ATTENTION The product will be available on order and will be shipped in 10 working days! Technical features Indoor unit catalog code: RAI-35RPE Outdoor unit catalog number : RAC-35NPE Power : 12000 Btu Panel Included : P-AP56NAMS Optional Wi-Fi Card: ( Code SPX-WFG01 ) Remote Control with Optional Receiver ( Code SPX-RCKA3 ) Simplified Wall Command Optional : ( Code SPX-RCDB ) Optional Wall Control with Weekly Timer : ( Code SPX-WKT3 ) Energy efficiency SEER: 6.5 SCOP : 4.3 Energy Efficiency Class in Cooling : A++ Heating Energy Efficiency Class: A+ Performance Cooling Capacity: 3.5 kW Heating Capacity: 4.8 kW Cooling absorption: 0.87 kW Heating absorption: 1.23 kW Treated Air Internal Unit: 505 m 3 /h Sound Power Level Indoor Unit : 56 dB(A) External Unit Sound Power Level: 61 dB(A) Sound Pressure Level Indoor Unit : 27~40 dB(A) Sound Pressure Level Outdoor Unit : 48~49 dB(A) Electrical data Power supply (V,Hz, Ø) : 230/50/1 Refrigerant gas : R32 Operating range - Cooling: -10° ~ 46°C - Heating: -15° ~ 24° C Installation data Pipe diameter Liquid : 6.35 mm (1/4") Gas pipe diameter: 9.52 mm (3/8") Maximum piping length: 20 m Maximum height difference Indoor Unit / Outdoor Unit: 10 m Dimensions and weight Internal Unit Dimensions (HxWxD): 285x570x570 mm Indoor Unit Weight: 20 Kg Panel dimensions (HxWxD): 32x620x620 mm External Unit Dimensions (HxWxD): 548x750x288 mm Weight of Outdoor Unit: 32.5 Kg Warranty The residential and light commercial series of Hitachi air conditioners are covered by a 2-year warranty from the date of purchase and a further 5-year warranty on the electronic boards of the outdoor and indoor units as well as on the compressors. This warranty includes parts and labor. 4 Way Cassette The Hitachi Cooling & Heating Unit Most Loved by Architects for Residential Air Conditioning The unit that disappears A simple panel, that's what you see when you choose the Hitachi Cooling & Heating 4-Way Cassette. The recessed installation is the favorite of architects and designers. The aesthetic impact is minimal and is ideal for installation in false ceilings The Shape of Air The extended throw and 4-way distribution of the air flow through the adjustable flaps, gives the environment a uniform and pleasant climate at 360° Cleaning and Control with a Simple Touch Thanks to the panel, the maintenance of the Hitachi Cooling & Heating 4-way Cassette is really easy to use and clean. Switching on and off is very simple via the Hi-Kumo app , you can do it at any time of the day, even when you're at work or traveling Quietness Great comfort in the room thanks to the low sound impact that reaches 27 dB(A) Easier filter cleaning The panel opens with a simple touch for quick and easy cleaning More Comfort Thanks to Independent Flap Control The four air delivery deflectors can be configured individually. Furthermore, they have been designed to avoid the formation of annoying air currents and reduce load losses. The deflector design, shaped to take advantage of the COANDA effect, avoids direct impact of airflow and improves user comfort False ceiling installation Thanks to its reduced height of just 285 mm, it can be easily installed in any false ceiling Compatible with Hi-Kumo Wi-Fi System Thanks to the Hi-Kumo APP you can turn on, turn off, change the temperature or make programming anywhere in the world you are. The system can be controlled via a smartphone with internet connection to the Wi-Fi device (Optional) Built-in Condensate Drain Pump For maximum safety and ease of installation, the system includes a condensate drain pump which allows a useful lift of 850 mm from the false ceiling level Energy saving up to 14% with the Presence Sensor The presence sensor allows to reduce consumption during the phases of occupation of the room, keeping the environment comfortable and generating significant energy savings Energy class A++ High efficiency to achieve the best comfort with the lowest consumption Control Options The system can be controlled by the remote control or with the simplified wall control or with a weekly timer Quality assurance With the purchase of a Hitachi Cooling & Heating air conditioner you can feel comfortable for 5 years . Hitachi guarantees its residential air conditioning systems beyond the two years required by law to ensure well-being and peace of mind every day and for as long as possible. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

The product is available on order Technical features Indoor unit catalog code : PLA-M100EA Outdoor unit catalog code : PUZ-ZM100VKA Panel: PLP-6EA Power: 34000 btu Optional Wi-Fi card : MAC-567IF-E Optional commands Remote control : PAR-SE9FA-E Infrared Receiver : PAR-SL100A-E Wired Command : PAC-YT52CRA-K Deluxe Wired Control : PAR-40MAA White Prism Remote Control : PAR-CT01MAA-SB Black Prism Remote Control : PAR-CT01MAA-PB Energy efficiency SEER: 7.6 SCOP : 4.3 Energy Efficiency Class in Cooling : A++ Heating Energy Efficiency Class: A+ Annual Energy Consumption in Cooling : 435 kWh/a Annual Energy Consumption in Heating: 2521 kWh/a Performance Cooling Capacity: 9.5 kW Heating Capacity: 11.2 kW Cooling absorption: 2.084 kW Heating absorption: 2.685 kW Treated Air Indoor Unit : 19~29 m 3 /min Sound Power Level Indoor Unit : 61 dB(A) External Unit Sound Power Level: 69 dB(A) Sound Pressure Level Indoor Unit : 31~40 dB(A) Sound Pressure Level Outdoor Unit: 49 dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R32 Operating range - Cooling: -15° ~ 46° C - Heating: -20° ~ 21° C Installation data Pipe diameter Liquid : 9.52 mm (3/8") Gas pipe diameter: 15.88 mm (5/8") Maximum piping