Overview JUNKERS CERAPUR BALCONY ZWB 28-1 EB CONDENSING BOILER for outdoor use COMPLETE WITH FUME KIT - NEW ErP 2016: Wall mounted condensing outdoor boiler with DHW production, combinable with solar thermal systems for DHW using Solar Kit.. Technical specifications Heating and DHW energy efficiency class (ErP): A/A For heating and domestic hot waterÿ Loaded profiles declared XL Nominal heat input (heating): 24.6 kW Nominal thermal power (sanitary): 28 kW Nominal heat input (sanitary): 28.6 kW Thermal efficiency at nominal power 40/30°C: 104.3% Efficiency thermal useful at 30% nominal load 40/30°C: 109.2% Continuous sanitary production: 13.4 l/min Sanitary temperature range that can be set: 40/60°C NOx class: 5 Absorbed electric power: 230 W Degrees of protection: IP X5D Dimensions (D x W x H):ÿ285 x 535 x 775ÿmm; 54kg Version:ÿMETHANEÿ Main features CERAPUR BALCONY Wall-mounted condensing boiler for outdoor use with DHW production, which can be combined with solar thermal systems for DHW using the Solar Kit. Small and compact,ÿCERAPURÿBALCONY has been designed to solve space problems and resist bad weather, while ensuring maximum comfort in the production of heat and domestic hot water. Advantages: Wall-mounted condensing boilers for outdoor use with DHW production, which can be combined with solar thermal systems for DHW using the Solar Kit. Certifications achieved of tipC13, C33, C63, C83, B33. Suitable for use with 60 mm drains. Class 5 emissions required by UNI EN 297, UNI EN 483 and UNI EN 15502 standards. External installation. We will remotely control the digital room chronothermostat with the following functions: two fixed heating programs P1 and P2; a programmable P3 heating program with 22 available time slots; setting of the operating temperatures both in heating and in DHW; display of boiler operating status and any anomalies; in combination with the external probe (accessory) the functioning as a climatic control unit is activated which automatically regulates the delivery temperature according to the external temperature. Automatic antifreeze function up to an external temperature of -15°C, on both the sanitary and heating sides. Fully automatic filling function for the heating circuit. Continuous power modulation (DHW heating). Primary heat exchanger in patented high efficiency aluminosilica alloy. Domestic hot plate heat exchanger for condensing also in DHW. 6 liter heating expansion tanks. Circulator in Energy Class A. The ErP legislation and the new energy labels The future of heating systems Starting fromÿ26 September 2015ÿthe heating systems and for the production of hot water, in order to be placed on the market, will have to comply with theÿErPÿ (Energy Related Products) regulations issued by the European Union. The ErP standards favor the eco-compatible design of products that consume energy from fossil fuels and have the aim of reducing energy consumption and CO2 emissions, as well as providing consumers with transparent and homogeneous information on the energy efficiencyÿ of appliances, favoring comparison. Regulations N 811/2013 and 812/2013 provide for a specific energy labeling of appliances for heating and the production of domestic hot water. Regulations N 813/2013 and 814/2013 prescribe, among other things, the minimum energy efficiency and pollutant emissions requirements that manufacturers of equipment for heating and domestic hot water production must comply with. These regulations therefore raise energy efficiency standards, improving system performance and excluding underperforming technologies from the market. The energy labelÿwill be supplied by the manufacturer with the appliance and will represent a concrete help for the consumer, allowing him to better understand the characteristics of the system, acquire greater awareness of energy saving, allow him to choose better what to buy. The energy label will provide information on the energy class of the product, on a scale between A++ and G, and on other additional notations, such as power and noise emissions. The ErP legislation provides for two types of labelling: the former is supplied by the manufacturer together with the product for heating and/or domestic hot water production appliances the second for systems composed of several elements.ÿ In this second case, the label indicates the levels of energy efficiency that can be reached thanks to all the components used, allowing for an increase in the score attributed to each appliance and increasing the energy class of the system: therefore, the task of whoever builds/installs the system is to provide the consumer with the correct explanatory label . The ErP standards represent an opportunity to develop a market of highly efficient technologies, such as condensing, heat pumps, solar thermal, cogeneration and the integration of different energy sources in a single system. These technologies will have an impact on consumption in the home, approximately 80% of which is due to heating and the production of hot water, and are currently incentivized at the tax level. Junkers Boschÿ already in line with the dictates of the ErP legislation, represent a future that has always distinguished the brand. Warranty All products for sale on our site are new and packed. The guarantee on this article is 24 months from the date of purchase.

