Fitting for IVR multilayer pipe size 16 x 2 General characteristics Brand: IVR Size: 16x2 Typology: for multilayer pipe

Read more less

Ariston monobloc heat pump water heater Nuos Plus 200 code 3069775 A+ Wi-fi Integrated Technical Features Product code: 3069775 Energy label specifications according to European ErP directive Energy efficiency: Class A+ Heating/sanitary operation features: Nominal storage capacity 200 l Maximum hot water capacity at 40°C l 256 Base Positioning Thermal dispersion 21 W Seasonal yield (average climate) 130% Min/max air temperature -7/42°C Sound power 55db Maximum operating pressure 6 bar Resistance power 1500+1000 W IPX4 electrical protection Minimum installation room volume 30m3 Class A+ Profile L Dimensions HxWxD: 173.7x60x68 Weight 90 kg NEWS PLUS WI-FI ARISTON Monobloc Heat Pump Water Heater Floor Monobloc Model. The heat pump revolution with new efficiency standards thanks to the use of air heat as a renewable energy source to obtain greater comfort and high energy savings. * Access to the 65% tax deduction for energy requalification interventions. The intervention must be carried out in compliance with the requirements requested by the Revenue Agency for energy requalification interventions. General Features: Integrated WiFi for APP management Compatible with BridgeNet Bus for integration with complex systems. Lowest warm-up time in its class. Heat pump operating range with air temperatures from -5 to 42°C. Water temperature up to 62°C with the heat pump alone. Sanitary recirculation Active anode (protech) + magnesium anode Internal installation First ignition free. Product Warranty: All products for sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.

Read more less

Heat Pump Water Heater Ariston Nuos Primo HC 240 SYS class A 3069655 Technical features: Type Refrigerant R-134a Minimum storage room temperature 1°C Exchanger surface 0.65m2 Thermal dispersion (PES)* 44W Annual energy consumption (average climate)* 1533 kwh/year Refrigerant charge 900 g Seasonal yield 109% Energy Class A XL load profile Article number 3069655 Heat pump water heater NEW FIRST HC New standards of efficiency thanks to the use of the heat in the air as a source of renewable energy to obtain greater comfort and high energy savings. Furthermore, the system prevents the freezing of the condensed water so that Nuos can operate in heat pump mode even with air at -5°C. Prepared for integration with a solar thermal system. RENEWABLE FUTURE WITH ENERGY EFFICIENCY ITALIAN DESIGN HIGH QUALITY' Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Water Heater Heat Pump Water Heater Haier M5 100 liters HP110M5 Model M5 monoblock HP110M5 Commercial code 25001027Y Reservoir Wall hanging / Ducted installation Tank volume L 110 Power supply V-Hz 220~240V/50Hz Tank pressure Bar 8 Extra Coil / Exchange Surface No Anti-corrosion Magnesium anode IP protection class IPX4 System data Auxiliary electric resistance power W 1200 Average absorbed power (heat pump only) W 240 Maximum absorbed power (heat pump only) W 350 Maximum absorbed power (with electric resistance) W 1550 Default water temperature °C 55 Water temperature range with resistance °C 35÷75 Water temperature range heat pump only °C 35÷65 Refrigerant / quantity kg R134a / 0.45 Global Warming Potential (GWP) 1430 Sound power dB(A) 50 Operating temperature (heat pump only) min~max °C -7÷45 Operating temperature (system) min~max °C -7÷45 Performance Type of extraction Environment / External COP@7°C (EN16147) 2.71 COP@14°C (EN16147) 3.17 Heating time (@7°C) h 4h58 Heating time (@14°C) h 4h09 Tapping cycle (EN16147) M Power absorbed in standby / Pes (@7°C) W 20 Maximum volume of usable hot water (EN16147) L 102.5 Energy efficiency class (ERP) A+ Dimensions and connections Water outlet " G1/2"M Water inlet / Condensate drain " G1/2"M Safety valve " G1/2"M Ducting hole diameter for air intake/delivery mm Ø 160 Water heater dimensions (LxPxH) mm 492x537x1170 Packing dimensions without pallet (LxPxH) mm 587x587x1247 Net weight kg 51 M5 Haier Monobloc AIR/WATER TREATMENT HEAT PUMP WATER HEATER The Haier heat pump water heater line was born thinking about the energy saving of families. Unlike a traditional water heater, heat pump water heaters provide hot water thanks to the heat present in the air, thus saving on your electricity bill. The electrical energy used by the system is only that necessary for the operation of the compressor and the fan. The electric heaters are inserted only if really necessary or if requested