length: 100 m Maximum height difference Indoor Unit / Outdoor Unit: 30 m Dimensions and weight Internal Unit Dimensions (HxWxD): 298x840x840 mm Indoor Unit Weight: 24 Kg Grid dimensions (HxWxD): 40x950x950 mm Grid weight: 5 Kg External Unit Dimensions (HxWxD): 1338x1050x330 mm Weight of Outdoor Unit: 116 Kg Mitsubishi Electric P Series 4 Way Cassette Units range of new units designed for the creation of a more comfortable environment, which guarantees maximum satisfaction for users. Horizontal stream The new indoor unit is equipped with the "horizontal flow" function which allows to obtain a jet of air that touches the ceiling (Coanda effect), thus increasing the sensation of comfort perceived by the occupants Condensate drain pump included The PLA series units are not only easy to install but also The provision of a drain pump with a head of 550 mm facilitates the drainage of condensate water even in critical conditions 3D i-see sensor The new 4-way recessed ceiling box is equipped with the exclusive “3D I-see Sensor”, a 360° rotating sensor with a data acquisition interval of 3 minutes. It is not only able to detect the temperature , but also the presence , position and number of people in the room Thanks to it, it is therefore possible to manage regulation logics based on the presence of occupants in the air-conditioned environment, with considerable energy savings. Energy saving Thanks to the Energy Saving mode, 3D I-see allows you to modulate the air conditioning power based on the number of people present in the room: when the crowding index corresponds to 30% of the total, the system is able to self-regulate allowing you to save conditioning energy equivalent to about 1°C. When the crowding index tends to 0%, the system switches off automatically, avoiding energy waste. The 3D I-see sensor also features the Seasonal airflow function which allows the maintenance of the set-point temperature by changing the operating mode from air conditioning to ventilation and guaranteeing further savings Comfort By activating the direct/indirect function, the user will be able to decide whether or not to direct the air flow towards the areas where the presence of people is detected. Thanks to the Seasonal airflow mode, the system is able to maintain an excellent level of comfort, avoiding cold drafts in cooling and counteracting the problem of stratification typical of heating mode Energy Save Degree of Crowding The temperature is controlled based on the number of people in the room detected by the 3d-i see sensor. If the degree of crowding is around 30%, a power of 1°C less is supplied Energy Save Empty Room When the room is empty for more than 60 minutes, the power output is reduced by 2°C When no presence is detected for more than 120 minutes, the outdoor machine turns off automatically MELCloud, the Wi-Fi control MELCloud is the new Wi-Fi control for your Mitsubishi Electric system. Taking advantage of the support of the cloud, the "Cloud", to transmit and receive information and the optional dedicated MAC-567IF-E Wi-Fi interface, you can easily control your system wherever you are via PC, tablet or smartphone ; all you need is an internet connection. The MELCloud service was created to have maximum compatibility with PCs, tablets and smartphones thanks to dedicated apps or via a web browser. One word is enough for you! MELCloud is compatible with Google Home. Saying «Hey Google!», or «Ok Google!» you have full control of the climate system. MELCloud is compatible with Amazon Alexa. A word will be enough to freely manage your air conditioning units R32 Power Inverter outdoor units The new R32 Power Inverter Commercial range outdoor units offer numerous advantages. High seasonal efficiency : The use of R32 refrigerant guarantees an increase in seasonal efficiency in cooling Increased piping length : Increased installation flexibility for sizes 60-140 thanks to increased piping length Nominal heating capacity down to -3°C : Nominal capacity is maintained down to -3°C, making it easier to use in cold climates • Compatibility with fan motor for head • MelCloud energy monitoring Power Inverters Energy efficiency finds its maximum expression in the Power Inverter series. The wide operating range and maximum installation flexibility, thanks to particularly long refrigerant lines and the possibility of reusing existing pipes, complete the offer. The Power Inverter Units are equipped with innovative Power Receiver technology and rotary compressors to obtain maximum efficiency Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor unit catalog code : GUD100T/AT Outdoor unit catalog code : GUD100W/NhA-X Panel catalog code : TF06 Power : 36000 Btu Wi-Fi Optional : (Code MC20002050 ) Infrared remote control included : YAP1F6 Energy efficiency SEER : 6.1 SCOP : 4 Energy Efficiency Class in Cooling : A++ Heating Energy Efficiency Class: A+ Annual Energy Consumption in Cooling : 566 kWh/a Annual Energy Consumption in Heating: 3139 kWh/a Performance Cooling Capacity: 12 kW Heating Capacity: 12 kW Cooling absorption: 3 kW Heating absorption: 3.40 kW Treated Air Indoor Unit : 1220~1500 m 3 /h Sound Power Level Indoor Unit : 51~59 dB(A) External Unit Sound Power Level: 70 dB(A) Sound Pressure Level Indoor Unit : 42~50 dB(A) Sound Pressure Level Outdoor Unit : 55 dB(A) Electrical data Power supply (V,Hz, Ø) : 380~415/50/3 Refrigerant gas : R32 Operating range - Cooling: -20° ~ 48°C - Heating: -20° ~ 24° C Installation data Pipe diameter Liquid : 9.52 mm (3/8") Gas pipe diameter: 15.88 mm (5/8") Maximum piping length: 65 m Maximum height difference Indoor Unit / Outdoor Unit: 30 m Dimensions and weight Internal Unit Dimensions Without Panel (HxWxD): 240x840x840 mm Indoor Unit Weight: 31 Kg Panel dimensions (HxWxD): 52x950x950 mm Panel Weight: 6 Kg External Unit Dimensions (WxHxD): 820x940x460 mm Weight of Outdoor Unit: 60 Kg Gree Compact Cassette with 360° Air Delivery • 8-way cassette for applications in the small commercial / service sector • Suitable for shops, offices, meeting rooms, hotels, restaurants, clubs, gyms and open space areas • Compact and attractive design • 8-way air outlet, 360° flow, with flap oscillation range between 45 and 80°, differentiated according to hot/cold mode, for maximum comfort • The 570 x 570 mm dimensions are ideal for installation in false ceilings with standard 600 x 600 mm modules • Fan with aerodynamic profiles optimized to guarantee maximum silence • The condensate drain pump is integrated for a height difference of up to 1000 mm • Dual room temperature sensor for customizable comfort: option to select either return air temperature sensor on the unit or temperature sensor on the wired controller • Connection to a fresh air intake from outside is possible • High energy efficiency, at all powers expressed, both in cooling and in heating, especially with a view to operation 365 days a year (seasonal efficiency) • The special closing system of the refrigerant valve prevents and excludes the risk of refrigerant leaks from inappropriate maintenance • The electrical box has a special design and is made of fireproof material, for maximum protection of the electronic board from fire risks Wi-Fi Optional By integrating the kit, which can be purchased separately, it will be possible to remotely control the unit, via the APP installed on your smartphone, on/off, mode, temperature, etc. to program your own comfort at any time, even when you are away from home Outdoor Unit Characteristics • Energy class up to A++ in cooling mode and up to A+ in heating mode • Intelligent regulation of compressor frequency, accurate temperature control • Reliable cooling and heating down to -20°C outside temperature • Minimization of the sound level thanks to the axial fan • Quick achievement of comfort conditions: the unit allows rapid cooling and heating and is able to quickly reach the temperature set by the user • Intelligent defrost: the unit is able to correctly evaluate the presence of frost on the outdoor unit through a temperature sensor. The goal is to "defrost only when needed", optimizing the heating effect for high environmental comfort Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

The product is available on order NB: COMPLETE WITH GRILLE AND REMOTE CONTROL Technical features Model: Internal catalog unit code: SLZ-M60FA External unit catalog code : SUZ-M60VA Typology : Inverter Energy efficiency: SEER/SCOP (W/W): 6.2/4.1 Energy Efficiency Class (Cool) : A++ Energy Efficiency Class (Heating) : A+ Power (BTU) : 21000 Performance: Rated Capacity Cooling (kW): 5.7 Nominal heating capacity (kW): 6.4 Internal unit sound pressure (dB-A): 27-34-39 External unit sound pressure (dB-A): 49/51 Electrical data: Power supply (V/Hz/?) : 230/50/1 Characteristics: Refrigerant gas : R32 Dimensions: Indoor Unit HxWxD (mm): 245 x 570 x 570 ; 15kg; Grid H x W x D (mm) : 10 x 625 x 625; 3kg; Outdoor Unit HxWxD (mm):880 x 840 x 330 ; 54kg; General characteristics SLZ-M SERIES The ideal solution for offices and commercial establishments The linear shapes of the SLZ-M units make them ideal solutions for offices and shops, ensuring a high level of environmental comfort Optimized energy efficiency and sound pressure reduction Great attention has been paid to seasonal energy efficiency, increased by approximately 10% compared to the previous model, reaching class A++ in cooling. Through the use of the new «3D turbo fan», the units offer significantly improved quietness compared to the previous model SLZ-KA. Modern and elegant design The 4-way cassettes of the SLZ series, designed for installation in 60x60 false ceilings, are the ideal solution for offices or commercial establishments . The use of the straight line gives the units a modern design dominated by linear shapes, making them perfectly combinable with any type of interior. Comfortable airflow Through the introduction of the new fan and thanks to the design of the panel and fins, it is possible to direct the air flow horizontally , directing it completely towards the ceiling and eliminating any type of draft, thus ensuring a high level of comfort. Compactness and simplified installation With a height of 245mm from the false ceiling, a feature that makes it the most compact on the market, the unit is easy to install thanks to the presence of special hooks for the temporary installation of the panel and thanks to the 850mm head of the condensate drain pump in endowment. 3D i-see sensor Thanks to the 3D i-see sensor angular accessory, it is possible to use additional functions for energy saving and room comfort . The sensor makes it possible to direct the air flow directly or indirectly towards the occupants and to reduce the power supplied in moments of less occupancy. This is achieved thanks to a complete mapping of the environment , both in terms of occupancy and temperature, for optimal air distribution. Fresh air intake For an optimal air exchange in rooms with difficult recirculation or for a better well-being of the occupants, the SLZ-KF(M) unit guarantees the possibility of introducing fresh air. Guarantee : All the products for sale on our site are new and packed. The guarantee on this item is 24 months from the date of purchase.