Read more less

Gas water heater Therm 5700 S 17 liters t5700s 17 low NOx complete with methane fume exhaust kit 7736504994 Product data Symbol Unit 7736504994 Declared load profile XL Water heating energy efficiency class A Water heating energy efficiency ηwh % 83 Annual electricity consumption AEC kWh 25 Annual fuel consumption AFC GJ 18 Thermostat setting (factory setting) Tset °C 60 Sound power level within LWA dB 63 Daily electricity consumption (average climatic conditions) Qelec kWh 0.112 Daily fuel consumption Qfuel kWh 23,909 Nitrous oxide emissions (for gas and fuel oil only) NOx mg/kWh 26 Dimensions 575 x 365 x 170 mm Therm 5700 S Instantaneous gas water heater with touch display and electronic temperature control Intuitive setting thanks to the touch display Constant temperature hot water for maximum comfort Reduced gas consumption, thanks to the electronic control of the temperature of the water supplied Management with dedicated App, via accessory module Maximum comfort The Therm 5700 S water heater allows you to enjoy maximum comfort thanks to the constant supply of hot water: the temperature monitoring probe guarantees constant water production and without sudden changes in temperature Temperature control To be as efficient as possible, this water heater constantly monitors the temperature and flow rate of the water that is supplied by it, ensuring maximum comfort Intuitive setup Bosch products are designed to be intuitive and easy to use. The settings of the Therm 5700 S water heater are also very simple thanks to the touch display. Furthermore, using a special accessory, it can be controlled remotely via the Bosch Water App Low NOx emissions The water heater is designed to minimize polluting emissions Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Gas water heater Junkers Bosch Open Chamber THERM 4000 10 Liters Low NOx LPG T4004 - NEW Technical features Product data T4004 10 31 Water heating energy efficiency class A Declared load profile M NOx nitrogen oxide emissions (mg/kWh) 28 Sound power level inside LWA [dB(A)] 58 Technical data Technical data T4004 10 Version [kW] Natural gas(1), LPG(2) Nominal thermal power (Pn) [kW] 17.4 Minimum rated heat output (Pmin) [kW] 7.9 Nominal heat input (Qn) [kW] 19.8 Minimum nominal heat input (Qn,min) [kW] 9 Power modulation range (Pn,min-Pn) [kW] 7.9 - 17.4 Flow rate of water supplied with ?T 25 °C [l/min] 10 Efficiency at 100% of nominal heat input (?u,Hi,100%) [%] 88 Efficiency at 30% of nominal heat input (?u,Hi,100%) [%] 88 Maximum operating pressure allowed (pW,max) [bar] 12 Height (mm) 580 Width (mm) 310 Depth (mm) 225 Therm 4000 Instant gas water heater with low emissions available in 10 l/min methane and LPG version Bosch quality and efficiency thanks to the triple safety system and continuous flame modulation Excellent value for money with European production No electrical preparation required thanks to battery power supply Elegant and compact design (only 58 cm in height) Bosch quality and efficiency The Therm 4000 gas water heater guarantees maximum operating safety, thanks to the triple safety system consisting of the smoke outlet sensor, the temperature limiter and a control device which cuts off the gas flow in the event of ignition failure or accidental shutdown. The continuous modulation of the flame also allows this water heater to adapt to real needs. Compact and elegant design Available in methane and LPG versions, the Therm 4000 water heater adapts to any context, thanks to its elegant design and compact dimensions (only 58 cm in height). Furthermore, it does not require any electrical preparation thanks to the battery power supply. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase

Read more less

ATTENTION THE BOILER IS SUPPLIED WITH METHANE. FOR CONVERTING TO LPG, CONTACT THE AUTHORIZED ASSISTANCE SERVICE IN ADVANCE Junkers Bosch Open Chamber Boiler Cerastar 24 KW ZWR 24-7 KE 23 low NOx Product data Symbol Unit 7736900325 Declared load profile M Energy efficiency class C Water heating energy efficiency class B Rated thermal power Prated kW 24 Annual energy consumption QHE GJ 59 Annual electricity consumption AEC kWh 35 Annual fuel consumption AFC GJ 9 Seasonal space heating energy efficiency ηS % 77 Water heating energy efficiency ηwh % 52 Sound power level within LWA dB 49 Information on operating capacity outside peak hours no Specific precautions to be taken at the time of assembly, installation or maintenance (if applicable) see technical documentation Condensing boiler no Low temperature