• Pipe diameter Liquid : 6.35 mm (1/4")
• Gas pipe diameter: 9.52 mm (3/8")
• Maximum piping length: 15 m

Dimensions and weight

• Internal Unit Dimensions (WxHxD): 837×308×189 mm
• Indoor Unit Weight: 8.7 Kg
• External Unit Dimensions (WxHxD): 717x483x230 mm
• Weight of Outdoor Unit: 28 Kg

Dual Inverter compressor guaranteed for 10 years

LG, which places great faith in the quality and reliability of its products, offers a 10-year warranty on the Inverter compressor of all mono and multi-split models featured in this catalogue.

The warranty mentioned above covers the costs of the Inverter compressor only for a total period of 10 years from the date of purchase of the air conditioner. Any other cost other than the value of the replaced component alone is to be considered excluded from coverage.

LG Free Compact

Comfort Air function By pressing the button on the infrared control, the deflector is positioned automatically according to the selected operating mode. In heating the deflector adjusts to the lowest position while in cooling it is set to the highest position

Active Capacity Control 4-step energy consumption control using a button on the infrared control

Normal 100% consumption: Premises with several people, with a high degree of activity

Step1 80% consumption : Premises with more people, with a reduced degree of activity

Step2 60% consumption : Local with few people, with reduced degree of activity

Step2 40% consumption: Local with few people, with very low degree of activity

Smart diagnosis

Smart Diagnosis allows you to check the functionality and troubleshooting via smartphone with a simple SMART DIAGOSIS app available for android devices

Outdoor Unit

The self-supporting structure in galvanized steel sheet panels painted in warm gray (Ral 9001) with surface treatment and Cataphoresis process, a surface treatment capable of conferring considerable resistance to corrosion in order to protect the outdoor unit from atmospheric. Removable right panel for connection operations with the refrigerant circuit. Removable cover to access the control components. Protection grid on the air expulsion.

The Wide Louver Fin external heat exchanger which gives an improvement in the exchange efficiency equal to 28% more than a traditional exchanger, coated with a GOLD FIN galvanic bath anti-corrosion treatment to give better resistance to acid rain and salt in sea areas

Compressor

Capacity delivery system consisting of 1 Twin Rotary Dc inverter hermetic compressor with direct start. linear control of the capacity with an action range between the minimum of 10% up to a maximum of 130%

The fan for heat exchange with the outside of the helical type with intake on the rear side and horizontal delivery on the front side with an air flow rate of 27 m3/min. Motor type BLDC inverter with air flow and low noise from 0.30 kW

Refrigerant circuit

Made of aluminum tubes, complete with dehydrating filters, 4-way cycle inversion valve, electronically controlled expansion valves on each connection, liquid state refrigerant separator with accumulation function on compressor suction, service valves dedicated to each connection of the internal units on the gas side. The distribution system provides for connections having the liquid and gas diameters of 6.35 mm and 9.52 mm respectively

Main electronic board

Main control and safety electronic board accessible by removing the top cover, capable of automatically managing the cooling and heating operating modes and the defrosting function of the external heat exchanger

Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.