by the user (BOOST mode) Heat pump water heater: how does it work? To understand how a heat pump works, it is sufficient to think of how a refrigerator works: it transfers the heat present inside it to the surrounding environment. The Haier water heater reverses the cycle, extracting heat from the air and transferring it to the water. It is possible to channel the incoming and outgoing air outside to exploit the heat present outside Features Haier heat pump water heater The Haier heat pump water heater is designed to offer the best possible experience and maximum savings thanks to: backward curved fan, reduces noise and energy consumption coil at the bottom of the tank, ensures more hot water anti-legionella function, automatically heats the water to 65°C, every seven days, to destroy any bacteria that may form in the tank load shedding control, allows you to stop the operation of the unit in periods programmed by the user The tank of the Haier heat pump water heater The Haier heat pump water heater tank is built with quality materials and components, which ensure excellent thermal insulation and protect the tank from electrochemical corrosion favored by the water, ensuring its correct operation over the years. The tank is also subjected to impulse tests, to ensure a wide range of operating pressure.

Read more less

Technical features Product code: 3623243 Energy label specifications according to the European ErP directive Energy efficiency: Class A Load profile: M profile Characteristics of heating/DHW operation: Monobloc wall mounted water heater COP air 7°C* 2.03 Heating time* h:min 4:28 Min/max air temperature °C -5/42 Sound power (IU) db(A) 15 Sound power (EU) dB(A) 57 Average absorbed electrical power W 510 Maximum quantity of hot water at 40°C* l 139 Nominal accumulation capacity lt: 110 Maximum working pressure bar 8 Maximum absorbed voltage/power V/W 220-240/1950 Empty mass (IU) kg 38 IP24 electrical protection Insulation thickness mm 41 Diameter of water connections " 1/2 M Minimum storage room temperature °C 1 Thermal dispersions (Pes)* W 24 Outdoor unit: Coolant connections diameter 1/4 - 3/8 with flare Empty mass (EU) kg 27 Standard air flow m3 /h 1100 Refrigerant circuit max pressure (low pressure side) bar 12 Refrigerant circuit max pressure (high pressure side) bar 27 IPX4 degree of protection Maximum distance between storage tank and outdoor unit m 8 Maximum height difference between storage tank and outdoor unit m 3 Maximum height difference between storage tank and outdoor unit m 3 For more information CLICK HERE General characteristics Nuos SPLIT 80-110 WH   The Nuos Split water heater is a guarantee of comfort even in the smallest spaces. It stands out for its high energy saving capacity, since it allows you to consume 70% less energy than traditional water heaters . Super compact and silent, it is easy to install and easily transported. Thanks to the technology with which it is equipped, it allows you to easily program five different modes of use, to always have maximum comfort and hot water in large quantities. Working range of the Nuos Split in heat pump with air temperatures from - 5 to 42°C. Ecological gas R134A allows to reach water temperatures up to 62°C in heat pump. Condenser wrapped around the boiler (not immersed in water) Low noise (outdoor unit) Titanium enamelled steel boiler Supplementary electrical resistance Active anode (ProTech) + magnesium anode LCD display Functions: green, boost, boost 2, auto, hourly programming of voyage and anti-legionella samples. Green function Function that maximizes energy savings. The water heater works exclusively in heat pump mode, heating domestic water up to 62°C Boost function Function that reduces the heating times of the water heater to a minimum, increasing sanitary comfort. The machine works simultaneously in heat pump and electrical resistance, speeding up the heating of the water. Once the maximum operating temperature of the heat pump has been exceeded, the electrical resistance continues to heat up to the water set-point temperature. Auto mode Function that allows the best compromise between comfort and savings. The machine optimizes the heat pump and resistance activation logic. Anti-legionella function This function provides for automatic disinfection cycles. On a monthly basis, the machine starts a check and, if necessary, heats the sanitary water up to 65°C, keeping it at this temperature until any bacterial proliferation in the tank is destroyed. Hourly scheduling of withdrawals