boiler no Boiler B1 yes Cogeneration space heater no Mixed heater yes Useful thermal power At rated heat output and high-temperature regime P4 kW 24.3 At 30 % of rated heat output and low temperature regime P1 kW 7.3 Efficiency At rated heat output and high-temperature regime η4 % 81,0 At 30 % of rated heat output and low-temperature regime η1 % 80,7 Auxiliary electricity consumption At full load elmax kW 0.019 At partial load elmin kW 0.018 In stand-by mode PSB kW 0.007 Other items Heat loss in stand-by Pstby kW 0.193 Nitrous oxide emissions (for gas and fuel oil only) NOx mg/kWh 22 Other items for combination heaters Daily electricity consumption (average climatic conditions) Qelec kWh 0.160 Daily fuel consumption Qfuel kWh 10,850 Dimensions HxWxD mm 850x440x380 Junkers Bosch CERASTAR boiler Environmentally friendly and NOx class 6 The Cerastar conventional boiler uses the best technologies to respect the environment. In fact, thanks to its components, the level of polluting emissions is reduced, following the new ErP 2018 regulation. Management via EasyControl smart thermostat The boiler can be controlled via the Bosch EasyControl smart thermostat. The new regulator that allows you to manage home heating directly from your smartphone and that simply adapts to your habits. Zero noise, zero stress The Cerastar boiler is among the quietest in its category, in fact with its 46 decibels (18 kW Cerastar) it will allow you to use all its functions in silence. Hot water, when you want it The Cerastar boiler achieves 3 stars in sanitary comfort according to European standards EN13203-1/2 and allows you to use domestic hot water when you wish. The boiler's Comfort function offers you the possibility of preheating the water, programming the appliance at specific times based on your routine. The Eco function, on the other hand, is designed to save energy and have a lower impact on bill costs. Product Warranty The warranty on this item is 24 months from the date of purchase.

Read more less

ATTENTION THE BOILER IS SUPPLIED WITH METHANE. FOR CONVERTING TO LPG, CONTACT THE AUTHORIZED ASSISTANCE SERVICE IN ADVANCE Junkers Bosch Open Chamber Boiler Cerastar 18 kw zwr 18-7 ke 23 NOx 6 Code 7736900324 TECHNICAL FEATURES Declared load profile S Energy efficiency class C Water heating energy efficiency class A Rated thermal power Prated kW 18 Annual energy consumption (average climate conditions) QHE kWh - Annual energy consumption QHE GJ 44 Annual electricity consumption AEC kWh 27 Annual fuel consumption AFC GJ 4 Seasonal space heating energy efficiency ηS % 77 Water heating energy efficiency ηwh % 43 Sound power level within LWA dB 46 Useful thermal power At rated heat output and high-temperature regime P4 kW 18.2 At 30 % of rated heat output and low temperature regime P1 kW 5.4 Efficiency At rated heat output and high-temperature regime η4 % 81,1 At 30 % of rated heat output and low-temperature regime η1 % 81,0 Auxiliary electricity consumption At full load elmax kW 0.020 At partial load elmin kW 0.019 In stand-by mode PSB kW 0.007 Other items Heat loss in stand-by Pstby kW 0.177 Ignition burner power consumption Pign kW - Nitrous oxide emissions (for gas and fuel oil only) NOx mg/kWh 22 Other items for combination heaters Daily electricity consumption (average climatic conditions) Junkers Bosch CERASTAR boiler Environmentally friendly and NOx class 6 The Cerastar conventional boiler uses the best technologies to respect the environment. In fact, thanks to its components, the level of polluting emissions is reduced, following the new ErP 2018 regulation. Management via EasyControl smart thermostat The boiler can be controlled via the Bosch EasyControl smart thermostat. The new regulator that allows you to manage home heating directly from your smartphone and that simply adapts to your habits. Zero noise, zero stress The Cerastar boiler is among the quietest in its category, in fact with its 46 decibels (18 kW Cerastar) it will allow you to use all its functions in silence. Hot water, when you want it The Cerastar boiler achieves 3 stars in sanitary comfort according to European standards EN13203-1/2 and allows you to use domestic hot water when you wish. The boiler's Comfort function offers you the possibility of preheating the water, by programming the appliance at specific times based on your routine. The Eco function, on the other hand, is designed to save energy and have a lower impact on bill costs. Product Warranty The warranty on this item is 24 months from the date of purchase.