Read more less

The product is available on order only The Product Is Available Of Grid And Remote Control Technical features Model: Internal catalog unit code: SLZ-M50FA External unit catalog code : SUZ-M50VA Typology : Inverter Energy efficiency: SEER/SCOP (W/W): 6.3/4.2 Energy Efficiency Class (Cool) : A++ Energy Efficiency Class (Heating) : A+ Power (BTU) : 18000 Performance: Rated Capacity Cooling (kW): 4.6 Nominal heating capacity (kW): 5.0 Indoor unit sound pressure (dB-A): 51 Outdoor unit sound pressure (dB-A): 64 Electrical data: Power supply (V/Hz/?) : 230/50/1 Characteristics: Refrigerant gas : R32/1.20 Dimensions: Indoor Unit HxWxD (mm): 245 x 570 x 570 ; 15kg Grid HxWxD (mm) : 10 x 625 x 625 ; 3kg Outdoor Unit HxWxD (mm) : 714 x 800 x 285 ; 41kg Main features SLZ-M SERIES The ideal solution for offices and commercial establishments The linear shapes of the SLZ-M units make them ideal solutions for offices and shops, ensuring a high level of environmental comfort Optimized energy efficiency and sound pressure reduction Great attention has been paid to seasonal energy efficiency, increased by approximately 10% compared to the previous model, reaching class A++ in cooling. Through the use of the new «3D turbo fan», the units offer significantly improved quietness compared to the previous model SLZ-KA. Modern and elegant design The 4-way cassettes of the SLZ series, designed for installation in 60x60 false ceilings, are the ideal solution for offices or commercial establishments . The use of the straight line gives the units a modern design dominated by linear shapes, making them perfectly combinable with any type of interior. Comfortable airflow Through the introduction of the new fan and thanks to the design of the panel and fins, it is possible to direct the air flow horizontally , directing it completely towards the ceiling and eliminating any type of draft, thus ensuring a high level of comfort. Compactness and simplified installation With a height of 245mm from the false ceiling, a feature that makes it the most compact on the market, the unit is easy to install thanks to the presence of special hooks for the temporary installation of the panel and thanks to the 850mm head of the condensate drain pump in endowment. 3D i-see sensor Thanks to the 3D i-see sensor angular accessory, it is possible to use additional functions for energy saving and room comfort . The sensor makes it possible to direct the air flow directly or indirectly towards the occupants and to reduce the power supplied in moments of less occupancy. This is achieved thanks to a complete mapping of the environment , both in terms of occupancy and temperature, for optimal air distribution. Fresh air intake For an optimal air exchange in rooms with difficult recirculation or for a better well-being of the occupants, the SLZ-KF(M) unit guarantees the possibility of introducing fresh air. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Indoor unit catalog code : PLA-M125EA Outdoor unit catalog code : PUZ-M125YKA Panel: PLP-6EA Power: 42000 btu Optional Wi-Fi card : MAC-567IF-E Optional commands Remote control : PAR-SE9FA-E Infrared Receiver : PAR-SL100A-E Wired Command : PAC-YT52CRA-K Deluxe Wired Control : PAR-40MAA White Prism Remote Control : PAR-CT01MAA-SB Black Prism Remote Control : PAR-CT01MAA-PB Energy efficiency SEER : 231.9% SCOP : 162% Energy Efficiency Class in Cooling : - Heating Energy Efficiency Class : - Annual Energy Consumption in Cooling : - Annual Energy Consumption in Heating : - Performance Cooling Capacity: 12.1 kW Heating Capacity: 13.5 kW Cooling absorption: 4.01 kW Heating absorption: 3.63 kW Treated Air Indoor Unit : 21~31 m 3 /min Sound Power Level Indoor Unit : 65 dB(A) Sound Power Level Outdoor Unit: 72 dB(A) Sound Pressure Level Indoor Unit : 33~44 dB(A) Sound Pressure Level Outdoor Unit : 54 dB(A) Electrical data Power supply (V,Hz, Ø) : 380~415/50/3 Refrigerant gas : R32 Operating range - Cooling: -15° ~ 46° C - Heating: -15° ~ 21°C Installation data Pipe diameter Liquid : 9.52 mm (3/8") Gas pipe diameter: 15.88 mm (5/8") Maximum piping length: 65 m Maximum height difference Indoor Unit / Outdoor Unit: 30 m Dimensions and weight Internal Unit Dimensions (HxWxD): 298x840x840 mm Indoor Unit Weight: 26 Kg Grid dimensions (HxWxD): 40x950x950 mm Grid weight: 5 Kg External Unit Dimensions (HxWxD): 981x1050x330 mm Weight of Outdoor Unit: 84 Kg Mitsubishi Electric P Series 4 Way Cassette Units range of new units designed for the creation of a more comfortable environment, which guarantees maximum satisfaction for users. Horizontal flow The new indoor unit is equipped with the "horizontal flow" function which allows to obtain a jet of air that touches the ceiling (Coanda effect), thus increasing the sensation of comfort perceived by the occupants Condensate drain pump included The PLA series units are not only easy to install but also The provision of a drain pump with a head of 550 mm facilitates the drainage of condensate water even in critical conditions 3D i-see sensor The new 4-way recessed ceiling box is equipped with the exclusive “3D I-see Sensor”, a 360° rotating sensor with a data acquisition interval of 3 minutes. It is not only able to detect the temperature , but also the presence , position and number of people in the room Thanks to it, it is therefore possible to manage regulation logics based on the presence of occupants in the air-conditioned environment, with considerable energy savings. Energy saving Thanks to the Energy Saving mode, 3D I-see allows you to modulate the air conditioning power based on the number of people present in the room: when the crowding index corresponds to 30% of the total, the system is able to self-regulate allowing you to save conditioning energy equivalent to about 1°C. When the crowding index tends to 0%, the system switches off automatically, avoiding energy waste. The 3D I-see sensor also features