This is the function that allows you to program times and water temperatures to your liking. The water heater will reach the pre-set temperature at the preferred time (up to two times can be programmed): the process will give priority to heating via the heat pump and, only if necessary, will take place via the electric heaters. Nuos Range: Heat pump water heater Ariston presents NUOS: the widest and most complete range of ecological heat pump water heaters on the market, with high efficiency and energy saving. Ariston has long since chosen the path of ecology and for this reason has been investing for years now in the most advanced technology existing in the sector. The new NUOS heat pump water heaters were therefore born from research: efficient and capable of heating a large quantity of water using very little electricity, as they absorb the heat directly from the outside air. The NUOS range of heat pump water heaters is available in both monobloc and split versions (i.e. with outdoor unit), which can be installed on the wall or on the floor and with capacities ranging from 80 to 300 litres. In new buildings the NUOS range can also be used as an alternative to solar thermal as a source of renewable energy. Heat pump technology The NUOS range uses a thermodynamic cycle to heat the water contained in the storage tank through the air sucked in by the heating unit, reversing the natural flow of heat. A refrigerant fluid (R134A), through changes of state and compression and expansion cycles, takes the heat contained in the air at a lower temperature and transfers it to the sanitary water at a higher temperature. This mechanism is the reverse of the one used in refrigerators. The electrical energy required by the product is only that necessary to operate the fan which captures the air and the compressor which circulates the refrigerant fluid in the circuit. As required by national law, in new buildings it is necessary to satisfy at least 50% of the energy requirement used to heat sanitary water with renewable sources. (Legislative Decree n. 28 of 3 March 2011 based on the RES directive 2009/28/CE). The technology used in NUOS heat pump water heaters is an ideal choice to satisfy these legal obligations, representing an advantageous alternative to solar thermal . It is a valid answer even where there are installation limits due to a building that is not well exposed to the sun. IRPEF tax relief The search for thermal efficiency that distinguishes the NUOS range, as well as allowing immediate savings in terms of low consumption, allows our customers to have the possibility of tax deductions. For more information CLICK HERE Thermal Energy Account As an alternative to tax breaks, again in the event of replacing an electric water heater, the end user can request the incentive provided for by the Thermal Energy Bill, as a capital contribution. The incentive is paid by the GSE (Energy Services Manager) through bank transfer and corresponds to 40% of the expenses incurred for the purchase and expenses related to the installation, up to a maximum of € 400 in a single solution for the replacement of an electric water heater with a heat pump one with a capacity of up to 150 litres; for capacities exceeding 150 liters the refund is in one year if the value of the incentive is less than €600, in two years if it is greater than €600 (the maximum value of the incentive is €700). For more information CLICK HERE Economic saving Considering the profiles of European regulatory requirements, it has been estimated that the annual energy consumption dedicated to the production of domestic hot water of a family of 3 is equal to 1,550 kWh /year. Affordable investment An efficient product consumes less; it follows that, compared to an electric water heater of the same volume, there is an energy saving ed cheap up to 75%. NUOS is therefore an ideal investment that generally pays for itself in about 3 years. Furthermore, for those who take advantage of the tax breaks, the recovery times of the investment are considerably reduced. Energy saving The air is full of heat, a free and renewable energy that comes from the heating of the sun. NUOS manages to extract clean energy from the air and uses it to heat water while consuming only 30% of the electricity required compared to a traditional water heater. It has been estimated that the installation of a NUOS 80 heat pump water heater allows a reduction of 480 kg/year of CO2 linked to the electricity production processes. The same effect would be obtained by the absorption of CO2 by 40 trees. Renewable energy The great innovations are often hidden in what surrounds us on a daily basis. The air, for example, is full of heat, a free and renewable energy that comes from the heating of the sun. NUOS manages to extract clean energy from the air and use it to heat water. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date