Read more less

Gas water heater Junkers Bosch Therm 5600 S T5600 S 15 liters LPG Low NOx INDOOR - NEW Technical features: ACS energy class: A Declared load profile: XL Model: Therm 5600 OR T5600 OR 15 Installation Type: Indoor Power supply: LPG Technical data: Thermal power: 27.0 kW Minimum thermal power: 4.7 kW Thermal input: 30.0 kW; Minimum heat input: 5.0 kW Yields: At 100% of nominal flow: 90% At 30% of nominal flow: 94% Maximum Pressure: 12 bar Minimum operating pressure: 0.1 bar Modulation range: 4.7 - 27.0 kW Maximum water flow corresponding to a ∆t of 25°: 15.0 l/min Sound power level indoors: 59 db(A) Annual electricity consumption: 37 kWh Electrical Protection Degree: IPX4D Dimensions: (PxLxH): 170x365x575 mm; Weight: 13 Kg General characteristics: Junkers Bosch water heater model Therm 5600 S , gives a touch of innovation to your home, with extremely small dimensions becoming part of the furniture, guaranteeing very high performance, it has a modern and refined design, with display with touch regulation and, through a special accessory, possibility of remote control via the Bosch Water App. It has never been so easy to manage your water heater, now also comfortably seated through your electronic devices (Smartphone or Tablet), via Bluetooth, in fact Therm 5600 s by downloading the Bosch Water App, available for iOS and Android, allows you to regulate the temperature, manages consumption and if there is any malfunction, from precise diagnostics. Having the possibility of regulating the degree of temperature, it allows you to save between 20 and 100% of the maximum power, according to your needs, guaranteeing maximum efficiency in any circumstance, significantly reducing energy consumption. Advantages: It offers maximum comfort by producing hot water constantly, without sudden changes or interruptions, thanks to the probe for monitoring the real and desired temperature Extremely Efficient with constant electronic control of the temperature of the water supplied Easy to install, perfect even in case of replacement Sustainable: low NOx emissions Intuitive display with touch adjustment and, using a special accessory, the possibility of remote control via the Bosch Water App (Optional) Installation flexibility also combining with solar thermal systems for DHW production (Optional) and fumes discharge up to 12 meters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Technical features: ACS energy class: A Declared load profile: XL Model: Therm 5600 S T5600 S 17 Installation Type: Indoor Power supply: METHANE Technical data: Thermal power: 29.1 kW Minimum thermal power: 5.2 kW Thermal input: 32.0 kW Minimum thermal input: 5.5 kW Yields: At 100% of nominal flow: 90% At 30% of nominal flow: 94% Maximum Pressure: 12 bar Minimum operating pressure: 0.1 bar Modulation range: 5.2 - 29.1 kW Maximum water flow corresponding to a ∆t of 25°: 17.0 l/min Sound power level indoors: 63 db(A) Annual electricity consumption: 40 kWh Electrical Protection Degree: IPX4D Dimensions: (DxWxH): 170x365x575 mm; Weight: 15Kg General characteristics: Junkers Bosch water heater model Therm 5600 S , gives a touch of innovation to your home, with extremely small dimensions becoming part of the furniture, guaranteeing very high performance, it has a modern and refined design, with display with touch regulation and, through a special accessory, possibility of remote control via the Bosch Water App. It has never been so easy to manage your water heater, now also comfortably seated through your electronic devices (Smartphone or Tablet), via Bluetooth, in fact Therm 5600 s by downloading the Bosch Water App, available for iOS and Android, allows you to regulate the temperature, manages consumption and if there is any malfunction, from precise diagnostics. Having the possibility of regulating the degree of temperature, it allows you to save between 20 and 100% of the maximum power, according to your needs, guaranteeing maximum efficiency in any circumstance, significantly reducing energy consumption. Advantages: It offers maximum comfort by producing hot water constantly, without sudden changes or interruptions, thanks to the probe for monitoring the real and desired temperature Extremely