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units Indoor unit catalog code : 3x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog number : AOYG24KBTA3 Outdoor unit code: 3NGF82002 Number of connectable indoor units : Up to 3 indoor units Energy efficiency SEER: 8.6 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 6.8 kW Heating capacity: 8.0 kW Sound power level : 61~67 dB(A) Sound pressure level : 48~53 dB(A) Electrical data Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid pipe diameter : 6.35 mm (1/4") x3 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") Maximum piping length: 50 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 716x820x315 mm Outdoor unit weight: 46.0 Kg High energy savings High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units Indoor unit catalog code : 3x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG18KBTA3 Outdoor unit code: 3NGF82001 Number of connectable indoor units : Up to 3 indoor units Energy efficiency SEER: 8.6 SCOP : 4.7 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 5.4 kW Heating capacity: 6.8 kW Sound power level : 59~61 dB(A) Sound pressure level : 46~49 dB(A) Electrical data Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid pipe diameter : 6.35 mm (1/4") x3 Gas pipe diameter : 9.52 mm (3/8") x3 Maximum piping length: 50 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 716x820x315 mm Outdoor unit weight: 46.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 1x ASYG07KMCF Indoor unit code: 3NGF82112 Power: 7000 btu/h Cooling capacity : 2.0 kW Heating capacity : 2.5 kW Air flow : 650 m 3 /h Sound power level : 54~56 dB(A) Sound pressure level : 21~41 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 3x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 1x ASYG07KMCF Indoor unit code: 3NGF82112 Power: 7000 btu/h Cooling capacity : 2.0 kW Heating capacity : 2.5 kW Air flow : 650 m 3 /h Sound power level : 54~56 dB(A) Sound pressure level : 21~41 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 2x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 3) Model Indoor unit catalog code : 1x ASYG14KMCF Indoor unit code: 3NGF82115 Power: 14000 btu/h Cooling capacity : 4.2 kW Heating capacity : 5.4 kW Air flow : 770 m 3 /h Sound power level : 57~59 dB(A) Sound pressure level : 21~44 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog code : AOYG30KBTA4 Outdoor unit code: 3NGF82003 Number of connectable indoor units : Up to 4 indoor units Energy efficiency SEER: 8.5 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 8.0 kW Heating capacity: 9.6 kW Sound power level : 63~66 dB(A) Sound pressure level : 50~54dB(A) Electrical data Power supply (V/Hz/F) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid Pipe Diameter : 6.35mm (1/4") x4 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") x2 Maximum piping length: 70 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 884x820x315 mm Outdoor unit weight: 55.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 2x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 1x ASYG14KMCF Indoor unit code: 3NGF82115 Power: 14000 btu/h Cooling capacity : 4.2 kW Heating capacity : 5.4 kW Air flow : 770 m 3 /h Sound power level : 57~59 dB(A) Sound pressure level : 21~44 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog number : AOYG24KBTA3 Outdoor unit code: 3NGF82002 Number of connectable indoor units : Up to 3 indoor units Energy efficiency SEER: 8.6 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 6.8 kW Heating capacity: 8.0 kW Sound power level : 61~67 dB(A) Sound pressure level : 48~53 dB(A) Electrical data Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid pipe diameter : 6.35 mm (1/4") x3 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") Maximum piping length: 50 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 716x820x315 mm Outdoor unit weight: 46.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor units 1) Model Indoor unit catalog code : 2x ASYG09KMCF Indoor unit code: 3NGF82113 Power: 9000 btu/h Cooling capacity : 2.5 kW Heating capacity : 2.8 kW Air flow : 700 m 3 /h Sound power level : 55~57 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi 2) Model Indoor unit catalog code : 1x ASYG12KMCF Indoor unit code: 3NGF82114 Power: 12000 btu/h Cooling capacity : 3.4 kW Heating capacity : 4.0 kW Air flow : 700 m 3 /h Sound power level : 55~58 dB(A) Sound pressure level : 21~42 dB(A) Liquid piping diameter : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Dimensions (HxWxD): 270x834x222 mm Weight : 10.0 Kg Built-in Wi-Fi Outdoor unit Outdoor unit catalog number : AOYG24KBTA3 Outdoor unit code: 3NGF82002 Number of connectable indoor units : Up to 3 indoor units Energy efficiency SEER: 8.6 SCOP: 4.6 Energy efficiency class in cooling: A+++ Energy efficiency class in heating: A++ Performance Cooling capacity : 6.8 kW Heating capacity: 8.0 kW Sound power level : 61~67 dB(A) Sound pressure level : 48~53 dB(A) Electrical data Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Guaranteed temperature range: - Cooling: -10° ~ 46°C - Heating: -15° ~ 24°C Installation data Liquid pipe diameter : 6.35 mm (1/4") x3 Gas pipe diameter : 9.52 mm (3/8") x2 + 12.70 mm (1/2") Maximum piping length: 50 m Maximum height difference between indoor unit and outdoor unit: 15 m Dimensions and weight External unit dimensions (HxWxD): 716x820x315 mm Outdoor unit weight: 46.0 Kg High energy saving High-Tech Components: DC technology is used for the compressor, indoor/outdoor fan motor and inverter control. High efficiency is ensured by a highly efficient heat exchanger, a large fan and a new refrigerant. New R32 refrigerant Its low global warming potential (GWP) of one third of the most common refrigerant used for air conditioning, is an advantage for the environment Fujitsu KM Series Other pluses of the KM range are noiselessness and small dimensions: split only 222 mm deep. The air conditioner can in fact operate at just 20 decibels in the cooling phase. Thanks to a particular high-density multi-passage heat exchanger and a powerful ventilation system, it has been possible to combine high performance with a reduction in overall dimensions to obtain an aesthetic capable of harmoniously fitting into any type of residential environment. The entire KM range of air conditioners can also be controlled remotely via smartphone and tablet: simply download the free FGLair application, also available in Italian. The design is characterized by the essentiality of the elegant linear edges: a minimal conception that has allowed Fujitsu Climatizzatori to win the "Good Design Award", in whose evaluation for the assignment of the recognition criteria such as ease of use, basis of product development, functionality and new technologies used. Slim and elegant design The slim and elegant shape is achieved thanks to the multi-pass high-density heat exchanger and the high-efficiency fan Smart control device included The air conditioner can be controlled from anywhere using the built-in wireless LAN interface. The wireless LAN interface is installed in the indoor unit. Thanks to the AIRSTAGE Mobile App, you can control the air conditioner anytime, anywhere. Functions Up-down movement of the flaps Automatic opening and closing of the flaps Automatic ventilation speed Automatic modification of the ventilation speed according to the temperature required in the room Automatic Restart In the event of a momentary power failure, the air conditioner restarts automatically when the power returns 10°C HEAT 10°C is the minimum attenuation temperature that can be set in heating Automatic switch-off Sleep Night comfort is guaranteed by the gradual regulation of the temperature before the programmed switch-off of the air conditioner Daily timer Four possible selections within 24 hours ON, OFF, ON OFF or OFF ON Maximum Power Function that allows you to activate the climate control system at maximum power for rapid achievement of comfort Automatic cold/heat switching By comparing the room temperature and the set temperature, the air conditioner automatically activates in heating or cooling Energy saving Control system for energy saving Filter status indicator Allows you to check the cleanliness of the filters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