Read more less

Ariston Nuos Primo 200 heat pump water heater energy class A code 3623238 Technical features Product code: 3069653 Energy label specifications according to the European ErP directive Energy efficiency: Class A Load profile: L profile Characteristics of heating/DHW operation: COP* 2.85 Heating time** h:min 6.19 Min/max air temperature °C -5/42 Max water temperature heat pump only/with R °C 55/75 Sound power *** dB(A) 53 Average absorbed electric power W 500 Nominal accumulation capacity l 200 Maximum working pressure 6 bar Maximum absorbed voltage/power V/W 220-230/2750 2 Resistance power W 2000 Standard air flow m3/h 400 Minimum volume of the installation room** m3 20 Empty weight kg 87 IP24 electrical protection Insulation thickness mm 31 Diameter of water connections " 3/4 M Minimum storage room temperature °C 1 Thermal dispersions (Pes)* W 28 Available static pressure Pa 55 Annual energy consumption (average climate)* kWh/year 912 Seasonal yield* % 112.3 V40 (quantity of water mixed at 40°C)* l 247 Dimensions mm HxWxD 1706x584x614 Nuos Primo HC Working range in heat pump with air temperatures from -5 to 42 °C R134a ecological gas allows water temperatures to be reached up to 62 °C in heat pump mode Condenser wrapped around the boiler (not immersed in water) Titanium enamelled steel boiler Immersed electric resistance Active anode (protech) + magnesium anode LCD display Functions: green, auto, boost, hourly programming of withdrawals and anti-legionella Coil and probe holder for solar or boiler integration (NUOS PRIMO HC 240 SYS) Integrated carrying straps Product for internal installation First ignition free Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Model : aroSTOR VWL BM 270/5 Product code: 0010026819 Volume : 270 litres Serpentine : Yes Installation: floor standing Energy efficiency Energy efficiency class: A+ COP (A7/W55) : 3.00 Performance Power supply (V,Hz, Ø) : 220~240/50/1 Refrigerant : R290 Inlet / outlet air connection: 160 mm Protection class : IPX4 Operating range : -7° to 45°C Domestic hot water temperature: from 30° to 60°C Maximum domestic hot water temperature HP + resistance: 65°C Sound power : 50 dB(A) Sound pressure : 40dB(A) Maximum electrical power absorbed pdc + resistance: 1900 W Kettle material : Stainless steel Insulation type : PU foam Thickness : 50mm Dimensions and weight Dimensions (HxWxD): 1783x634x634 mm Empty weight: 74.0 kg Full weight: 342.5 kg Heat pump water heater Vaillant aroSTOR floor-standing installation The perfect solution for single-family homes aroSTOR, the new frontier of water heaters: ecological, convenient and silent. Particularly suitable for replacing old electric water heaters or for installation in newly built apartments, aroSTOR heat pump water heaters are ideal for those who choose an electric solution thinking about saving and protecting the environment. Ecological water heating for all needs Whether you are modernizing a detached house or building a new one, with our new aroSTOR heat pump water heater, you can use the air as a renewable heat source for an eco-friendly and efficient hot water supply. aroSTOR is available in the 200 and 270 liter version for floor-standing installation or for the 80 and 100 liter wall-mounted installation. The floor-standing models are equipped with a low-maintenance stainless steel boiler and are suitable for meeting the hot water needs of up to 5 people Made for the climate demands of tomorrow Thanks to the new natural refrigerant R290, choosing aroSTOR is a safe investment, as it is built to meet the stricter future standards of the European F-gas regulation for climate protection. Enjoy maximum comfort with a clear conscience at all times. Efficient, silent and reliable With the aroSTOR hot water heat pump, you can transform 1 kWh of electricity into over 3 kWh of thermal energy for heating water. A glance at the efficiency label confirms this: with its energy efficiency class A+, the aroSTOR can stand up to any comparison. Likewise for silent operation: with a maximum sound pressure level of 41 db(A) at a distance of one metre, the aroSTOR is quieter than a modern