Efficient with constant electronic control of the temperature of the water supplied Easy to install, perfect even in case of replacement Sustainable: low NOx emissions Intuitive display with touch adjustment and, using a special accessory, the possibility of remote control via the Bosch Water App (Optional) Installation flexibility also combining with solar thermal systems for DHW production (Optional) and fumes discharge up to 12 meters Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Gas water heater Junkers Bosch THERM 5600 O T5600 O 15 liters Low NOx for outdoor LPG - NEW Technical features: ACS energy class: A Declared load profile: XL Model: Therm 5600 OR T5600 OR 15 Installation Type: External Power supply: LPG Technical data: Thermal power: 2ù,0 kW Minimum thermal power: 4.7 kW Thermal input: 30.0 kW Minimum heat input: 5.0 kW Yields: At 100% of nominal flow: 90% At 30% of nominal flow: 95% Maximum Pressure: 12 bar Minimum operating pressure: 0.1 bar Modulation range: 4.7 - 27.0 kW Maximum Water flow corresponding to a ∆t of 25°: 15.0 l/min Sound power level indoors: 59 db(A) Annual electricity consumption: 37 kWh Electrical Protection Degree: IPX4D Dimensions: (LxWxH): 170x365x575mm Weight: 13Kg Therm 5600O Ease of installation Bosch makes products that are easy to use and easy to install. The THERM 5600 SO water heater does not require fume extraction and exhaust systems Robust and cold resistant Outdoor products suffer during the harsh winter climate. Bosch water heaters are tested to withstand low temperatures and bad weather, thanks to the standard antifreeze device Simple and intuitive The water heater can be controlled from inside the home through the new regulator, in black glass with a large display and via bluetooth via smartphone. All this is made possible by the App to monitor consumption, temperatures and any error codes Eco-sustainable and versatile Bosch has always combined technology and the environment, creating products that are versatile with each other, in fact the THERM 5600 SO water heater can be combined with thermal systems for the production of domestic hot water (using the appropriate accessory). Furthermore, the attention paid to the environment is always maximum, the water heater is eco-sustainable and with low NOx emissions Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Junkers Bosch Tronic 3500 T 50 liter electric water heater Product data Symbol Unit 7736504805 Declared load profile M Water heating energy efficiency class C Water heating energy efficiency ηwh % 37 Annual electricity consumption AEC kWh 1405 Thermostat setting (factory setting) Tset °C 57 Sound power level within LWA dB 15 Information on operating capacity outside peak hours no Smart Control No Daily electricity consumption (average climatic conditions) Qelec kWh 6,563 Mixed water at 40 °C V40 l 68 Dimensions HxWxD mm 610x500x500 Electric 3500 T Electric water heater for the production of domestic hot water Water temperature gauge available Corrosion protection thanks to internal enamelling and magnesium anode Low standby power consumption Temperature regulation between 20°C and 60°C Advantages Available in 3 liters (50/80/100 L) Available in 50 L, 80 L and 100 L versions, making it the ideal solution for any need. Plenty of water available from different withdrawal points The high water storage allows the use of domestic hot water from different withdrawal points at the same time. Efficient and robust Robust construction with corrosion protection thanks to internal enamelling and magnesium anode. Solar integration with a special solar kit Possibility of integration with solar thermal kit for very high performance and ease of installation in any type of home. Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Junkers Bosch CR 100 modulating chronothermostat Chronothermostat with built-in sensor Modern design and backlit display Modulating chronothermostat with weekly programming Integrated sensor Thanks to this innovative chronothermostat you can ensure the desired room temperature thanks to the integrated sensor Modern design Chronothermostat with a modern design and backlit display Weekly programming The modulating chronothermostat features weekly programming with 6 daily switching points, control and management of a single direct or mixed heating zone and the production of domestic hot water. Possible management of the solar circuit for the production of DHW (domestic hot water) Product Warranty All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Therm 5700 S 12 liter gas water heater t5700s 12 low NOx complete with LPG fume exhaust kit Declared load profile M Water heating energy efficiency class A Water heating energy efficiency ηwh % 71 Annual electricity consumption AEC kWh 20 Annual fuel consumption AFC GJ 6 Other load profiles S Water heating energy efficiency (other load profiles) ηwh % 71 Annual electricity consumption (other load profiles, average climate conditions) AEC kWh 18 Annual fuel consumption (other load profiles) AFC GJ 2 Thermostat setting (factory setting) Tset °C 60 Sound power level within LWA dB 60 Information on operating capacity outside peak hours no Dimensions WxHxD 335x575x180 Therm 5700 S Instantaneous gas water heater with touch display and electronic temperature control Intuitive setting thanks to the touch display Constant temperature hot water for maximum comfort Reduced gas consumption, thanks to the electronic control of the temperature of the water supplied Management with dedicated App, via accessory module Maximum comfort The Therm 5700 S water heater allows you to enjoy maximum comfort thanks to the constant supply of hot water: the temperature monitoring probe guarantees constant water production and without sudden changes in temperature Temperature control To be as efficient as possible, this water heater constantly monitors the temperature and flow rate of the water that is supplied by it, ensuring maximum comfort Intuitive setup Bosch products are designed to be intuitive and easy to use. The settings of the Therm 5700 S water heater are also very simple thanks to the touch display. Furthermore, using a special accessory, it can be controlled remotely via the Bosch Water App Low NOx emissions The water heater is designed to minimize polluting emissions Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less

Gas water heater Therm 5700 S 15 liters t5700s 15 low NOx complete with smoke exhaust kit 7736504993 Product data Symbol Unit 7736504993 Declared load profile XL Water heating energy efficiency class A Water heating energy efficiency ?wh % 83 Annual electricity consumption AEC kWh 26 Annual fuel consumption AFC GJ 18 Thermostat setting (factory setting) Tset °C 60 Sound power level within LWA dB 61 Information on operating capacity outside peak hours no Specific precautions to be taken at the time of assembly, installation or maintenance (if applicable) see technical documentation Smart Control No Daily electricity consumption (average climatic conditions) Qelec kWh 0.120 Daily fuel consumption Qfuel kWh 23,923 Nitrous oxide emissions (for gas and fuel oil only) NOx mg/kWh 17 Dimensions 575 x 365 x 170 mm Therm 5700 S Instantaneous gas water heater with touch display and electronic temperature control Intuitive setting thanks to the touch display Constant temperature hot water for maximum comfort Reduced gas consumption, thanks to the electronic control of the temperature of the water supplied Management with dedicated App, via accessory module Maximum comfort The Therm 5700 S water heater allows you to enjoy maximum comfort thanks to the constant supply of hot water: the temperature monitoring probe guarantees constant water production and without sudden changes in temperature Temperature control To be as efficient as possible, this water heater constantly monitors the temperature and flow rate of the water that is supplied by it, ensuring maximum comfort Intuitive setup Bosch products are designed to be intuitive and easy to use. The settings of the Therm 5700 S water heater are also very simple thanks to the touch display. Furthermore, using a special accessory, it can be controlled remotely via the Bosch Water App Low NOx emissions The water heater is designed to minimize polluting emissions Product Guarantee: All products for sale on our site are new and packed. The warranty on this item is 24 months from the date of purchase.

Read more less