the Seasonal airflow function which allows the maintenance of the set-point temperature by changing the operating mode from air conditioning to ventilation and guaranteeing further savings Comfort By activating the direct/indirect function, the user will be able to decide whether or not to direct the air flow towards the areas where the presence of people is detected. Thanks to the Seasonal airflow mode, the system is able to maintain an excellent level of comfort, avoiding cold drafts in cooling and counteracting the problem of stratification typical of heating mode Energy Save Degree of Crowding The temperature is controlled based on the number of people in the room detected by the 3d-i see sensor. If the degree of crowding is around 30%, a power of 1°C less is supplied Energy Save Empty Room When the room is empty for more than 60 minutes, the power output is reduced by 2°C When no presence is detected for more than 120 minutes, the outdoor machine turns off automatically MELCloud, the Wi-Fi control MELCloud is the new Wi-Fi control for your Mitsubishi Electric system. Taking advantage of the support of the cloud, the "Cloud", to transmit and receive information and the optional dedicated MAC-567IF-E Wi-Fi interface, you can easily control your system wherever you are via PC, tablet or smartphone ; all you need is an internet connection. The MELCloud service was created to have maximum compatibility with PCs, tablets and smartphones thanks to dedicated apps or via a web browser. One word is enough for you! MELCloud is compatible with Google Home. Saying «Hey Google!», or «Ok Google!» you have full control of the climate system. MELCloud is compatible with Amazon Alexa. A word will be enough to freely manage your air conditioning units Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

ATTENTION The Product will be available to order and will be shipped within 10 working days! Technical Features Indoor unit catalog code: UT42F.NA0 Outdoor unit catalog code: UUD1.U30 Grid Code : PT-AAGW0 Power: 42000 btu Wired Control Included: (Code PREMTB001 ) Optional Wi-Fi Card: (Code PWFMDD200 ) Optional Infrared Control: (Code PQWRHQ0FDB ) Optional Remote Sensor: (Code PQRSTA0) Energy Efficiency SEER : 7.4 SCOP : 4.3 Annual Energy Consumption in Cooling: 1037 kWh/a Annual Energy Consumption in Heating: 3093 kWh/a Performance Cooling capacity: 12.1 kW Heating capacity: 13.5 kW Cooling Power Consumption: 3.31 kW Heating absorption: 3.51 kW Treated Air Internal Unit: 25 m 3 /min Sound Power Level Indoor Unit: 61 dB(A) Sound Power Level Outdoor Unit: 69 dB(A) Sound pressure level Indoor unit : 41~44 dB(A) Sound pressure level Outdoor unit : 51~52 dB(A) Electrical Data Power supply (V,Hz,Ø) : 220~240/50/1 Refrigerant gas: R32 Operating range - Cooling: -20° ~ 52° C - Heating: -25° ~ 18° C Installation Data Liquid Pipe Diameter: 9.52 mm (3/8") Gas pipe diameter: 15.88 mm (5/8") Maximum length of pipes: 85 m Maximum height difference between internal unit and external unit: 30 m Dimensions and Weight Internal Unit Dimensions (WxHxD): 840x288x840 mm Internal Unit Weight: 25.3 Kg Panel Dimensions: 950x35x950 mm Panel Weight: 7.1 Kg External Unit Dimensions (WxHxD): 950x1380x330 mm External Unit Weight: 85.0 Kg LG 4-Way Cassette Dual Temperature Control The room temperature can be detected in 3 different modes: • From the sensor located in the wired control • From the sensor located on the unit • From both sensors, using the lower of the two detected as the reference value, optimising the internal air temperature for a more comfortable environment ESP Fan Head Regulation The prevalence of the fans can be adjusted using the wired control supplied. Using this adjustment, it is possible to change the rotation speed of the internal unit's fan and associate the machine with installation heights greater than three metres up to a maximum of 4.2 metres. Independent Orientation Each deflector can be oriented independently to better manage the flow in relation to the geometry of the spaces (function available only with the wired control) ONE TOUCH Corners Each corner of the front panel can be removed to facilitate access to the internal unit Temperature Control After Thermistor Possibility of Wi-Fi connection with PWFMDD200 accessory Voice Control If the Wi-Fi module is installed, the internal unit becomes compatible with the Google Home and Alexa voice assistants. Available Functions • Ignition • Power off • Temperature regulation • Setting operating modes • Ventilation regulation • Monitoring External Unit • Self-supporting structure in galvanized steel sheet panels painted in warm grey with surface treatment and Cataphoresis process, a surface treatment capable of providing notable resistance to corrosion in order to protect the external unit from atmospheric agents • Removable right front panel for connection operations with the refrigeration circuit with integrated handle to facilitate transport and positioning of the unit • Removable top cover for access to control components with integrated handle on the right side for easy transport and positioning of the unit • Protective grille on the air expulsion Heat Exchanger Wide Louver Fin external heat exchanger which provides an improvement in exchange efficiency compared to a traditional exchanger, in corrugated copper tube with aluminium fins, coated with a Black Fin galvanic bath anti-corrosion treatment to provide better resistance to acid rain and saltiness in seaside areas. Air intakes protected by a square mesh net of the same colour as the external unit. Protection of the air detection probe in a dedicated housing Compressor Capacity delivery system consisting of 1 hermetic compressor of the Twin Rotary Dc inverter type with direct start, linear capacity control with an action range between a minimum of 10% up to a maximum of 130% Product Warranty: All products for sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.