refrigerator and can therefore be installed in your living space without any problems. Perfect combination with photovoltaic energy aroSTOR can be easily combined with a photovoltaic system. This gives you the advantage of being able to use the electricity generated by your system all year round. As soon as the sun supplies enough energy, the energy manager of the photovoltaic system activates aroSTOR. The result: with aroSTOR, you not only reduce your CO 2 footprint, but also your energy costs. First ignition free First start-up of the system and free warranty validation with official Vaillant technical assistance centres. aroSTOR floor installation New R290 natural refrigerant gas Stainless steel kettle guaranteed for 5 years Boost function for fast charging Quiet operation: max 40 dB(A) at 1 meter PV ready function for combination with photovoltaics Auxiliary electric resistance 1.2 kW Inlet air temperature range -7°C / +45°C Product guarantee: All products for sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features Product code: 3079033 Energy label specifications according to the European ErP directive Energy efficiency: Class A Load profile: L profile Characteristics of heating/DHW operation: COP* 2.41 Heating time* h:min 3:47 Min/max air temperature °C -5/42 Sound power (IU) db(A) 15 Sound power (EU) db(A) 65 Average absorbed electrical power W 680 Maximum quantity of hot water at 40°C* l 189 Nominal accumulation capacity l 150 Maximum working pressure 6 bar Maximum absorbed voltage/power V/W 220-240/2500 Resistance power W 1500+1000 Empty mass (IU) kg 60 IP24 electrical protection Insulation thickness mm 55 Diameter of water connections " 3/4 M Minimum storage room temperature °C 1 Thermal dispersions (Pes)* W 29 Outdoor unit: Coolant connections diameter 1/4 - 3/8 with flare Empty mass (EU) kg 32 Standard air flow m3 /h 1300 Refrigerant circuit max pressure (low pressure side) bar 12 Refrigerant circuit max pressure (high pressure side) bar 27 IPX4 degree of protection Maximum distance between storage tank and outdoor unit m 8 Maximum height difference between storage tank and outdoor unit m 3 For more information CLICK HERE General characteristics Nuos SPLIT 80-110 WH   The Nuos Split water heater is a guarantee of comfort even in the smallest spaces. It stands out for its high energy saving capacity, since it allows you to consume 70% less energy than traditional water heaters . Super compact and silent, it is easy to install and easily transported. Thanks to the technology with which it is equipped, it allows you to easily program as many as five different modes of use, to always have maximum comfort and hot water in large quantities. Working range of the Nuos Split in heat pump with air temperatures from - 5 to 42°C. Ecological gas R134A allows to reach water temperatures up to 62°C in heat pump. Condenser wrapped around the boiler (not immersed in water) Low noise (outdoor unit) Titanium enamelled steel boiler Supplementary electrical resistance Active anode (ProTech) + magnesium anode LCD display Functions: green, boost, boost 2, auto, hourly programming of voyage and anti-legionella samples. Green function Function that maximizes energy savings. The water heater works exclusively in heat pump mode, heating domestic water up to 62°C Boost function Function that reduces the heating times of the water heater to a minimum, increasing sanitary comfort. The machine works simultaneously in heat pump and electrical resistance, speeding up the heating of the water. Once the maximum operating temperature of the heat pump has been exceeded, the electrical resistance continues to heat up to the water set-point temperature. Auto mode Function that allows the best compromise between comfort and savings. The machine optimizes the heat pump and resistance activation logic. Anti-legionella function This function provides for automatic disinfection cycles. On a monthly basis, the machine starts a check and, if necessary, heats the sanitary water up to 65°C, keeping it at this temperature until any bacterial proliferation in the tank is destroyed. Hourly scheduling of withdrawals This is the function that allows you to program times and water temperatures to your liking. The water heater will reach the pre-set temperature at the preferred time (up to two times can be programmed): the process will give priority to heating via the heat pump and, only if necessary, will take place via the electric heaters. Nuos Range: Heat pump water heater Ariston presents NUOS: the