Read more less

ATTENTION The product will be available on order and will be shipped in 10 working days! Technical features Indoor unit catalog code : RAI-50RPE Outdoor unit catalog number : RAC-50NPE Power : 18000 Btu Panel Included : P-AP56NAMS Optional Wi-Fi Card: ( Code SPX-WFG01 ) Remote Control with Optional Receiver ( Code SPX-RCKA3 ) Simplified Wall Command Optional : ( Code SPX-RCDB ) Optional Wall Control with Weekly Timer : ( Code SPX-WKT3 ) Energy efficiency SEER : 6.2 SCOP : 4.4 Energy Efficiency Class in Cooling : A++ Heating Energy Efficiency Class: A+ Performance Cooling Capacity: 5.0 kW Heating Capacity: 6.0 kW Cooling absorption: 1.42 kW Heating absorption: 1.57 kW Treated Air Internal Unit: 600 m 3 /h Sound Power Level Indoor Unit : 56 dB(A) External Unit Sound Power Level: 65 dB(A) Sound Pressure Level Indoor Unit : 29~43 dB(A) Sound Pressure Level Outdoor Unit : 50~53 dB(A) Electrical data Power supply (V,Hz, Ø) : 230/50/1 Refrigerant gas : R32 Operating range - Cooling: -15° ~ 46° C - Heating: -15° ~ 24° C Installation data Pipe diameter Liquid : 6.35 mm (1/4") Gas pipe diameter: 12.70 mm (1/2") Maximum piping length: 30 m Maximum height difference Indoor Unit / Outdoor Unit: 20 m Dimensions and weight Internal Unit Dimensions (HxWxD): 285x570x570 mm Panel dimensions (HxWxD): 32x620x620 mm External Unit Dimensions (HxWxD): 750x850x298 mm Weight of Outdoor Unit: 50.0 Kg Warranty The residential and light commercial series of Hitachi air conditioners are covered by a 2-year warranty from the date of purchase and a further 5-year warranty on the electronic boards of the outdoor and indoor units as well as on the compressors. This warranty includes parts and labor. 4 Way Cassette The Hitachi Cooling & Heating Unit Most Loved by Architects for Residential Air Conditioning The unit that disappears A simple panel, that's what you see when you choose the Hitachi Cooling & Heating 4-Way Cassette. The recessed installation is the favorite of architects and designers. The aesthetic impact is minimal and is ideal for installation in false ceilings The Shape of Air The extended throw and 4-way distribution of the air flow through the adjustable flaps, gives the environment a uniform and pleasant climate at 360° Cleaning and Control with a Simple Touch Thanks to the panel, the maintenance of the Hitachi Cooling & Heating 4-way Cassette is really easy to use and clean. Switching on and off is very simple via the Hi-Kumo app , you can do it at any time of the day, even when you're at work or traveling Quietness Great comfort in the room thanks to the low sound impact that reaches 27 dB(A) Easier filter cleaning The panel opens with a simple touch for quick and easy cleaning More Comfort Thanks to Independent Flap Control The four air delivery deflectors can be configured individually. Furthermore, they have been designed to avoid the formation of annoying air currents and reduce load losses. The deflector design, shaped to take advantage of the COANDA effect, avoids direct impact of airflow and improves user comfort False ceiling installation Thanks to its reduced height of just 285 mm, it can be easily installed in any false ceiling Compatible with Hi-Kumo Wi-Fi System Thanks to the Hi-Kumo APP you can turn on, turn off, change the temperature or make programming anywhere in the world you are. The system can be controlled via a smartphone with internet connection to the Wi-Fi device (Optional) Built-in Condensate Drain Pump For maximum safety and ease of installation, the system includes a condensate drain pump which allows a useful lift of 850 mm from the false ceiling level Energy saving up to 14% with the Presence Sensor The presence sensor allows to reduce consumption during the phases of occupation of the room, keeping the environment comfortable and generating significant energy savings Energy class A++ High efficiency to achieve the best comfort with the lowest consumption Control Options The system can be controlled by the remote control or with the simplified wall control or with a weekly timer Quality assurance With the purchase of a Hitachi Cooling & Heating air conditioner you can feel comfortable for 5 years . Hitachi guarantees its residential air conditioning systems beyond the two years required by law to ensure well-being and peace of mind every day and for as long as possible. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Control to be purchased separately! Model: Internal Unit Code: ABH160K1ERG Indoor Unit Commercial Code: 25014A99L Outdoor Unit Code: 1U160S2SP1FB Outdoor Unit Commercial Code: 2502309L2 NO SENSOR Panel Code : PB-950KB Power : 60000 Btu Optional Commands: Infrared remote control YR-HQS01 Wired Command YR-E16B Made to Order YR-E17A Daily Timer Wired Control WiFi KZW-W001 Energy efficiency: SEER 5.96 SCOP 3.99 Energy Class in Cooling: A+ Energy Class in Heating: A Annual energy consumption in Cooling : 880 kWh/a Annual energy consumption in Heating : 3859 kWh/a Performance: Cooling Capacity: 15.0 kW Heating Capacity: 16.0 kW Cooling absorption: 5.03 kW Heating absorption: 5.26 kW Treated Air Indoor Unit : 1220 ~ 2050 m³/h Sound Power Level Indoor Unit: 65 dB(A) Sound Power Level Outdoor Unit: 72 dB(A) Sound Pressure Level Indoor Unit : 34 ~ 48 dB(A) Sound Pressure Level Outdoor Unit : 58 dB(A) Electrical data Power supply (V,Hz, Ø) : 380~415/50/3 Refrigerant gas : R32 Operating range - Cooling: -10° ~ 46°C - Heating: -15° ~ 24° C Installation data Pipe diameter Liquid : 9.52 mm (3/8") Gas pipe diameter: 19.05 mm (3/4") Maximum piping length: 70 m Maximum height difference Indoor Unit / Outdoor Unit: 30 m Dimensions and weight: Internal Unit Dimensions (LxPxH): 840x840x288 mm Indoor Unit Weight: 32 Kg Panel dimensions (LxPxH): 950x950x50 mm Panel Weight: 6.5 Kg External Unit Dimensions (LxPxH): 950x370x1350 mm Weight of Outdoor Unit: 101 Kg Haier Round Flow Cassettes Quietness The use of DC Inverter fans and the optimization of the design decrease the noise level of the indoor units. The optimized air flow guarantees the maximum silence of the air conditioner. Does the noise caused by your air conditioner bother you? Haier air conditioners have an advanced noise control system with an optimized design of the air ducts and cross-flow fan. The level of is reached with the Quietness setting only 28dB(A). fresh air the air exchange allows the introduction of clean air into the environment. The "Fresh Air" air inlet setting introduces fresh air into the room, up to a maximum of 20% of the unit's nominal air flow. Furthermore, the filters can be easily accessed from the front panel for cleaning and replacement 8-way flow Thanks to the 8 independent ways it is possible to guarantee a 360° air flow without blind spots. Automatic movement of the flaps. Cassette drives are sized to minimize the footprint of the drive Optional smart sensor The sensor detects the number, position and movement of people to offer optimal temperature control with direct and indirect flows. This technology makes it possible to reduce energy consumption by about 27%, without sacrificing comfort. Wi-Fi Optional Allows you to set the air conditioner remotely even when you are away. Imagine that you are running home in the middle of summer or you are lying on the sofa, but you cannot find the remote control. What you want is to be able to easily control your air conditioner wherever you are and at any time with "Haier Smart Air 2" directly from your phone or tablet With the Haier "hOn" application, you can control all the appliances of the Haier group in your Smart Home from your smartphone or tablet with a single app. Furthermore, through hOn, all the basic functions , purification functions and much more can be managed. The app allows the use of voice commands because it is compatible with Google Assistant and Alexa and therefore also allows voice control Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Model Indoor unit catalog code : AC071RNNDKG/EU Outdoor unit catalog code : AC071RXADKG /EU Power : 24000 Btu Panel included : PC4SUFMAN Optional accessories Wireless command included : AR-EH03E Wired command : MWR-SH11N Wi-Fi card : MIM-H04EN Motion sensor : MCR-SMD Energy efficiency SEER: 6.1 SCOP: 3.8 Energy efficiency class in cooling: A+ Energy efficiency class warming up : a Performance Cooling capacity : 6.80 kW Capacity in heating : 7.50 kW Absorption cooling: 2.75 kW Absorption heating : 2.80 kW Indoor unit treated air: 11.5 m³/min Indoor unit sound power level : 58 dB(A) Sound power level outdoor unit : 65 dB(A) Sound pressure level outdoor unit : 49 ~ 51dB(A) Sound pressure level indoor unit : 36 ~ 42dB(A) Electrical data Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant gas : R-32 Operating range - Cooling: -15° ~ 50°C - Heating: -20° ~ 24° C Installation data Liquid pipe diameter: 6.35 mm (1/4") Gas pipe diameter: 15.88 mm (5/8") Maximum piping length: 50 m Maximum difference in height indoor unit / outdoor unit: 30 m Dimensions and weight Indoor unit dimensions (WxHxD): 575x250x575 mm Indoor unit weight : 12 kg Panel dimensions (WxHxD): 620x46x620 mm Panel weight: 2.7 Kg External unit dimensions (WxHxD): 880x798x310 mm Outdoor unit weight: 51 Kg Samsung 4-Way WindFree Mini Cassette Refresh yourself, but without WindFree TM air Wind-Free™ Cooling technology effectively maintains a pleasant level of freshness, without annoying direct cold air jets. Cold air is gently dispersed through the 15672 micro holes, so as not to create too hot or too cold weather. Optimized Operation with MDS Motion Detection Sensor The motion detection sensor allows for customized airflow and energy-efficient operation Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