widest and most complete range of ecological heat pump water heaters on the market, with high efficiency and energy saving. Ariston has long since chosen the path of ecology and for this reason has been investing for years now in the most advanced technology existing in the sector. The new NUOS heat pump water heaters were therefore born from research: efficient and capable of heating a large quantity of water using very little electricity, as they absorb the heat directly from the outside air. The NUOS range of heat pump water heaters is available in both monobloc and split versions (i.e. with outdoor unit), which can be installed on the wall or on the floor and with capacities ranging from 80 to 300 litres. In new buildings the NUOS range can also be used as an alternative to solar thermal as a source of renewable energy. Heat pump technology The NUOS range uses a thermodynamic cycle to heat the water contained in the storage tank through the air sucked in by the heating unit, reversing the natural flow of heat. A refrigerant fluid (R134A), through changes of state and compression and expansion cycles, takes the heat contained in the air at a lower temperature and transfers it to the sanitary water at a higher temperature. This mechanism is the reverse of the one used in refrigerators. The electrical energy required by the product is only that necessary to operate the fan which captures the air and the compressor which circulates the refrigerant fluid in the circuit. As required by national law, in new buildings it is necessary to satisfy at least 50% of the energy requirement used to heat sanitary water with renewable sources. (Legislative Decree n. 28 of 3 March 2011 based on the RES directive 2009/28/CE). The technology used in NUOS heat pump water heaters is an ideal choice to satisfy these legal obligations, representing an advantageous alternative to solar thermal . It is a valid answer even where there are installation limits due to a building that is not well exposed to the sun. IRPEF tax relief The search for thermal efficiency that distinguishes the NUOS range, as well as allowing immediate savings in terms of low consumption, allows our customers to have the possibility of tax deductions. For more information CLICK HERE Thermal Energy Account As an alternative to tax breaks, again in the event of replacing an electric water heater, the end user can request the incentive provided for by the Thermal Energy Bill, as a capital contribution. The incentive is paid by the GSE (Energy Services Manager) through bank transfer and corresponds to 40% of the expenses incurred for the purchase and expenses related to the installation, up to a maximum of € 400 in a single solution for the replacement of an electric water heater with a heat pump one with a capacity of up to 150 litres; for capacities exceeding 150 liters the refund is in one year if the value of the incentive is less than €600, in two years if it is greater than €600 (the maximum value of the incentive is €700). For more information CLICK HERE Economic saving Considering the profiles of European regulatory requirements, it has been estimated that the annual energy consumption dedicated to the production of domestic hot water of a family of 3 is equal to 1,550 kWh /year. Affordable investment An efficient product consumes less; it follows that, compared to an electric water heater of the same volume, there is an energy saving ed cheap up to 75%. NUOS is therefore an ideal investment that generally pays for itself in about 3 years. Furthermore, for those who take advantage of the tax breaks, the recovery times of the investment are considerably reduced. Energy saving The air is full of heat, a free and renewable energy that comes from the heating of the sun. NUOS manages to extract clean energy from the air and uses it to heat water while consuming only 30% of the electricity required compared to a traditional water heater. It has been estimated that the installation of a NUOS 80 heat pump water heater allows a reduction of 480 kg/year of CO2 linked to the electricity production processes. The same effect would be obtained by the absorption of CO2 by 40 trees. Renewable energy The great innovations are often hidden in what surrounds us on a daily basis. The air, for example, is full of heat, a free and renewable energy that comes from the heating of the sun. NUOS manages to extract clean energy from the air and use it to heat water. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date

Read more less