PRODUCT AVAILABLE TO ORDER! Technical features Model Indoor unit catalog code : AUXG54KRLB External drive catalog number : AUXG54KATA Type : Cassette Circular air flow Power: 54000 btu/h Performance Dehumidification : 5.0 l/h Nominal cooling capacity : 13.4 kW Nominal heating capacity: 15.5 kW Absorbed power in cooling : 4.87 kW Absorbed power in heating : 4.86 kW Sound pressure Indoor unit Cooling : 47/43/40/36 dB(A) Internal Heating unit sound pressure : 47/43/40/36 dB(A) External unit sound pressure: 58/61 dB(A) Internal unit sound power: 61 dB(A) External unit sound power: 74/75 dB(A) Characteristics Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Liquid Pipe Diameter: 9.52 (3/8") Gas Pipe Diameter: 15.88 (5/8") Drain pipe diameter (int./ext.): 25/32 m Max Piping Length: 30m Maximum height difference: 30m Dimensions and weight Internal Unit Dimensions (HxLxP): 288x840x840 mm Indoor Unit Weight: 29 kg External Unit Dimensions (HxLxP): 998x940x320 mm Weight of Outdoor Unit: 63 kg Warranty FUJITSU GENERAL COMMERCIAL AIR CONDITIONING SPA OFFERS THE POSSIBILITY OF FREE EXTENDING THE LEGAL WARRANTY ON ITS PRODUCTS IN THE RAC AND PAC RANGE FOR A FURTHER 3 YEARS CASSETTE SYSTEM This cassette model sends air in four directions to air-condition the entire room evenly. Adaptable to interiors. Circular flow models distribute airflow 360° with a turbo fan motor and vane design that ensures smooth airflow. Thanks to the Touch wired remote control ( UTY-RNRGZ3 ) the position of each flap can be set differently. KRLB SERIES The AUXG_KRLB series with a unique and elegant design represents an excellent product in this category; it has high performance in terms of energy efficiency and low acoustic impact. This series is characterized by the possible optional addition of the 'Presence Sensor' ( UTY-SHZXC ). This feature increases energy savings which starts automatically with the detection of a person's movement. Two saving modes can be selected: energy or shutdown. Operation at low external temperature Compact Outdoor Unit The new model of the outdoor unit allows for easier installation. Product Guarantee All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

PRODUCT AVAILABLE TO ORDER! Technical features Model Indoor unit catalog code : AUXG09KVLA-E Outdoor unit catalog code : AUXG09KATA Typology : Compact Cassette, 4-way Flow Power: 9000 btu/h Energy efficiency SEER : 6.2 SCOP : 4.0 Seasonal Energy Efficiency Class in Cooling: A++ Seasonal Energy Efficiency Class in Heating: A+ Annual energy consumption Cooling : 141 kWh/a Annual energy consumption Heating : 804 kWh/a Performance Dehumidification : 0.6 l/h Nominal cooling capacity : 2.5 kW Nominal heating capacity: 3.2 kW Power absorbed in cooling: 0.68 kW Power absorbed in heating: 0.88 kW Sound pressure Indoor unit Cooling : 33/31/29/27 dB(A) Internal Heating unit sound pressure : 34/32/29/27 dB(A) Indoor unit sound power : 46/47 dB(A) External unit sound pressure : 47/48 dB(A) External unit sound power : 60 dB(A) Characteristics Power supply (V/Hz/Φ) : 230/50/1 Refrigerant gas : R-32 Liquid Pipe Diameter: 6.35 (1/4") Gas Pipe Diameter: 9.52 (3/8") Drain pipe diameter (int./ext.): 25/32 m Max Piping Length: 15m Maximum height difference: 15m Dimensions Indoor Unit HxLxP (mm) : 245x570x570 Indoor Unit Weight: 15 kg Outdoor Unit HxLxP (mm): 541x663x290 Weight of Outdoor Unit: 23 kg Warranty FUJITSU GENERAL COMMERCIAL AIR CONDITIONING SPA OFFERS THE POSSIBILITY OF FREE EXTENDING THE LEGAL WARRANTY ON ITS PRODUCTS IN THE RAC AND PAC RANGE FOR A FURTHER 3 YEARS CASSETTE SYSTEM The range of compact series cassette units ranges from a minimum capacity of 9,000 BTU/h up to 24,000 BTU/h in the compact version, INVERTER version in direct current. The compact series, contained in the dimensions, is perfectly suited for installation in false ceilings with standard 620x620 mm panels. The grille fits into the compact and elegant ceiling panel design. NEW GENERATION COMPACT CASSETTE UNITS has developed in its research laboratories new concept dual stage fans, to obtain unique performances in terms of energy saving, with better air distribution and extraordinarily low sound levels for the product category, all for a perfect comfort in the environment. KVLA SERIES Easy Maintenance For maintenance, simply remove the ceiling panel near the grille. Maintenance can therefore be performed without the need for an inspection hole. Installation flexibility It is suitable for panel-type ceilings, allows great freedom of installation and can be installed next to the lighting and ventilation opening. Operation at low ambient temperature Product Warranty All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less
